Product: WiFi+Bluetooth 5.2 System on Module
Manufacturer: TechNexion Ltd.
Manufacturer Address: 16F-5, No. 736, Zhongzheng Road, ZhongHe
District, 23511, New Taipei City, Taiwan
Model: PIXI-IW416
For Original Equipment Manufacturer integration only – this device
cannot be sold to the general public
FCC ID :2AKZA-IW416
IC:22364-IW416
1
Advertisement
Related Manuals for TechNexion PIXI-IW416
Summary of Contents for TechNexion PIXI-IW416
- Page 1 User Manual Product: WiFi+Bluetooth 5.2 System on Module Manufacturer: TechNexion Ltd. Manufacturer Address: 16F-5, No. 736, Zhongzheng Road, ZhongHe District, 23511, New Taipei City, Taiwan Model: PIXI-IW416 For Original Equipment Manufacturer integration only – this device cannot be sold to the general public...
- Page 2 General Specifications Form Factor PIXI 16mm x 12mm x 1.0mm Wireless SIP Module NXP IW416 WLAN IEEE 802.11 a/b/g/n Bluetooth Bluetooth 5.2 BDR/EDR/BLE Bluetooth: 2042MHz ~ 2480MHz 802.11b/g/n HT20: 2412MHz ~ 2472MHz Frequency 802.11n HT40: 2422MHz ~ 2462MHz Range 802.11a : 5180MHz ~ 5825MHz 802.11n HT20: 5180MHz ~ 5825MHz 802.11n HT40: 5190MHz ~ 5795MHz 1x MHF4 connector...
- Page 3 User Manual with Statement required FCC Statement: FCC 15.119: This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation.
-
Page 4: Important Note
Modular Approval OEM INTEGRATION INSTRUCTIONS: This device is intended only for OEM integrators under the following conditions: 1) The module must be installed in the host equipment such that 20 cm is maintained between the antenna and users, and 2) the transmitter module may not be co-located with any other transmitter or antenna. - Page 5 IC Statement: RSS-Gen Issue 4 8.4 This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
- Page 6 RSS-247 6.4(5) WLAN 11a (i)the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential forharmful interference to co-channelmobile satellite systems;(iii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band5725-5850 MHz shall be such that theequipment still complies with the e.i.r.p.
- Page 7 IC Radiation Exposure Statement: mobile device This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Cet équipement est conforme aux limites d'exposition aux rayonnements IC RSS-102 établies pour un environnement non contrôlé.
- Page 8 "Contient le module émetteur IC : IC:22364-IW416 CAN ICES-003 (B) / NMB-003 (B) Hereby, TechNexion declares that the radio equipment type PIXI-IW416 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.technexion.com/products/connectivity/pixi-iw416/...
