Konica Minolta AccurioShine 101 Operation Manual

Konica Minolta AccurioShine 101 Operation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
1
2
How to Laminate
3
How to Coat
4
5
6
7
AccurioShine 101
OPERATION  MANUAL
Operation Manual
Ver. 20190930

Advertisement

loading
Need help?

Need help?

Do you have a question about the AccurioShine 101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konica Minolta AccurioShine 101

Summary of Contents for Konica Minolta AccurioShine 101

  • Page 1: Table Of Contents

    OPERATION  MANUAL AccurioShine 101 Before Operation How to Laminate How to Coat Troubleshooting Operation Manual Maintenance Ver. 20190930 Touch Panel Supplement...
  • Page 2 Contents AccurioShine 101 Introduction Introduction Ⅱ Safe and Proper Explanation of Warnings (signal word) Use of Ⅲ Note for Safe Use Equipment Ⅳ 0-3/-4/-5 Other Note / Usage Environment Caution/Warning/Interlock Before 4 types of supplies Paper Type and Size Operation...
  • Page 3 Introduction We sincerely thank you for choosing our coater. Please carefully read this Operation Manual to use this coater properly. Before use, be especially sure to reado Chapter 1:Safe and Proper Use of This Coater. Keep this Operation Manual readily available for reference. Trademark right Machine name and company name are company trademark or registered trademark.
  • Page 4 Safe and Proper Use of Equipment   (Be sure to observe each item) 0-1. Explanation of Warnings (Signal Words) ・ The signal word is a warning indication which shows a message on the basic safe behaviour, ・ "Warning", and "Caution". ・ The warning indications are an important part of safety. If the equipment is mishandled, serious accidents may occur resulting in death or serious injury, or damage to the equipment.
  • Page 5 0-2. Note for Safe Use ● General Notes WARNING ・   Do not modify the equipment, remove components, or attach components not specified by our          company without permission.   There is a possibility of injury, or damage to the equipment. We will not guarantee the quality of       the equipment if any of the above items are performed. ・   Do not remove the safety devices intentionally, or deactivate the functions to use the equipment.      There is a possibility of the human body being exposed to danger, or damage of the equipment       caused by a malfunction.       CAUTION ・   Immediately stop the use of the equipment if smoke comes out of the equipment, or equipment       becomes abnormally hot during operation.   Contact your sales representative after removing the power cable from the outlet. ● Notes regading Electrical Shock WARNING ・   There is a possibility of receiving an electrical shock, if the cover is removed while the power        cable of the equipment is plugged in.   There is a possibility of a major accident occurring from an electrical shock, resulting in death or        serious injury, or damage of the equipment. ・   Do not remove unspecified covers. ・   When connecting an additional ground wire, please request an electrical specialist.  ...
  • Page 6 0-3 ． Power Supply ・ Make sure to use the ground earth cord, and make a ground connection. ・ Range of power supply for stable operation is; 　　AC100V（+6％～ 10％） 　50/60Hz ・ Power cable should be connected to directly to an outlet on the wall. Rated Power: 750W 0-4 ．...

