Air Curtain
Owner's Manual
Models:
CED & CED-E | RBT | ETD & ETD-E ETA &
ETA-E | ECE & ECE-E | FAC & CAC
IMPORTANT!
IMPORTANT!
1.
CHECK FOR DAMAGE: When you receive your air cur-
CHECK FOR DAMAGE: When you receive your air cur-
tain, immediately check for visible or concealed damage.
tain, immediately check for visible or concealed damage.
Claims should be made immediately to the transporta-
Claims should be made immediately to the transporta-
tion company. Powered Aire will not be liable for damage
tion company. Powered Aire will not be liable for damage
claims submitted late.
claims submitted late.
2.
LOCATE AND RETAIN THE SERIAL NUMBER: The unit's
LOCATE AND RETAIN THE SERIAL NUMBER: The unit's
serial number is necessary to request technical support,
serial number is necessary to request technical support,
order replacement parts or to acquire a wiring diagram.
order replacement parts or to acquire a wiring diagram.
The serial number is located on a silver sticker located on
The serial number is located on a silver sticker located on
the right side end cap when facing the front of the air cur-
the right side end cap when facing the front of the air cur-
tain.
tain.
For PARTS, TECHNICAL SUPPORT or INFORMATION
For PARTS, TECHNICAL SUPPORT or INFORMATION
call: 1-888-321-2473
call: 1-888-321-2473
1
Trained and experienced mechanic/electrician
required for installation.
Powered Aire will not be responsible for misplaced
Powered Aire will not be responsible for misplaced
switches.
switches.
Please review the following instructions for unpacking your air curtain
and preparing it for installation.
1.
Remove shrink-wrap and remove wood slats from
top and sides of crate.
Using a Phillips head screwdriver, unscrew the truss
2.
head screws that hold intake screen in place. Set
aside screen and screws for later use. Remove filter
(if supplied).
The air curtain is lagged to the bottom of the crate
3.
frame. Use a 3/8" socket with extension and remove
the 4 lag screws (one in each corner) that attach the
air curtain to the skid. Unit is now ready for installation.
Lag screw holes are used to bolt the air curtain to the
wall. (Caution - Do NOT grasp by blower wheels. They
will bend and throw wheels out of balance, affecting
safety and performance of air curtain).
Replace the intake screen and filter (if provided) when installation is
4.
complete.
Location of Remote Switches
If remote switches are supplied with the air curtain they are shipped in
one of the following locations:
Inside the junction
In a box inside
box.
the unit.
Inside the Control Panel
enclosure (if supplied).
2
