Installation Guide
SmartRack
Mounting Bracket for
®
2- and 4-Post Open Frame Racks
Adds keyhole slots and threaded holes for mounting vertical PDUs and cable management accessories
to any Tripp Lite 2-post, 4-post, standard or heavy-duty rack. Holds up to 3 vertical PDUs.
Package Includes
Mounting Brackets
Adapter Plates
M6 Screws
Cage Nuts
8-32 Flange Nuts
(x2)
for Open Frame Racks
(x4)
(x4)
(x4)
(x2)
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Tripp Lite SmartRack SRPDU4PHDBRKT
Summary of Contents for Tripp Lite SmartRack SRPDU4PHDBRKT
- Page 1 2- and 4-Post Open Frame Racks Adds keyhole slots and threaded holes for mounting vertical PDUs and cable management accessories to any Tripp Lite 2-post, 4-post, standard or heavy-duty rack. Holds up to 3 vertical PDUs. Package Includes Mounting Brackets...
- Page 2 For Use with 2-Post and For Use with Standard or 4-Post Open Frame Racks Heavy-Duty Rack Enclosures Attach a mounting bracket to an adapter plate using two Attach one mounting bracket directly into holes in the 8-32 flange nuts. rack frame using two M6 screws and two cage nuts. Mount one bracket and adapter plate assembly into pre- Repeat with the second bracket and adapter plate threaded holes near the top of the rack frame using two...
