Summary of Contents for Cookology TOF690SS/1
- Page 1 Built-in Electric Oven User Manual TOF690SS/1 Please register the warranty for this product on www.Cookology.com In case of any differences between the appliance and the pictures in this manual, the product shall prevail.
-
Page 2: Table Of Contents
CONTENTS SAFETY INFOR Intended use Warning Causes of damage INSTALLATION OPERATING THE APPLIANCE Identifying the appliance TOF690SS/1 Component Before using the appliance Types of heating Using your appliance ACCESSORIES ENERGY EFFICIENT USE ENVIRONMENT HEALTH MAINTENANCE YOUR APPLIANCE APPLIANCE DOOR CURE YOUR APPLIANCE WHEN NEEDED... -
Page 3: Safety Infor
SAFETY INFORMATION Intended Use Thank you for buying the Built-in Oven. Before unpacking it, please read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Warmly recommend retain the instruction manual and installation instructions for future use or for subsequent owners. -
Page 4: Warning
WARNING Risk of electric shock! 1. Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker in the fuse box. - Page 5 Risk of scalding! 1. The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance. 2. When you open the appliance door, hot steam can escape. Steam may not be visible, depending on its temperature.
-
Page 6: Causes Of Damage
Hazard due to magnetism! Permanent magnets are used in the control panel or in the control elements. They may affect electronic implants, e.g. heart pacemakers or insulin pumps. Wearers of electronic implants must stay at least 10 cm away from the control panel. - Page 7 damaged over time. Only leave the appliance to dry with the door open if a lot of moisture was produced while the oven was operating. 7. Fruit juice: when baking particularly juicy fruit pies, do not pack the baking tray too generously. Fruit juice dripping from the baking tray leaves stains that cannot be removed.
-
Page 8: Installation
INSTALLATION min.35 min. min. min. min. min.585 min. min. max.595 min.35 min.35 To operate this appliance safe , please be sure that it has been installed to a professional standard respecting the installation instructions . Damages occur because of incorrect installation are not within the warranty. -
Page 9: Operating The Appliance
OPERATING THE APPLIANCE IDENTIFYING THE APPLIANCE Confirm the model number. You can distinguish model number by the control panel. TOF690SS/1 COMPONENT Cancel Cancel the current state and enter standby mode. 2. Child-Proof Lock use child-proof lock with 3s press Use timer function 3. -
Page 10: Before Using The Appliance
BEFORE USING THE APPLIANCE First using for the first time Before using the appliance to prepare food for the first time, you must clean the cavity and accessories. Remove all stickers, surface protection foils and transport protection parts. Remove all accessories and the side-racks from the cavity. Clean the accessories and the side-racks thoroughly using soapy water and a dish cloth or soft brush. -
Page 11: Types Of Heating
TYPES OF HEATING Your appliance has various operating modes which make your appliance easier to use. To enable you to find the correct type of heating for your dish, we have explained the di erences and scopes of application here. Types of Heating Temperature For traditional baking and roasting on one... -
Page 12: Using Your Appliance
Caution! If you open the appliance door during an on-going operation, the operation will not be paused. Please be especially careful with the risk of burns. Notes To defrost big portions of food, it is possible to remove the side-racks and place the container on the cavity floor. - Page 13 Change during cooking During the period of appliance operating, you can change the heating type setting and temperature setting by oven-function or slider. After the change, if there no other action after 6 seconds the oven will heat as what you changed. If you want change cooking duration time in the cooking process, please touch and change it by slider or “+/-“symbol.
-
Page 14: Accessories
Childproof lock Your appliance has a childproof lock so that children cannot switch it on accidentally or change any settings. When you give a long press for 3 seconds, childproof lock is activated. A long press for 3 seconds again the oven is unlocked. You can activate and deactivate childproof lock when the oven is work or not. - Page 15 You can use the tray to place liquid or cooking food with juice. Only use original accessories. They are specially adapted for your appliance. You can buy accessories from the after-sales service, from specialist retailers or online. Note The accessories may deform when they become hot. This does not a ect their function. Once they have cooled down again, they regain their original shape.
- Page 16 Locking function Accessories can be approximately pulled halfway out until they lock in place. The locking function prevents accessories from tilting with the gravity of food and accessories themselves while they get pulled out. Accessories should be inserted into cavity correctly for the tilt protection.When inserting the wire rack, ensure the wire rack is onto the right facing direction like the picture When inserting the backing tray, ensure the backing tray is onto the right facing direction...
-
Page 17: Energy Efficient Use
ENERGY EFFICIENT USE Remove all accessories, which are not necessary during the cooking & baking process Do not open the door during the cooking & baking process If you open the door during cooking & baking, switch the mode to “Lamp” (Without change the temperature setting) Decrease the temperature setting in not fan assisted modes to 50°C at 5min to 10min before end of cooking &... -
Page 18: Environment
ENVIRONMENT The packaging is made for protect your new appliance against damages during transport. The materials used are selected carefully and should be recycled. Recycling reduces the use of raw materials and waste. Electrical and electronic appliances often contain valu- able materials. - Page 19 Caution! Risk of surface damage Do not use: Harsh or abrasive cleaning agents. Cleaning agents with a high alcohol content. Hard scouring pads or cleaning sponges. High-pressure cleaners or steam cleaners. Special cleaners for cleaning the appliance while it is hot. Wash new sponge cloths thoroughly before use.
