Original Instructions
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Read the instructions carefully. Make sure you understand
the instructions and be familiar with the controls and
the proper use of the appliance. Please understand that
you can reduce the risk by following the instructions and
warnings in this manual, but you cannot eliminate all the
risks.
Lawn Mowing Robot (hereinafter referred to as "GOAT")
has many built-in safety sensors, however, safety risks
still exist.
All related residual risks have been described or informed
in this manual.
Description of intended use: Intelligent lawn mowers are
mainly used in mowing grass, especially in parks, private
villa yards, and football fields.
For machines used in public areas, that warning signs
shall be placed around the working area of the machine.
They shall show the substance of the following text:
WARNING! Automatic lawnmower!
Keep away from the machine! Supervise children!
DO NOT modify the mower by yourself. Modifications
could interfere with mower operations, result in serious
injury and/or damage, or void the Limited Warranty. Use
only Ecovacs approved parts and accessories.
WARNING
Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge or people unfamiliar with these instructions to
use the machine, local regulations may restrict the age of
the operator.
To avoid using the machine and its peripherals in bad
weather conditions especially when there is a risk of
lightning.
Before each mowing session, check that all parts of the
mower can function normally.
Periodically inspect the area where the machine is to be
used and remove all stones, sticks, wires, bones, and
other foreign objects.
NEVER allow children to touch the power supply unit,
charging station, blades, the battery compartment, or any
parts with gaps such as the wheels.
WARNING
Never to operate the machine and/or its peripherals with
3 EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOAT G1-800 and is the answer not in the manual?

Questions and answers

John Hodder
March 4, 2025

My goat is constantly stopping and showing the goat lifted error message

1 comments:
Mr. Anderson
March 4, 2025

The ECOVACS GOAT G1-800 shows the "GOAT lifted" error message and stops frequently because it has been lifted or tilted. To resume mowing, the user must enter the PIN code before restarting the operation.

This answer is automatically generated

angela
March 1, 2025

how to reset as it won't connect

1 comments:
Mr. Anderson
May 14, 2025

To reset the ECOVACS GOAT G1-800 for connection issues, follow these steps:

1. Make sure the Station and Navigation Beacon are in their original positions.
2. Check if the Navigation Beacon has power. If the batteries are low or empty, replace them with new dry cell batteries, ensuring correct polarity.
3. Reconnect the base connector to the pile connector correctly.
4. If the issue continues, contact Customer Service.

These steps help resolve signal and connection problems between the components.

This answer is automatically generated

Summary of Contents for ECOVACS GOAT G1-800

  • Page 1 Original Instructions injury and/or damage, or void the Limited Warranty. Use IMPORTANT only Ecovacs approved parts and accessories. READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE WARNING Read the instructions carefully. Make sure you understand...
  • Page 2 Never allow children to be in the vicinity or play with the the skilled professional to repair or replace the cord. machine when it is operating. Please use the extension cable manufactured by ECOVACS. WARNING If you have any problem, contact Customer Service.
  • Page 3: European Union Compliance Statement

    Instructions to always wear substantial footwear and European Union Compliance long trousers while operating the machine with a Statement manual controller. Information on Disposal for Users of Waste Electrical Additionally when using the manual controller & Electronic Equipment a) Mow only in daylight or in good artificial light. b) Avoid operating the machine in wet grass.
  • Page 4: Radio Equipment Directive

    Information on Disposal for Users of used batteries Restriction of the use of certain hazardous substances (RoHS) Directive Ecovacs Home Service Robotics Co., Ltd. hereby declares the whole product including parts (cables, cords, and so on) meets the requirements of RoHS Directive...
  • Page 5 Directive 2011/65/EU and amendment Commission Delegated Directive (EU) 2015/863, the Radio Equipment Directive 2014/53/EU and the Machinery Directive 2006/42/EC. The declaration of conformity can be viewed at the following address: https://www.ecovacs.com/global/ compliance 7 EN...
  • Page 6 SYMBOLS Class III WARNING— Read instruction manual before Direct current operating the machine. Alternating current WARNING— This product conforms to the applicable EC Directives. Keep a safe distance from the machine when operating. Polarity of the charging port WARNING— Before charging, read the instructions. Do not ride on the machine.
  • Page 7 Sensors Description Name To perceive the environmental information around GOAT, help GOAT to build a map, and assist Panoramic camera in the positioning and navigation of GOAT. Horizontal: 360 degrees; Vertical: 50 degrees To perceive the environmental information in front of GOAT, identify special targets, and AI camera optimize the working performance.
  • Page 8: Regular Maintenance

    Replacement Frequency CLEANING. Blades"1" About 6-8 weeks Dry Cells Replace when App prompts Camera Brush About every 1 year Note: Please utilize only the battery which is the original one or that of the same model as specified by ECOVACS.
  • Page 9: Specific Maintenance