  • Page 7: Before Operation

    AccurioShine 101 Before Operation 1-1: Caution/Warning/Interlock Explanation of Warning/Caution Labels and Interlock locations. * Observe the contents of the Warning label, and perform safe work avoiding accidents. * If the Warning label can not be read or has been removed, contact your sales representative for a new label.
  • Page 8 AccurioShine 101 Before Operation 1-2: 4 types of supplies Laminate Film Dry Coating Detail is “7-2” Detail is “7-1” Possible to see that Rewind side Icon on Icon on transfered area is thinner. Touch Panel Touch Panel Laminate Film Dry Coat Ribbon...
  • Page 9 AccurioShine 101 Before Operation 1-3: Paper Type and Size Max= 320 (330mm) x 660mm Size Min= A4 (Lamuinate) A5 (Dry Coat / Foil) Thickness 110~400gsm (t= 0.12 ～ 0.45mm) 【Loading direction】 Loading Coating side Load as landscape for A4 size as the is face up.
  • Page 10 AccurioShine 101 Before Operation 1-5: Accessories and option Feed Table Multipul Shafts/Paper Core Paper Core Ref. 「1-7」 Re-wind type For used ribbon re-winding. Un-wind type 1set Each 1x Feed End Guide Handle Feed End Guide Long Ref. 「1-7」 （For long sheet）...
  • Page 11 AccurioShine 101 Before Operation 1-6: Set Output Tray Work Main Body Table Ready Work Table Put at left Table corner Installation area is ”width:86cm/ depth:56cm”. Need to use the bigger operation table. Operation Table needs to be very flat and strong for 33kg.
  • Page 12 AccurioShine 101 Before Operation 1-7: Set Feed Table Ready Feed Table and parts Upper Bar Feed Table, End Guide and Handle are Lower Bar attached on this section. Flip up Air Suction Box Flip up the Air Suction Box for easy access.
  • Page 13 AccurioShine 101 Before Operation 1-8: Set Multipul Shafts Set the supply roll on Un-wind shaft and Note set on the machine. Un-wind Set the empty Paper Core on Re-wind Multipul Shaft shaft to re-wind the coated film. Explanation picture doesnʼt have supply roll Multipu Shaft on Un-wind Multipul Shaft.
  • Page 14 AccurioShine 101 Before Operation 1-9: Parts Name and Function Top Cover Heat Roller Paper seration air Separation Rubber Heat Roller Feed the top sheet. Melt the hot melt glue of supply. Air Suction BOX Suck up the top sheet and feed one by one.
  • Page 15 AccurioShine 101 Before Operation 1-10: Power devise Touch Panel Right after Power ON. During reading... Home Screen ℃ When present temp. reached as set temp. Same function with Start icon Manual on touch panel. Start 1st push: Feed Table lifts up and air separation starts.
  • Page 16 AccurioShine 101 Before Operation 1-11: Adjustment of Blower Wing Look inside the machine from the discharge section. There are Blower Fans inside (feeder side) and the Blower Wing is attached on it. Blower Wing Blower Fan Pinch the part like as right figure to adjust the blower volume by angle of Blower Wing.
  • Page 17 AccurioShine 101 Before Operation 1-12: Home Screen Number of Mode select Preset Count Feed adjust processing Temp. adjust ℃ Speed adjust Manual to Service Mode operation Condition ８ 4 types: 1) Laminate, 2) Dry Coat, 3) Spot Gloss and 4) Foil.
  • Page 18 AccurioShine 101 Laminate 2-1: Touch Panel When starting up for the first time, NOTE wait for a few minutes after reaching Right after power on. the set temperature and making a sound before operation. During reading... Power On Plug in a power cord and power on the ℃...
  • Page 19 AccurioShine 101 Laminate 2-2: Touch Panel ℃ Push= Set Feeding Feed Set “Feed Set” screen comes up. Change the “Overlap value” by up-down arrows buttons, and push “Enter” button when set. Then the set value is recorded and Home screen comes up.
  • Page 20 AccurioShine 101 Laminate 2-3: Film Set Multipul Shaft 　　Un-winder THIS SHAPE Multipul Shaft: Un-wind Shaft Unwinder side Multipul Shaft Screw Remove the Unwinder Multipul Shaft from the Tighten as screw machine. direction to fix. Set the ribbon on Un-wind Shaft ①...
  • Page 21 AccurioShine 101 Laminate 2-4: Film Set Film Error Tension Shaft Ready Set Plate Set Plate To push the film through machine to exit. Tension Shaft Insert Set Plate Slack the film and push it between Air Suction BOX and Film Error Tension Shaft by Set Plate.
  • Page 22 AccurioShine 101 Laminate 2-5:Set Papers start Feed Tray at lowest position Turn the Handle and make the Feed Tray at the lowest position for paper loading. Flip up the Air Suction BOX Flip up the Air Suction BOX for smoothly paper loading at the next step.
  • Page 23 AccurioShine 101 Laminate 2-6:Set Papers start Air Suction Flip down the Air Suction BOX 【Note】 Unnecessory to lift down the Feed Tray after flip down the Air Suction BOX at original position. The height adjustment for air suction feeding will be adjusted automatically when push start button.
  • Page 24 AccurioShine 101 Dry/Spot/Foil Coat 3-1:Touch Panel Dry Coat, Spot Gloss and Foil process are similar. The explanation on this chapter is as “Dry Coat” step. Right after power on. Change the rolls, temperature and speed depending on the film type.
  • Page 25 AccurioShine 101 Dry/Spot/Foil Coat 3-2:Touch Panel Push= Clear counter number ℃ “Clear Set” screen comes up. Clear Set Push button, then the number will CLEAR be “0” . Push “Esc” button and Home screen comes up. Note Unnecessary to clear the conter if CLEAR you donʼt use.
  • Page 26 AccurioShine 101 Dry/Spot/Foil Coat 3-3:Film Set Dry Coating, Foiling and Spot Gloss process are all similar. This manual explains as in case of Dry Coating function. Please check the ribbon set, suitable temp. ② and speed for each function. ③...
  • Page 27 AccurioShine 101 Dry/Spot/Foil Coat 3-4:Film Set For Foil For Dry Coat / Spot Gloss Set this parts when operate Set this parts when Set Separation Bar Dry Coat film and operate the foil film There are 2 types of Separation Bar. Need to Spot Gloss film.
  • Page 28 AccurioShine 101 Dry/Spot/Foil Coat 3-5:Film Set Tape Ribbon top on Paper Core Tape the top of ribbon on the Paper Core of Re-wind shaft by scotch tape. Wind the ribbon more than 1 around the Paper Core. Strech Film Re-wind the un-winded film by step.9 to the Un-wind Shaft by hand.
  • Page 29 AccurioShine 101 Dry/Spot/Foil Coat 3-6:Set Papers start Feed Tray at lowest position Turn the Handle and make the Feed Tray at the lowest position for paper loading. Flip up the Air Suction BOX Flip up the Air Suction BOX for smoothly paper loading at the next step.
  • Page 30 AccurioShine 101 Dry/Spot/Foil Coat 3-7:Set Papers start Check the Temperature Home Screen icon on Home screen changed to icon. This shows the heater temp. reaches the set ℃ temp. Please wait until the start button comes up for a while.
  • Page 31 AccurioShine 101 Dry/Spot/Foil Coat 3-8:Hand Feed Foil only one part of the printed paper. Make the masking paper that has hollowed ABCD ABCD out only that part. Double with printed paper and process one by one by hand feed. ABCDEF ABCDEF This section explains this.

