Operating and Installation
Instructions
Gas cooktop
It is essential to read the operating and installation instructions be-
fore setup, installation, and commissioning. This prevents both per-
sonal injury and damage to the appliance.
en-US
M.-Nr. 11 880 120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM 3054-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Miele KM 3054-1

Summary of Contents for Miele KM 3054-1

  • Page 1 Operating and Installation Instructions Gas cooktop It is essential to read the operating and installation instructions be- fore setup, installation, and commissioning. This prevents both per- sonal injury and damage to the appliance. en-US M.-Nr. 11 880 120...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS  WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death. - Do not use or store gasoline or other combustible liquids or vapors in the vicinity of this or any other appliance.

  • Page 3: Table Of Contents

    Contents IMPORTANT SAFETY INSTRUCTIONS ............IMPORTANT SAFETY INSTRUCTIONS ............Caring for the environment ................15 Overview......................16 Cooktop....................... 16 KM 3054-1...................... 16 Control knobs...................... 17 Burner........................19 Kitchen timer control elements/indicators............20 Included accessories................... 21 Before first use ....................22 Cleaning the cooktop for the first time..............22 Turning on the cooktop for the first time .............
  • Page 4 Contents Customer Service....................42 Contact in the event of a fault ................42 Appliance warranty and product registration ............42 Installation......................43 IMPORTANT SAFETY INSTRUCTIONS - INSTALLATION ........43 Safety distances....................45 Installation notes ....................46 Installation dimensions..................47 KM 3054-1...................... 47 Installation ......................

  • Page 5: Important Safety Instructions

    “Installation”, as well as in the “IMPORTANT SAFETY INSTRUCTIONS”. Miele cannot be held liable for injury or damage caused by non- compliance with these instructions. Keep these instructions in a safe place and pass them on to any future owner.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS Safety with children  Do not leave children unattended: Children should not be alone or unsupervised in the area where the appliance is installed. Do not al- low them to sit or stand on the appliance.  Be sure to supervise any children in the vicinity of the cooktop, and do not let them play with it.
  • Page 7 Unauthorized installation, maintenance, and repairs can cause considerable danger for the user. Installation, maintenance, and re- pairs must only be carried out by a Miele authorized technician.  Maintenance by the user: Never repair or replace any part of the appliance unless the instructions specifically recommend doing so.
  • Page 8 Do not open the casing of the cooktop under any circumstances.  Any repairs not performed by a Miele authorized service techni- cian will void the warranty.  Defective components should be replaced by Miele original parts only.
  • Page 9 Switch it off immediately. Disconnect it from the electricity and gas supply. Contact Miele Service.  If the cooktop is installed behind a cabinet door, do not close the door while the cooktop is in operation.
  • Page 10 IMPORTANT SAFETY INSTRUCTIONS Correct use  The cooktop gets hot when in use and remains hot for a while af- ter being turned off. There is a potential hazard until the residual heat indicator goes out.  WARNING NEVER use this cooktop as a space heater to heat or warm the room.
  • Page 11 IMPORTANT SAFETY INSTRUCTIONS  If the cooktop is covered, there is a risk that the material of the cover will ignite, explode or melt if the cooktop is still hot or if turned on inadvertently. Never cover the cooktop with a board, cloth or pro- tective sheet.
  • Page 12 IMPORTANT SAFETY INSTRUCTIONS  If the cookware is too small, it will not sit properly on the burner grate. If the cookware is too large, heat emitted from the bottom of the cookware may damage the countertop, walls with poor heat-re- sistance (e.g.
  • Page 13 IMPORTANT SAFETY INSTRUCTIONS  Ensure that the igniters are clean and dry to allow the burners to ignite and burn properly.  Fire hazard! Loose-fitting or hanging garments can catch fire. Be sure to wear appropriately fitting clothing when cooking. Never allow loose clothing or flammable materials to come into contact with the burners while the burners are in use.
  • Page 14 The steam may reach electrical components and cause a short cir- cuit.  Miele will guarantee to supply functional parts for a minimum of 10 years and up to 15 years following the discontinuation of your cooktop. SAVE THESE INSTRUCTIONS AND REVIEW THEM PERIODICALLY...

