Carry out installation
22/43
6 Installation and commissioning
6.1 Installation
The appliance may only be operated indoors.
Place the lightSTUDIO AW Mount with the corresponding lightSTUDIO
AW Head variant on a stable, level surface.
The lightSTUDIO AW Mount with the mounted lightSTUDIO AW Head
version requires a footprint of 134 x 84 cm and an additional 15 cm of
space at the rear for the connection cables and the power supply unit.
CAUTION!
Falling or crushing
The appliance may tip over if placed on an inclined or mova-
ble surface.
Ensure the lightSTUDIO AW Mount is placed on a stable sur-
face and securely connected to the lightSTUDIO AW Head.
Connect the corresponding lightSTUDIO AW Head variant to the PC
using the USB cable.
Figure 6 - 1 Connection via the USB cable