  • Page 32: Troubleshooting

    AccurioShine 101 Troubleshooting 4-1:Paper is not fed [Situation] Loaded paper cannot be fed at all even if push the Start button. The error screen (on right picture) shows up. Check the below steps and remove the issues for feeding error. The error screen can be closed when push 「Esc」...
  • Page 33 AccurioShine 101 Troubleshooting 4-2:Miss Feed [Situation] Possible to feed, but the feeding error happens often. Check the below steps and remove the issues for miss feeding error. The error screen can be closed when push 「Esc」 button. Error screen shows up and this circle turns white color.
  • Page 34 AccurioShine 101 Troubleshooting 4-3:Jam Heat Roller around [Situation] Paper cannot pass through the Heat section (between Heat Roller and Platen Roller) correctly. Check the below steps and remove the issues. The error screen can be closed when push 「Esc」 button.
  • Page 35 AccurioShine 101 Troubleshooting 4-4:Cannot Laminate/Coat Do not rotate the Heat Roller [Situation] Cannot laminate and/or coat beautifully. There are 2 Thermistors that sensing temperature on the Quality trouble. Heat Roller. The top of Thermistor is pressed to fix on Heat Roller. Therefore these Thermistors can get damage (break) if the Heat Roller rotates oposite direction.
  • Page 36 AccurioShine 101 Troubleshooting 4-5:Jam Exit Section around Do not rush to remove the papers quickly when [Situation] POINT trouble happens around cutter section. Paper jams around the exit section of the Necessary to observe carefully and find out the machine.

  • Page 37: Maintenance

    AccurioShine 101 Maintenance 5-1:Daily Maintenance Most maintenance is cleaning of the rollers The dirt on Heat Roller is really tough to clean up CAUTION because it is melted and sticked on the Heat Roller and guides that got dust and dirt.
  • Page 38 AccurioShine 101 Maintenance 5-2:Work Guide Set Explain how to attach and remove the Work Guide on this section. Removing the Work Guide makes it easier to reach the roller during maintenance or when the film has stuck to the roller and you want to clean it.

