Tripp Lite SRWALLBRKT Series Installation Manual

SRWALLBRKT Vertical Wall Bracket
SRWALLBRKT2U
175 lb. (80 kg) Max

Contents

M6 Screw x12
Installation
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE
MAY OCCUR!
1
Mount the bracket to a wall. Choose appropriate hardware
according to the weight load and mounting surface.
• Installers are responsible to provide hardware.
• Installers must verify the supporting surface will safely support
the combined load of the equipment and all attached hardware
and components.
• If mounting to wood studs, make sure
mounting screws are anchored
into the center of the studs.
Use of a stud finder is
highly recommended.
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
Installation Guide
Español 2 • Français 3
175 lb. (80 kg) Max
M6 Cage Nut x12
"
1 6
m ]
6 m
[ 4 0
2U bracket panel shown.
"
1 6
m ]
All brackets install the same,
6 m
[ 4 0
regardless of size.
SRWALLBRKT4U
2
Attach and secure equipment to the top
horizontal rails using four M6 Screws, Cup
Washers and Cage Nuts. Repeat for each
additional unit.
