Manitowoc 3900W Service Manual

Table of Contents

Advertisement

Quick Links

Download this manual

This manual has been prepared for and is considered part of -

The crane serial number is the only method your distributor or the factory

has of providing correct parts and answers to service problems.

The crane serial number is located on a decal attached to the operator's

cab. Always furnish crane serial number when ordering parts or

communicating service problems with your distributor or the factory.

TH

2401 SO. 30

08/29/05

SERVICE MANUAL

3900W

Crane Model No.

395143

Crane Serial No.

This manual is divided into the following sections:

SECTION 1

General

SECTION 2

Attachment

SECTION 3

Maintenance

SECTION 4

Lubrication

SECTION 5

Capacities

SECTION 6

Operating Controls

SECTION 7

Adjustments

SECTION 8

Troubleshooting

NOTICE

To prevent death or serious injury:

• Avoid unsafe operation and maintenance.

• This crane must be operated and maintained by trained and

experienced personnel. Manitowoc Cranes is not responsible for

qualifying these personnel.

• Do not operate or work on this crane without first reading and

understanding Operator's Manual and Capacity Charts supplied with

crane.

• Store Operator's Manual supplied with crane in holder in operator's

cab.

• Attach laminated Capacity Charts supplied with crane to chain in

operator's cab.

• If Operator's Manual or Capacity Charts are missing from cab,

contact your distributor for new ones.

MANITOWOC CRANES, INC.

STREET

PO BOX 70

MANITOWOC, WI 54221-0070 USA

PHONE 920-684-6621

FAX 920-683-6338