  • Page 39: Touch Panel

    AccurioShine 101 Touch Panel 6-1:Mode Select Home Screen ℃ Mode select (Change to be gray color which you select) Film Type Mode Feature After Before Basic Temp. Type Basic Speed Cover the film on whole Laminate Laminate paper except front side.
  • Page 40 AccurioShine 101 Touch Panel 6-2:Feeding Set ℃ Feed Set screen Feed Set icon nter Enter Overlap value Icon Explanation This icon “Feeding Set screen” comes up when push this icon on Home screen. images Set the overlap value on this setting screen.
  • Page 41 AccurioShine 101 Touch Panel 6-3:Temperature Set The machine changes the temperature and speed to standard value automatically for each opeartions when an operator celects the mode icon. Normally, proceed with original setting. However, please change the temperature on this screen if necessary depending on the paper type and film.
  • Page 42 AccurioShine 101 Touch Panel 6-4:Speed Set The machine changes the temperature and speed to standard value automatically for each opeartions when an operator celects the mode icon. Normally, proceed with original setting. However, please change the speed on this screen if necessary depending on the paper type and film.
  • Page 43 AccurioShine 101 Touch Panel 6-5:Status icon Home screen ℃ Icon Status Explanation This icon is in the condition that the Heat Roller is Heating heating up. Wait until the temperature rises to the set value. The buzzer sounds when the temperature reaches that level, and the below “Start”...
  • Page 44 AccurioShine 101 Touch Panel 6-6:Error/Eco Screen Explanation ③ ② ① ① This mark turns white color when misfeed happens at the Feeder UNIT section. ② This mark turns white color when film runs out or film is cut. ③ Empty for now.

  • Page 45: Supplement

    AccurioShine 101 Supplement 7-1:Laminate info Film flow Re-winder Laminate Feed without gaps Film or with a slight gap Heat Roller icon on screen （about 100~120℃） （Blank space on 3 sides） Paper Paper Platen Roller Paper flow Feature Laminate Film Clear thick film Set the film core on...
  • Page 46 AccurioShine 101 Supplement 7-2:Dry Coat info Film flow Re-winde Un-winde Dry Coat Ribbon Enlarged view Separation Bar Heat Roller Liner Film Heat icon on screen Roller （about 130~150℃) Coating （Cover whole sheet） material Paper Gap between Platen Roller sheets Paper...
  • Page 47 AccurioShine 101 Supplement 7-3: Spot Gloss info フィルムの流れ Film flow Re-wind Un-wind Spot Gloss Film Separation Bar Enlarged view Heat Roller Liner Film icon on screen Heat （Coat only tonner base） （about 110~130℃) Roller Coating material Gap between Paper Platen Roller...
  • Page 48 AccurioShine 101 Supplement 7-4: Foil info Film flow Re-wind Gold, Silver and Un-wind other foil roll Separation Bar Enlarged view icon on screen Heat Roller Liner Film （Bright only tonner base） Heat （about 120~140℃) Roller Coating material Gap between Paper...
  • Page 49 AccurioShine 101 Supplement 7-5: Relation of paper and film Position relation between Dry Coat/Spot Gloss/Foil Film and Paper Put on the Un-wind side Re-wind side channel Multipul Shaft This width is wider than printing image To the hole on machine body...
  • Page 50 AccurioShine 101 Supplement 7-6: Specification Machine/Model Multi Cry Coater / AccurioShine 101 Main Body 1310(W)×580(D)×795(H) ｍｍ （Feed Tray　+　Outuput　Tray Machine size Main Body 420(W)×580(D)×365(H) ｍｍ Main Body: about 32.5Kg 　 Weight Feed Tray　+　Outuput　Tray : about 5.5Kg 　 AC100V ±10% 50/60Hz Rated voltage AC115V AC 110 ～...
  • Page 51 AccurioShine 101 Supplement 7-7: Specification * Max Roll diameter: Genuine Film * Genuine Supply Supplies Dry Coat Ribbon / Spot Gloss Film / Foils Laminate Film (Genuine 30μ) Discharge　Method Discharge Tray IPX0(zero) [Non protected for water: Non use at the place near the water.]...
  • Page 52 Warranty Procuct Name Multi Dry Coater  AccrioShine 101 Model Name Warranty period 6 months after purchase. Installed date           /           /          / Dearler                             TEL:  Warranty Determination Warranty period is 6 months after purchase. However, the troubles that used with sperical materials and/or works and/or supplies are excepted. The followings are charge condition even if in the warranty period. (1) Breakdown and/or damaged attributable disregarding the Operation Manual. (2) Breakdown and/or damaged attributable customized or responsibility of use. (3) Breakdown and/or damaged attributable shipping trouble and falling when moving. (4) Fire, earthquake, natural disaster by wind and flood damage, pollution and abnormal voltage. (5) Wrapping, covers, Feed Table, Output Unit and other accessories. AccrioShine 101 Userʼs Manual Ver. 20191012  ...