    1. Replace the Blades WARNING Remember to power off GOAT before operation. ALWAYS wear protective gloves when replacing the Blades. Please only use the Blades manufactured by ECOVACS and use new screws when assembling Blades. • Power off GOAT. •...
  • Page 10 2. Replace the Camera Brush • Pull old Camera Brush out from the Station by grabbing the hook on it. • Slide the new Camera Brush along the slot into the Station until you hear a "click". Brush 1 Brush 2...
  • Page 11 3. Replace the Dry Cells in Navigation Beacon • Turn the Beacon counterclockwise until the projection points at “ ” and remove the Beacon from the Navigation-assisted Pole. • Disassemble the Beacon by turning the upper Beacon counterclockwise. • Take out the Dry Cells and replace them with new ones. •...
  • Page 12 4. Clean the Blade Disc, Chassis, Off-road Wheels and Front Wheels WARNING ALWAYS wear protective gloves. DO NOT use the high pressure washer. High pressure water can enter the sealings and damage electronic and mechanical parts. • Power off GOAT. •...
  • Page 13 5. Clean the Other Components Wipe the components with a clean, dry cloth. Avoid using cleaning sprays or detergents. 15 EN...
  • Page 14 6. Check the Navigation Beacon Regularly • If the Navigation Beacon tilt angle exceeds 10°, reinstall the Naviga- • If there are branches and tendrils on the Navigation Beacon which tion Beacon firmly to the ground at the original position. may cause signal interference, please clear them away in time.
  • Page 15 STORAGE OVER THE WINTER TRANSPORTATION It is recommended to use the original package to protect GOAT when GOAT you intend to transport GOAT for a long distance. Remember to power • Power off your GOAT after it is fully charged. off your GOAT before carrying out any transportations and handle it •...
  • Page 16: Function Messages

    FUNCTION MESSAGES This part will tell you the explanation about function messages GOAT displays. Message Meaning MAP CREATING Your GOAT is mapping in the App. MAP LEARNING Your GOAT is learning the map autonomously. MAP EDITING The map is being edited via the App. AUTO MOWING Your GOAT is mowing the whole lawn.
  • Page 17: Fault Messages

    FAULT MESSAGES Smart as GOAT, it will tell you the errors when things go wrong so that you can find the way to fix them. See the table below for the detailed information. Message Cause Action Too simple. Please reset! The PIN code you set is too simple.
  • Page 18 Message Cause Action 1. Clean up the the wheels, the areas around wheels and the Blade Disc. 2. Check if there is water under the Blade Disc. If any, please Cutting system blocked! Your GOAT has a cutting system malfunction. move your GOAT to a dry place.
  • Page 19: Troubleshooting

    TROUBLESHOOTING If there is something wrong with your GOAT when working, you can consult the table below. Please contact our Customer Service if the problems still exist. Issue Cause Solution Make sure that the Base connector is correctly connected to Red Indicator Light on the Station The Base connector is not correctly the Pile connector.
  • Page 20 Issue Cause Solution Wait until its temperature returns to normal. If the problem Battery is too hot or too cold. persists, please contact Customer Service. GOAT stops working and returns to the Station. Battery is low or signal is weak. Wait until the battery is full and signal is strong.
  • Page 21: Technical Data

    TECHNICAL DATA Product Name Lawn Mowing Robot Model MPB11 MPB12 MPB13 Brand ECOVACS Basic Information Dimensions: 650×432×420 Length (mm) × Width (mm) × Height (mm) Net Weight (kg) (Battery Included) Rated Voltage Working Capacity ( ) 1600 2000 Mower Parameters...
  • Page 22 Bluetooth® 2400MHz ~ 2483.5MHz Wi-Fi 2400MHz ~ 2483.5MHz GSM:EGSM 900:Uplink:880-915MHz,Downlink:925-960MHz DCS 1800: Uplink:1710-1785MHz,Downlink:1805-1880MHz WCDMA: BAND I: Uplink:1920-1980MHz,Downlink:2110-2170MHz BAND VIII: Uplink:880-915MHz,Downlink:925-960MHz LTE: E-UTRA BAND 1: Uplink:1920-1980MHz,Downlink:2110-2170MHz Connectivity Cellular Network E-UTRA BAND 3: Uplink:1710-1785MHz,Downlink:1805-1880MHz Frequency Range E-UTRA BAND 7: Uplink:2500-2570MHz,Downlink:2620-2690MHz E-UTRA BAND 8: Uplink:880-915MHz,Downlink:925-960MHz E-UTRA BAND 20: Uplink:832-862MHz,Downlink:791-821MHz E-UTRA BAND 28: Uplink:703-748MHz,Downlink:758-803MHz E-UTRA BAND 38: Uplink:2570-2620MHz,Downlink:2570-2620MHz...
  • Page 23 Model CH2203 CH2203B CH2203A Input Voltage 21 V Station Input Current 1.8A 4.3A Output Voltage 21 V Output Current 1.8A 4.3A Note: Technical and design specifications may be changed for continuous product improvement. Explore more accessories at https://www.ecovacs.com/global. 25 EN...
