H-7587, H-7588
π
STACKABLE CUBE
LOCKERS
TOOLS NEEDED
3/8" Wrench (included)
Phillips Screwdriver (included)
CAUTION! Some parts may have sharp edges.
Take care when handling to avoid injury. For your
safety, wear work gloves when assembling.
PAGE 1 OF 9
1-800-295-5510
uline.com
PARTS
1
2
7
9
8
6
5
#
DESCRIPTION
1
Back Panel
2
Side Panel
3
Top/Bottom Panel
4
Door Frame Assembly
5
Nut
6
Bolt
7
Bracket
8
Washer for Bracket
9
Phillips Head Bolt for Bracket
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
3
4
3
QTY.
1
2
2
1
26
26
2
4
4
0224 IH-7587
