- Page 1 OPM-200 High Performance Optical Power Meter User Manual M-OPM-200_1.4...
- Page 2 OPM-200 User Manual All information contained herein is believed to be accurate and is subject to change without notice. No responsibility is assumed for its use. © Santec Inc., 2023. All rights reserved.
-
Page 3: Table Of Contents
FDA-CDRH Compliance ........................... 1 CSA / IEC Compliance ..........................1 CE Compliance ............................1 GENERAL INFORMATION ..................... 2 OPM-200 High Performance Optical Power Meter Overview ............2 Applications ..............................2 Key Features .............................. 2 Test & Measurement Standards ......................3 Included Accessories .......................... - Page 4 OPM-200 User Manual Notes ................................21 Commands Lists ............................21 MAINTENANCE ......................25 Cleaning the Unit ............................. 25 Cleaning the Detector Glass ........................25 STORAGE AND SHIPPING ................... 26 Returning Instruments to Santec ......................26 Contact Information ..........................26 SPECIFICATIONS ......................27...
-
Page 5: List Of Figures And Tables
LIST OF FIGURES AND TABLES Figure 1: OPM-200 High Performance Optical Power Meter ............2 Figure 2: Front view of an OPM-200 with two front panel 2mm InGaAs detectors ....... 7 Figure 3: Rear view of an OPM-200 ..................... 8 Figure 4: Front view of an RD-IN2-OPM-200 with FC sliding detector adapter (SD-FC) .... -
Page 6: Compliance
OPM-200 User Manual COMPLIANCE FDA-CDRH Compliance Under the US Food and Drug Administration (FDA) Center for Devices and Radiological Health (CDRH), the unit complies with the Code of Federal Regulations (CFR), Title 21, Subchapter J, which pertains to laser safety and labeling. See following link for more information: •... -
Page 7: General Information
OPM-200 High Performance Optical Power Meter Overview The OPM-200 is designed to provide accurate and precise measurements with a dynamic range of +8 dBm to -80 dBm with the 2 mm InGaAs detector and +30 to -50 dBm with the integrating sphere detector. -
Page 8: Test & Measurement Standards
OPM-200 User Manual o Simple and intuitive programming o Input trigger and analog output • Detector options o Remote-head: up to 10m o Front panel mounted Test & Measurement Standards • NIST traceable • ISO 17025 calibration Included Accessories •... -
Page 9: Safety Information
Santec assumes no liability for the customer’s failure to comply with any of these safety requirements. Classification The OPM-200 consists of an exposed metal chassis that is connected directly to earth via a power cord and is therefore classified as a Class 1 instrument. Important Safety Information... - Page 10 If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. Only technicians authorized by Santec should carry out repairs. In addition to voiding the warranty, opening the unit (even when unplugged) can expose you to potential shock hazards.
-
Page 11: Getting Started
SAFETY INFORMATION on page 4. This manual contains complete operating instructions for safe and effective operation of the OPM- 200 High Performance Optical Power Meter. It is recommended that users of the OPM-200 familiarize themselves with contents of this manual before using the instrument. -
Page 12: Product Overview
Product Overview OPM-200 Front Panel A front view of the OPM-200 is shown in Figure 2. It features a touchscreen which displays information such as power, wavelength, modules, and settings Standard configurations have the detector and analog output mounted on the front panel or have a remote-head M12 port. -
Page 13: Opm-200 Rear Panel
OPM-200 User Manual OPM-200 Rear Panel A rear view of the OPM-200 is shown in Figure 3. See Table 2 for a detailed description. Figure 3: Rear view of an OPM-200 Table 2: Detailed description of the OPM-200 rear panel components (see Figure 3) -
Page 14: Rd-Xxx-Opm-200 Remote-Head Detector
Remote- heads are detected on startup. Figure 4 and Figure 5 show the front and rear of an RD-IN2-OPM-200 (see Table 3 for a detailed description). -
Page 15: Operation
1. Verify that the power switch is set to the “off” position (O). Connect the meter to an AC power supply using the power cord provided. 2. Toggle the power switch to the “on” position (I). The Santec logo will flash on the screen during the unit’s initialization. - Page 16 Select the desired averaging time (as shown is 10 ms averaging) IP address • When the OPM-200 is connected by Ethernet, the IP address is shown here. If there is no IP address assigned, a red logo is displayed (as shown)
-
Page 17: Module Level
OPM-200 User Manual Module level If you select a module, the touchscreen pages will show you the details and let you modify the settings of that module (Figure 8). ß Swipe à Figure 8: Module level touchscreen pages The Setup page of the module level acts in the same way as the top level page except the settings are applied only to the selected module with the exception of Dark All which still applies to all detectors. - Page 18 OPM-200 User Manual Figure 9: Units selector flyout...