- Page 20 Area Appliance exterior Cleaning Hot soapy water: Clean with a dish cloth and then dry with a soft cloth. Door handle If descaler comes into contact with the door handle, wipe it o immediately. Otherwise, any stains will not be able to be removed. Enamel surfaces Observe the instructions for the surfaces of the cooking com- and self-cleaning...
-
Page 21: Appliance Door
Enamel is baked on at very high temperatures. This can cause some slight color variation. This is normal and does not a ect operation. The edges of thin trays cannot be completely enameled. As a result, these edges can be rough. This does not impair the anti-corrosion protection. - Page 22 Removing the appliance door Open the appliance door fully. Fold open the two locking levers on the left and right Close the appliance door as far as the limit stop. With both hands, grip the door on the left- and right-hand side, and pull it out upwards. Fitting the appliance door Reattach the appliance door in the opposite sequence to removal.
- Page 23 Removing the door cover The plastic inlay in the door cover may become discolored. To carry out thorough cleaning, you can remove the cover. Remove the appliance door like instructed above. Press on the right and left side of the cover. Remove the cover.
- Page 24 Caution! While the appliance door is well installed, the door cover can also be taken o , by this time. Removing the door cover means to set the inner glass of the appliance door free, the glass can be easily moved and cause damage or injury. As removing the door cover and inner glass means to reduce the overall weight of the appliance door.
-
Page 25: Cure Your Appliance When Needed
Change the power cord Position A show the terminal box position on the back of the back outer case and it’s closed. Steps: a. cut o the power, use small flat screwdriver to open two snap 1，2. b. use Phillips crewdriver to take o screws 3，4 ，5and6. - Page 26 Knobs can be removed. To disengage knobs, simply remove them from the support. Alternatively, press on the outer edge of knobs so Knobs can no There is dirt that they tip and can be picked up easily. longer be under knobs Carefully clean the knobs using a cloth and soapy water.
- Page 27 Maximum operating time The maximum operating time of this appliance is 9 hours, to prevent that you forget shot o the power. Replacing the lamp on the corner of the cavity If the cavity lamp fails, it must be replaced. Heat-resistant, 25 watt, 230 V halogen lamps are available from the after-sales service or specialist retailers.
-
Page 28: Customer Service
When calling us, please give the model number and S/N so that we can provide you with the correct advice. The rating plate bearing these numbers can be found when you open the appliance door. Model: TOF690SS/1 Rated voltage: 220-240V~ Rated frequency:... -
Page 29: Tips And Tricks
TIPS AND TRICKS You want to cook your Try to use settings of similar recipes first and optimize own recipe the cooking process due to the result. Put a wooden stick inside the cake about 10 minutes before the given baking time is reached. If there is no raw Is the cake baked ready? dough at the stick after pulling out, the cake is ready. - Page 30 Every heat resistant baking ware can be used. It is Which kind of baking recommended not to use aluminum in direct contact with food, especially when it is sour. ware can be used? Please ensure a good fitting between container and lid. Preheat the oven for 5 minutes and place the food in the level given by this manual.
-
Page 31: Typical Recipes
TYPICAL RECIPES Duration CAKE Form Level Mode Temp.in °C in minutes Sponge Cake (simple) Conventional in a Box shape with Fan Sponge Cake (simple) Conventional in a Box shape Sponge Cake with Round form Conventional Fruits in a round Form with Fan Sponge Cake with Tray... - Page 32 Duration CAKE Form Level Mode Temp.in °C in minutes Tray Convention Small Cakes p.h.t:10:00 Tray Small Cakes Convention b.t.:34:00 p.h.t.: 8:00 Butter Yeast Cake Tray Conventional b.t.: 30:00 p.h.t.: 8:00 Shortbread Tray Conventional b.t.: 13:00 Shortbread 2 Trays Tray Conventional p.h.t:8:20 with Fan b.t.: 12:00...
-
Page 33: Meat
Duration MEAT Form Level Mode Temp.in °C in minutes Beef Tender Loin Tray Double Grill with fan Meatloaf 1 kg Meat Tray Conventional Chicken 1 kg Tray L2:Rack Double Grill L1:Tray with fan Fish (2,5 kg ) Tray Conventional Ribs Tomahawk Tray Convention Cooked B.T. - Page 34 TEST FOOD ACCORDING TO EN 60350-1 ℃ RECIPESA Accessories Level Time(min) Pre-heat Toast Rack Yes 5min Rack 2 chicken Rack & tray 75-80 Tray 1 In chicken recipe, begin with the backside on top and turn the Chicken after 30 min. to the top side Use a dark, frosted mold and place it on the rack Take out the trays at the moment, when the food is ready, even when it is not at the...
-
Page 35: Cooking By Eco Mode
Rack and round plate 65-70 Lasangne Rack and glass plate 75-80 Cheese Cake Springform Φ20cm 80-90 DATASHEET (EU 65/2014 & EU 66/2014) TOF690SS/1 No of Cavities Heat Source Electric Usable Volume ECelectric, cavity (Conventional) 1.06kWh/cycle ECelectric, cavity (Forced Air) 0.69kWh/cycle EEICavity... - Page 36 Please register the warranty for this product on www.Cookology.com...