  • Page 15: Caring For The Environment

    Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed.

  • Page 16: Overview

    Overview Cooktop KM 3054-1 8.8. a Wok burner b Power burner c Economy burner d Normal burner e Normal burner f Grates g Symbols for allocation of knobs h In-operation/residual heat indicator i Kitchen timer control elements/indicators j Delete kitchen timer durations k Knobs for burners...

  • Page 17: Control Knobs

    Overview Control knobs Wok burner a  Burner off The gas supply is turned off b  Strongest flame The outer and inner burners are on the highest setting c  Strong flame The outer burner is on the lowest setting, the inner burner on the highest setting d  Weak flame The outer burner is off, the inner burner is on the highest setting e  Weakest flame...
  • Page 18 Overview Economy, normal, and power burners a  Burner off The gas supply is turned off b  Strong flame The burner is on the highest setting c  Weak flame The burner is on the lowest setting...

  • Page 19: Burner

    Overview Economy, normal, and power burners Burner Wok burner a Burner cap b Burner head c Burner base d Thermocouple a Outer burner cap e Ignitor b Inner burner cap c Burner head d Burner base e Thermocouple f Ignitor...

  • Page 20: Kitchen Timer Control Elements/Indicators

    Overview Kitchen timer control elements/indicators Sensor controls a Activate system lock/set the time b Kitchen timer - On/Off - Switch between timer functions - Select a burner Displays/Indicator lights c Timer indicator d Burner timer indicator A timer has been set for the burner e Time display  to ...

  • Page 21: Included Accessories

    Overview Included accessories The accessories supplied with your ap- pliance, as well as a range of optional ones, are available to order from Miele (see “Optional accessories”). Wok ring The Wok ring supplied with your appli- ance can be used in instances where extra stability is required.

  • Page 22: Before First Use

    Before first use Cleaning the cooktop for the Turning on the cooktop for the first time first time  Before first use, wipe down the appli- The metal components have a protec- ance with a damp cloth and dry it. tive coating.

  • Page 23: Cookware

    Cookware - Select cookware that fits the size of the burner: Large diameter = large burner Small diameter = small burner - A wok burner is particularly suitable for wok pans. Do not allow the base - Do not use cookware with bases with of the wok pan to come into contact pronounced edges.
  • Page 24 Cookware Combi-trivet Wok ring  Use the wok ring supplied to give ad- Use the combi-trivet supplied for small items of cookware. The cookware will ditional stability to cookware, espe- then be stable on the burner and not tip cially to woks with a rounded base. over.

  • Page 25: Energy Saving Tips

    Energy saving tips - Whenever possible, keep pots and pans covered while cooking. Doing so will prevent unnecessary heat loss. - Wide, shallow cookware heats up faster and is therefore preferable to tall, narrow cookware. - Cook with as little water as possible. - Reduce the power setting once the water has come to a boil or the oil/fat is hot enough for frying.

  • Page 26: Operation

    Operation Turning the appliance on  Fire hazard due to overheated food.  Press the knob lightly and turn it Unattended food can overheat and counterclockwise to the large flame ignite. symbol. Do not leave the cooktop unattended  Then press it down firmly to open the while it is being used.

  • Page 27: Adjusting The Flame

    Operation Switching on during a power outage Wok burner In case of a power outage, the flame Depending on the knob design, there can be ignited manually. may be a stopper at the 6 o’clock posi- tion to prevent you turning the knob to ...

  • Page 28: Switching Off

    Operation Switching off In-operation/residual-heat indi- cators  Turn the knob clockwise to  burner off. The in-operation/residual heat indicator lights up when a burner is ignited. They This stops the flow of gas and the flame go out when the cooktop is switched goes out.