- Page 19 OPM-200 User Manual Tapping once on the wavelength button (λ) brings you to the wavelength selector page (Figure 10). Tapping a second time on the wavelength button brings out the wavelength selector flyout (Figure 11) where up to 4 wavelengths can be stored in memory for convenience.
-
Page 20: Opm-200 Webpage
OPM-200 User Manual OPM-200 WEBPAGE To access the OPM-200 webpage, connect the meter to a network and on any computer or tablet on the same network, open a web browser (recommended: Google Chrome, Microsoft Edge or Firefox) and enter the OPM-200’s IP address as indicated on the Setup page (Figure 12) into the URL bar. -
Page 21: Dashboard
The Dashboard tab shows the unit part number, serial number, and date of manufacturing. Additionally, the calibration or test report PDF is stored on the unit and can be downloaded to the PC. Enter the OPM-200’s IP address here Figure 13: OPM-200 webpage – Dashboard... -
Page 22: Upgrade
The Upgrade tab shows the current OPM-200 firmware as well as each connected power meter’s firmware version (Figure 14). The power meter firmware is stored in the OPM-200 and can be updated without any additional files. The OPM-200 firmware requires a new .up file that is provided by Santec. -
Page 23: Network
OPM-200 User Manual Network You can view, edit, or reset the network settings of the OPM-200 from the Network tab (Figure Figure 15: OPM-200 webpage – Network... -
Page 24: About
About The About tab (Figure 16) displays the unit’s firmware version, model, and serial number. Advanced mode is reserved for Santec technicians and Santec-approved service centers. Any unauthorized use will void the unit’s warranty. Figure 16: OPM-200 webpage – About... -
Page 25: Programming Guide
Connect the OPM-200 to the network via an Ethernet cable • Swipe on the front panel touchscreen to the Setup page to view the OPM-200’s IP address The TCP/IP libraries provided by most operating systems are sufficient. Santec can provide a communications library upon request. -
Page 26: Notes
1. Some commands can take several seconds to return. The Read timeout should be increased to at least 5000ms using visa.TimeoutMilliseconds 2. The OPM-200 runs SCPI commands synchronously. An *OPC? command can be sent and a 1 will be returned when all operations have been completed: Query("LAS:ENAB "... - Page 27 :STATus:QUEStionable[:EVENt]? :STATus:PRESet :SYSTem:ERRor[:NEXT]? :SYSTem:VERSion? :SYSTem:COMMunicate:LAN:ADDRess “ip/dhcp” Table 7: OPM-200 commands list Returns a comma separated list of all modules present in the unit. List is always :MODule:CATalog? returned in order. I.e first item is module 1, last item is module n Return details about module “#”.
- Page 28 OPM-200 User Manual Do the dark reading for module n and store :SENSe#:DARK as user dark. Set STAT:OPER:COND bit when darking is ongoing. Alias: ZERO Do dark reading for all modules and set the toggle on GUI Setup screen and store as :SENSe:DARK:ALL user darks.
- Page 29 OPM-200 User Manual Set resolution <1|2|3> where 1: 0.1 2: :SENSe#:RESolution # 0.01 3: 0.001 :SENSe#:RESolution? Return current resolution Return current trigger type. 0:Rising 1: :SENSe#:TRIGger:INput:EDGE? Falling 0: trigger on the high edge of the BNC TTL input (rising edge), 1: trigger on the low edge...
-
Page 30: Maintenance
OPM-200 User Manual MAINTENANCE Cleaning the Unit 1. Unplug the unit from the line power. 2. Clean the enclosure with a damp cloth. 3. Do not plug the unit back in until it is completely dry. Cleaning the Detector Glass Remove the detector adapter and inspect the detector glass for any contamination or damage. -
Page 31: Storage And Shipping
As indicated above, please ship the returned material in the original shipping box and packing material. If these are not available, follow the guidelines below: 1. Contact Santec to obtain an RMA number. 2. Cover the front panel with foam to prevent damage. -
Page 32: Specifications
OPM-200 User Manual SPECIFICATIONS Table 8: OPM-200 optical and electrical specifications sheet Parameter Specification Detector Type 2mm InGaAs Integrating sphere (InGaAs) Wavelength Range (nm) 840 to 1700 Power Range (dBm) 8 to -80 30 to -50 ± 3.7% (840 to 1200 nm) - Page 33 OPM-200 User Manual Table 9: OPM-200 mechanical and environmental specifications sheet Parameter Specification Unit Dimension W x H x D (cm) OPM-200 23.5 x 12 x 32.5 RD-IN2-OPM-200 8.5 x 5 x 13.3 RD-INS-OPM-200 6.8 x 8.5 x 13.3 Remote-head Mounting Hole Thread Size Shipping Box Dimensions W x H x D (cm) 36.5 x 39 x 53...
- Page 34 Santec Photonics Laboratories. Our telephone number and facsimile number are shown below. However, we are not responsible for any trouble arising from your own repair or modification on this product.
