O PERATING INSTURCTION
RYZE-BLK
A BACKREST TILT ADJUSTMENT
B SEAT HEIGHT ADJUSTMENT C ARMREST ADJUSTMENT
A BACKRESTT TILT ADJUSTMENT
While seated, Pull out the single control
lever then the backrest can be tilted
slightly. While pushing in the single
control lever the backrest can be
locked in the original position. The tilt
angle is approximately 23°.
B SEAT HEIGHT ADJUSTMENT
While seated, pull the single control
lever upward and hold it while raising
or lowering the seat to reach your
desired seat height. When the lever is
released to its original position, the
seat height is locked. The seat height
adjustment range is approximately
3.74".
C ARMREST ADJUSTMENT
Armrest can be flipped upwards.
