PRODUCT SPECIFICATION (RAW 40 FB4 (IP65))

Product Name:
Type Of Laser:
Guaranteed Optical Output:
Suitable For:
Control Signal:
Scanning System:
Scan Angle:
Safety:
Weight:
Package Includes:
R | G | B [mW]:
Beam Size [mm]:
Beam Divergence:
Modulation:
Power Requirements:
Consumption:
Operation Temperature:
Ingress Rating:
System Features:
Laser Safety Features:
Notice:
Dimensions [mm]:
Unity RAW 40 FB4 (IP65)
Full-color, Semiconductor diode laser system
>4t0W
Stadium sized venues (over 30,000 people), large outdoor shows. Beam
show, text, graphic, and mapping capable
Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA | PC, Lighting
Console, Auto Mode, Mobile App: Apple, Android]
40,000 points per second @ 8°
50°
Fully complies with the latest EN 60825-1 and FDA regulations
30kg
Laser projector w/ FB4 DMX, IP65 housing, heavy duty flight case,
Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power
cable (3M/9ft), interlock, keys, manual, quickstart guide, variance card (*
service dongle if outside US)
10,000 | 13,000 | 17,000
6.5 x 6.7
<1.1mrad [Full Angle]
Analog, up to 100kHz
100-230V/50Hz
Max. 900W
(-10 °C )-45 °C
IP65
All the adjustments, such as power output of each color, X & Y axes
invert, X & Y size and position, safety, etc., are managed digitally by the
FB4 control system. Ethernet in, power in/out, DMX in/out, Estop in/out,
ILDA in.
Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety,
Mechanical shutter, Adjustable aperture masking plate
*Due to Advanced Optical Correction technology used in our laser
systems, each laser colour's optical power output may slightly differ from
the specification of the respective laser module(s) installed. This does
not affect the total guaranteed power output
Depth: 468
Width: 308
Height: 218
