Summary of Contents for EKF PROXIMA VD-100N
- Page 1 TECHNICAL MANUAL Residual current circuit breaker VD-100N PROXIMA EKF...
- Page 2 1 DESCRIPTION Residual current circuit breakers VD-100N PROXIMA EKF are used in 50/60 Hz AC electrical circuits. Residual current circuit breakers (RCCB) are designed to: • protect persons against electric shock by accidental indirect contact with exposed conductive parts of electrical installation;...
-
Page 3: Technical Data
2 TECHNICAL DATA Table 1 - Main characteristics Characteristics Values Number of poles 1P+N; 3P+N 1P+N: 220/230/240; Rated operating voltage Ue, V AC 3P+N: 380/400/415 10,16, 25, 32, 40, Rated current In, А 50, 63, 80, 100 Rated breaking residual current 10,30,100,300 IΔn, mA Frequency, Hz... -
Page 4: Tripping Characteristics
3 TRIPPING CHARACTERISTICS Table 2 - Trip /non-trip time limits for alternating residual current, VD-100N, types AC and A. Type In,А IΔn, мА Trip /non-trip time limits for alternating residual current, VDT-100N, types AC and A, sec. IΔn 2IΔn 5IΔn 500А... -
Page 5: Overall Dimensions
4 OVERALL DIMENSIONS 35,7 71,7 44,5 72,1 Fig. 1... -
Page 6: Installation And Connection
5 INSTALLATION AND CONNECTION RCCB shall be installed and connected by qualified electrical personnel. Before installation, make sure that: • Device characteristics (RCCB marking) meet the required values. • The device has no visible damage. • The mechanism properly operates by turning the handle a few times and pressing the «T»... - Page 7 RCCB Wiring diagram (electromagnetic) RCCB VD-100N 1P+N RCCB VD-100N 3P+N Fig. 2...
-
Page 8: Operation Conditions
If vertically installed, upper position of the operating handle shall correspond to the RCCB ON status, while the handle lower position shall correspond to the RCCB OFF status in compliance with IEC 60447. If horizontally installed, the handle right position shall correspond to the RCCB ON status, while the handle left position shall correspond to the RCCB OFF status. -
Page 9: Maintenance
9 MAINTENANCE For maintenance, follow national safety rules for operation of electrical Installations. Under normal operating conditions: test RCCB operation with the Test button every month; visually inspect the device and tighten screw terminals every 6 months. Do not operate the RCCB, if visual damage to its housing is found. -
Page 10: Manufacturer's Warranty
MEA regional headquarters: EKF ELECTRICAL SOLUTION FZCO, Office 249, Techno Hub-2, Dubai Silicon Oasis, P.O. box 341079, Dubai, United Arab Emirates, tel. +9 (714) 547-06-18. Importer and EKF trademark service representative оn the territory of the Republic of Kazakhstan: «Energoresheniya Kazakhstan»,... -
Page 11: Certificate Of Acceptance
13 CERTIFICATE OF ACCEPTANCE The residual current circuit breaker VD-100N PROXIMA EKF has been approved for operation. Date of manufacture: for information, refer to the product package. Quality control stamp...
