  • Page 1 USER MANUAL MODEL ILCA 150W 1492SE...

  • Page 2: Table Of Contents

    6. CHARACTERISTICS OF THE WHEELCHAIR 7. UNPACKING AND UNFOLDING 8. CONTROL PANEL INTRODUCTION (JOYSTICK) 9. WHEELCHAIR FOLDING STEPS 10. BATTERY DISASSEMBLY 11. CHARGING 12. BATTERY USE 13. PRECAUTIONS FOR OPERATION 14. MAINTENANCE 15. STORAGE 16. QUALITY ASSURANCE MANUAL DE USUARIO MODELO ILCA 150W 1492SE...

  • Page 3: Introduction

    1. INTRODUCTION Dear customer, Welcome aboard your new power wheelchair model 1492SE ILCA 150W. Thank you for choosing a Teyder product. This model has been designed with the specific needs of the user and/or the caregiver in mind, combining an ultra-light chassis that is easy to transport, with the dual functionality of manual or electronic mode of use.
  • Page 4 15. During the use of the patient, routine cleaning once a day, when replacing infected patients, must be thoroughly disinfected with disinfectant. **The product has a normal service life of 5 years from the date of delivery. MANUAL DE USUARIO MODELO ILCA 150W 1492SE...

  • Page 5: Overview

    1. Motor: DC24V Lithium Battery 150W 2PCS 2. Battery capacity: DC24V 6AH/12AH/ 18AH 3. Charger: ZB2402ML 100-240V 50/60Hz Maximum out current: 2A 4. Charging time: 5 – 8 hours 5. Controller: Maximum out current: 24V/30A MANUAL DE USUARIO MODELO ILCA 150W 1492SE...

  • Page 6: Characteristics Of The Wheelchair

    2. Aluminium alloy frame: the complete wheelchair weighs 19 kg (with battery). 3. Easy to lift with one hand, easy to store and transport. 4. Armrest can be raised. 5. Improve the telescopic fixing structure. 6. Electromagnetic brake 7. Optional Bluetooth remote control MANUAL DE USUARIO MODELO ILCA 150W 1492SE...
  • Page 7 8. Displaced Motor 9. Lift with one hand 10. Lifted Armrest 11. Telescopic anti-roll frame MANUAL DE USUARIO MODELO ILCA 150W 1492SE...

  • Page 8: Unpacking And Unfolding

    Install the anti-rolling frame: Align the holes at the back, insert the anti-rolling frame, and install the pins (as shown in the figure). 7.4. Engine clutch Motor clutch gear adjustment: electric mode (hand push cannot be done); push mode, you can push wheelchair (cannot drive). Push mode Electric mode MANUAL DE USUARIO MODELO ILCA 150W 1492SE...

  • Page 9: Control Panel Introduction (Joystick)

    Power on (make sure it is in electric mode) 1. Battery indicator all 5 lights are on fully charged 2. Power Switch 3. Slow down 4. 360º Joystick 5. Horn 6. Accelerate 7. Speed Indicator MANUAL DE USUARIO MODELO ILCA 150W 1492SE...
  • Page 10 Charger socket: This socket is only used to charge the wheelchair. This socket must not be used as a power source for any other electrical device. If other electrical devices are connected, the control system or the EMC performance of the wheelchair may be damaged. MANUAL DE USUARIO MODELO ILCA 150W 1492SE...
  • Page 11 8.4. Pairing instructions with the remote control The controller is paired with the chair once the following steps are carried out MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...

  • Page 12: Wheelchair Folding Steps

    Lift both sides to fold the wheelchair. The whole wheelchair can be lifted by the hand strap. 10. BATTERY DISASSEMBLY Press the spring group next to the battery, lift the pole up, open the battery compartment, remove the battery. MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...

  • Page 13: Charging

    3. When the charging indicator on the charger turns green, it indicates that the power is sufficient, unplug the charger and the charging output plug when sufficient. 4. Charging method: Insert charging head of the charger into the charging port on the bottom of the controller. MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...

  • Page 14: Battery Use

    “S” shaped turn. After you are familiar with "S" shaped turn, to practice backward operation, and pay attention to the speed control setting. And the backward speed should lower than forward speed. MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...

  • Page 15: Maintenance

    14.3. Temperature  Some parts of your wheelchair are susceptible to temperature.  In extremely cold temperature, the battery can be frozen.  Temperature above 55°may cause your wheelchair’s speed to be reduced. MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...
  • Page 16  Clean the wheelchair with a clean, soft cloth and wipe it dry. Never use chemicals to clean it (to prevent it from reforming and discolouring). MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...

  • Page 17: Storage

    Batteries are guaranteed for 6 months. If you need a repair, please contact the dealer who sold it to you, through whom we will provide you with the necessary support. MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...
  • Page 18 Manufacturer: Suqian Excellent Science and Technology Co., Ltd Room 501-1, Buildng A, Software park Shuyang Country, Suqian, Jiangsu China Representative CE: RIOMAVIX S. L. C/ de Almansa, 55, 1D 28039 Madrid España MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...
  • Page 19 MANUAL DE USUARIO MODELO ILCA 150W 1492SE 1492SE...