  • Page 29: Kitchen Timer

    Kitchen timer Timer A duration of between 1 minute () and 6 hours (.) can be set. Setting Use the - sensor to reduce the time  Touch the  sensor button. from . to , and the + sensor to in-  and the indicator light for the timer crease the time from ...

  • Page 30: Setting The Timer For A Burner

    Kitchen timer Setting the timer for a burner System lock, kitchen timer A timer can be allocated for any burner The system lock cannot be activated if that is switched on. This function can a timer duration has been set. The sys- be used on all burners at the same tem lock can be used to prevent a timer time.

  • Page 31: Safety Features

    Safety features Ignition safety The cooktop is equipped with an igni- tion safety device. If a gas flame is ex- tinguished (e.g., by food boiling over or by a draft) and re-ignition does not work, the gas supply is switched off. This prevents the release of gas.

  • Page 32: Cleaning And Care

    Cleaning and care Unsuitable cleaning agents  Danger of burning due to hot surfaces. To avoid damaging the surfaces of the The cooktop surface, grates, and appliance, do not use: burners will be hot after use. - cleaning agents containing soda, al- Allow the cooktop to cool down be- kalines, ammonia, acids, or chlorides, fore cleaning it.

  • Page 33: Cleaning The Ceramic Surface

     Soften any stubborn soiling before-  Stains caused by limescale or water hand. can be removed using Miele’s ce-  Dry the cooktop after using water to ramic and stainless steel cooktop clean it. This helps prevent lime de- cleaner.

  • Page 34: Cleaning The Grates

    Cleaning and care Cleaning the grates Cleaning the knobs  Remove the grates. The knobs are not dishwasher-safe. The knobs should only be cleaned by  Clean the grates in a dishwasher or hand. with a solution of warm water and a little liquid dish soap applied with a soft sponge.

  • Page 35: Cleaning The Burner

    Cleaning and care Cleaning the burner Do not clean any parts of the burner in a dishwasher. The surface of the burner cap will be- come more matte with time. This is quite normal and does not indicate damage to the burner cap. ...

  • Page 36: Assembling The Burner

    Cleaning and care Assembling the wok burner Assembling the burner Assembling the economy, normal, and power burners  Place the burner head  onto the  Place the burner head  onto the burner base  so that the thermo- burner base  so that the thermo- couple ...
  • Page 37 Cleaning and care Checking burning properties  Ignite all burners to check that they are operating correctly: - The flame must not go out on the lowest setting, or when the knob is turned quickly from the highest to the lowest setting.

  • Page 38: Frequently Asked Questions

    You can save time and money in many cases, as you do not need to contact Miele Customer Service. Information to help you rectify faults yourself can be found at www.miele.com/ser- vice. The following tables are designed to help you to find the cause of a malfunction or a fault and to resolve it.
  • Page 39 Take any cookware off the cooktop and wipe away any food deposits.  Disconnect the power supply to the cooktop for approx. 1 minute.  If the problem persists after the power supply has been restored, please contact Miele Service.
  • Page 40 Frequently asked questions Problem Possible cause and solution The in-operation/resid- Overheating protection has been triggered. ual heat indicators flash  Turn all knobs clockwise to the “” position. You and  appears in the can operate the burners again once  has disap- kitchen timer display.

  • Page 41: Optional Accessories

    Optional accessories Miele offers a range of useful acces- Ceramic and stainless steel sories, as well as cleaning and condi- cleaner 250 mL tioning products for your appliance. Removes heavy soiling, lime scale, and These products can be easily ordered aluminum residue.

  • Page 42: Customer Service

    Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. Please quote the model identifier and serial number of your appliance (SN) when contacting Miele Customer Service.

