- Page 1 User Guide Bluetooth Nano USB Adapter MA530 REV1.0.0 1910080133...
- Page 2 Specifications are subject to change without notice. is a registered trademark of MERCUSYS TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from MERCUSYS TECHNOLOGIES CO., LIMITED.
- Page 3 2402MHz~2480MHz: 8.5dBm EU declaration of conformity MERCUSYS hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.mercusys.com/support/ce.
- Page 4 低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 BSMI Notice 安全諮詢及注意事項 • 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 • 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 • 注意防潮，請勿將水或其他液體潑灑到本產品上。 • 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 • 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 • 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 設備名稱：Bluetooth Nano USB Adapter 型號（型式）：MA530 Equipment name Type designation (Type) 限用物質及其化學符號 產品元件 鉛 鎘 汞 六價鉻 多溴聯苯 多溴二苯醚 名稱 CrVI PBDE ○ ○...
- Page 5 • Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. • Do not use the device where wireless devices are not allowed. • This equipment can be powered only by equipments that comply with Power Source Class 2 (PS2) or Limited Power Source (LPS) defined in the standard of IEC 62368-1.
- Page 6 Protective earth Earth Frame or chassis Functional earthing Caution, hot surface Caution Operator’s manual Stand-by “ON”/”OFF” (push-push) Fuse Fuse is used in neutral N RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
- Page 7 Switch of mini-gap construction Switch of micro-gap construction (for US version) µ Switch of micro-gap / micro-disconnection construction (for other versions except US) ε Switch without contact gap (Semiconductor switching device)
- Page 8 Conventions The Adapter or MA530, or device mentioned in this User Guide stands for Bluetooth Nano USB Adapter without any explanations. Note: Features of the adapter may vary by model and driver version. All images, steps, and descriptions in this guide are only examples and may not reflect your actual adapter experience.
-
Page 9: Table Of Contents
CONTENTS Conventions ....................... 01 Chapter 1 Introduction ..................02 1.1 Product Overview ......................02 1.2 Features ..........................02 Chapter 2 Installation Guide ................03 2.1 Hardware Connection ...................... 03 2.2 Driver Installation ......................03 Chapter 3 Pair With Your Bluetooth Devices ........... 04 Chapter 4 Uninstall Driver ..................06 Troubleshooting ...................... -
Page 10: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 Introduction Product Overview MA530 makes your PC Bluetooth-capable with ultra-fast Bluetooth 5.3 which achieves more stable connection, farther range and faster transmission speeds. Just connect your Bluetooth devices to your computer and enjoy with ease. † Features Ǵ Bluetooth 5.3 — Speed, coverage, security and reliability improvement than last- gen Bluetooth Ǵ... -
Page 11: Chapter 2 Installation Guide
4. Once the process is finished, restart your computer. Note: • Your MERCUSYS Bluetooth USB adapter will be listed in the Device Manager when the driver is installed correctly. • If the driver installation fails, disable the antivirus software and firewall, then try again. -
Page 12: Chapter 3 Pair With Your Bluetooth Devices
Chapter 3 Pair With Bluetooth Devices Chapter 3 Pair With Your Bluetooth Devices With both the hardware and software successfully installed into your computer, you can quickly pair with your Bluetooth devices. For Windows 7: 1. Open Start menu to access Devices and Printers. 2. - Page 13 Chapter 3 Pair With Bluetooth Devices Note: Make sure your Bluetooth device is set to be discoverable. If the Bluetooth icon doesn’t appear, refer to Troubleshooting->Q1. During the pairing, you may be prompted to enter the pairing code. You need to enter the identical code to both devices.
-
Page 14: Chapter 4 Uninstall Driver
1. Press Windows key + R, type 'control', and then press Enter to open the Control Panel . 2. Locate Programs and click Uninstall a program. 3. Find Mercusys MA530 Bluetooth 5.3 Driver. Right-click the driver and select Uninstall 4. Follow the on-screen instructions to complete the uninstallation. 5. Restart your computer. -
Page 15: Troubleshooting
A1. Make sure your device has BLUETOOTH function. A2. Make sure you have installed the latest Bluetooth driver on the computer. You can check the published driver versions from https://www.mercusys.com/support A3. For devices with non-standard Bluetooth protocols, such as Logitech Mouse, there may be some compatibility problems. -
Page 16: Appendix: Specifications
Appendix: Specifications Appendix: Specifications Normal Interface USB 2.0 Interface Standards Bluetooth 5.3 19.15 × 14.94 × 7.19 mm Dimensions (0.75 × 0.59 × 0.28 in.) Operating System Windows 11/10/8.1/7 (32/64-bit) Signal Rate 2402-2480 MHz Safety & Emissions CE, ROHS Environmental and Physical Operating 0°C~40°C (32°F~104°F) Temperature...
