- Page 1 ™ DJET1000 Kit Air-Fuel Ratio Combustion Monitor Instruction Manual 10/03 Part Number 1000A-23...
- Page 2 ECM: ENGINE CONTROL AND MONITORING. Information and specifications subject to change without notice. DJET1000 is a trademark of ECM: Engine Control and Monitoring. Dynojet is a trademark of Dynojet Research, Inc. Printed in the United States of America.
-
Page 3: Table Of Contents
DJET1000 Kit Components List Important Operation Notes Installing the DJET1000 Kit Connecting the DJET1000 to an ECM AFRecorder Connecting the DJET1000 to an ECM Lambda Pro Connecting the DJET1000 to an ECM G100 Gauge Using the DJET1000 Kit Application Notes... -
Page 5: Introduction
Dynojet™ stack system. AFR can be displayed and graphed by the Dynojet software along with RPM and horsepower. The DJET1000 kit comes with a tailpipe probe; however, the AFR sensor can be removed from the probe and mounted into a 18mm x 1.5mm boss in the engine’s exhaust. The DJET1000 adapter module can also accept AFR information from other ECM products such as: AFRecorder, Lambda Pro, and a G100 gauge. -
Page 6: Important Operation Notes
Important Operation Notes 1. Before installing the AFR sensor, apply a small amount of non-lead containing antiseize compound to its threads. Do not get the compound on the sensor’s tip. 2. Do not operate an engine with the tailpipe probe or AFR sensor in the exhaust for more than three minutes without the AFM1000 control module powering the sensor. -
Page 7: Installing The Djet1000 Kit
2. Remove the Dynojet Air Fuel Ratio module if one is installed on the stack. You cannot use the Dynojet Air Fuel Ratio module and the DJET1000 Kit at the same time. 3. On the bottom of the DJET1000 adapter module is a label and access to a rotary switch. - Page 8 4. Plug the DJET1000 adapter module into the top of the stack. Make sure the pins in the connector engage properly and push it in straight. DJET1000 adapter module mating connectors 5. Plug the wiring harness into the AFM1000 control module. Make sure the pins in the connector engage properly and push it in straight.
- Page 9 adapter. Note that the DJET1000 provides an additional 12 VDC power socket. Do not plug the black plug into that socket, plug it into the one on the stack. Plug the power connector back into the Dynojet CPU module. POWER socket Additional 12 VDC AFR IN power socket...
- Page 10 10. Assemble the tailpipe probe. You will need to get the proper fitting to match the one on your compressed air hose. The below pictures show important details of the assembly process. Install probe tip to main body and tighten firmly Install fitting that matches your hose (customer supplied)
- Page 11 AFR sensor. The air should be on when measuring AFR from the tailpipe but should not be on when calibrating the AFM1000. Close the On/Off valve when the probe is not being used. You are now ready to use your DJET1000 kit. On/Off 20 psig...
-
Page 12: Connecting The Djet1000 To An Ecm Afrecorder
AFRecorder to the “AFR IN” BNC connector on the front of the DJET1000 adapter module. Connecting the DJET1000 to an ECM Lambda Pro The DJET1000 adapter module will accept the analog output from any Lambda Pro. Turn off the power to the Dynojet CPU module and remove the power connector. -
Page 13: Using The Djet1000 Kit
Using the DJET1000 Kit 1. Start the engine in the vehicle to be tested and run it until no visible water vapor or liquid water is coming out of the exhaust. This is to minimize the chance of liquid water striking and thermally shocking the AFR sensor. - Page 14 This purges the trapped air. After the purge cycle is complete, make a second dyno run to collect accurate AFR data. If the trapped air is not purged, leaner than actual AFR readings will be read. 7 After the dyno run, re move the probe from the exhaust and close the tailpipe probe's On/Off valve and remove the probe from the exhaust.
-
Page 15: Application Notes
Application Notes 1. The biggest killer of AFR sensors is liquid water in the exhaust. Liquid water strikes the hot sensor and causes it to crack. Before any dyno run, make sure that the exhaust system is well heated and that liquid water cannot be seen coming out of the tailpipe. 2. -
Page 16: Troubleshooting
Troubleshooting If the AFM1000 has been calibrated, its red light off and green light on, the probe at least 18” up the exhaust pipe, the tailpipe probe's pressure at 20±3 psig and ejecting exhaust, and the exhaust system has been purged, the AFR measured will be accurate. If the AFM1000’s red light is on or flashing, refer to the AFM1000’s Instruction Manual. -
Page 17: Safety Warnings
Always wear eye protection when working near engines, vehicles, or machinery. When installing the DJET1000 kit, it is best to think-out your moves before you make them. Route and cable-tie all cables away from hot, moving, sharp, high energy (spark), caustic objects, and where people walk. -
Page 18: Warranty And Disclaimers
Warranty and Disclaimers WARRANTY The products described in this manual, with the exception of the UEGO sensor, are warranted to be free from defects in material and workmanship for a period of one year from the date of shipment to the buyer. Within the one year warranty period, we shall at our option replace such items or reimburse the customer the original price of such items which are returned to us with shipping charges prepaid and which are determined by us to be defective.