  • Page 43: Installation

    *INSTALLATION* Installation IMPORTANT SAFETY INSTRUCTIONS - INSTALLATION  Risk of damage caused by incorrect installation. Incorrect installation can damage the cooktop. The cooktop must only be installed by a qualified specialist.  Damage from falling objects. Take care not to damage the cooktop when installing cabinetry or a ventilation hood above it.
  • Page 44 *INSTALLATION* Installation  An air curtain or other overhead range hood, which operates by blowing a downward airflow onto a cooktop, shall not be used in conjunction with the cooktop unless the hood and cooktop have been designed and tested in accordance with the Standard for Do- mestic Gas Ranges, ANSIZ21.1•CSA1.1, and listed by an indepen- dent testing laboratory for combination use.

  • Page 45: Safety Distances

    *INSTALLATION* Installation Safety distances Position Dimensions Description  13" (330 mm) Maximum depth of wall cabinet  2" (50 mm) Minimum distance to back wall  18" (457 mm) Minimum safety distance to bottom edge of adjacent wall cabinet  ≥ cooktop width See “Installation – Installation dimensions”...

  • Page 46: Installation Notes

    *INSTALLATION* Installation Tiled countertop Installation notes Seal between cooktop and counter- Grout lines  and the shaded area un- der the cooktop frame must be smooth and even. If they are not, the cooktop will not sit flush with the countertop and the sealing strip underneath the cook- ...

  • Page 47: Installation Dimensions

    *INSTALLATION* Installation Installation dimensions All dimensions in this instruction booklet are given in mm and inches. KM 3054-1 1 / 4 " 2 0 1 1 / 1 6 " ( 7 m / 1 6 " 1 1 3 ( 5 2 6 m ( 4 6 ß...

  • Page 48: Installation

    *INSTALLATION* Installation Installing the cooktop Installation  Attach the sealing strip provided un- Preparing the countertop derneath the edge of the cooktop.  Create the countertop cut-out. Re-  Feed the cooktop power cord down member to maintain the minimum through the countertop cut-out.
  • Page 49 *INSTALLATION* Installation Securing the cooktop Checking for proper function  After installing the appliance, ignite all burners to check that they are operat- ing correctly: - The flame must not go out on the lowest setting, or when the knob is turned quickly from the highest to the lowest setting.

  • Page 50: Gas Connection

    *INSTALLATION* Installation Gas connection The gas hose and power cord could be damaged by hot spots on the ap-  Connection to the gas supply pliance. may only be performed by a duly au- Make sure that the gas hose and thorized technician.
  • Page 51 If the appliance is not equipped with the United States or the current Natural correct connection for the gas type in Gas and Propane Installation Code, your household, contact your Miele CSA B149.l. for Canada. dealer. After conversion to a different type of...
  • Page 52 Gas leak due to unsuitable regulator. Only use the regulator supplied by Miele. If you are in any doubt, contact Miele Customer Service. Leakage test Leak testing of the appliance shall be conducted according to the manu- facturer's instructions.

  • Page 53: Burner Ratings

    *INSTALLATION* Installation Burner ratings Nominal ratings Burner Gas type BTU/hr Economy burner Natural gas 1.11 3,750 Liquid propane 0.97 3,300 Normal burner Natural gas 1.70 5,800 Liquid propane 1.88 6,400 Power burner Natural gas 2.73 9,300 Liquid propane 2.87 9,800 Natural gas 4.84 16,500...

  • Page 54: Electrical Connection

    Canadian Electric Code, CSA Work by unqualified persons can C22.1-02. in Canada. cause considerable danger to users. Miele cannot be held liable for any damage arising as a result of such work. Installation, repair and maintenance work should only be performed by a Miele authorized service technician.
  • Page 55 *INSTALLATION* Installation Power cord and plug The appliance is equipped with a flexi- ble power cord and a 3-prong ground- ing plug for your protection against shock hazard. The plug must be in- serted into a properly grounded outlet.  Do not cut or remove the grounding prong from this plug.
  • Page 59 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters 9 Independence Way Headquarters and Miele Centre Princeton, NJ 08540 161 Four Valley Drive www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
  • Page 60 KM 3054-1 en-US M.-Nr. 11 880 120 / 01...
