Smeg OFGG7GVXA Manual

Smeg OFGG7GVXA Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1. PRECAUTIONS FOR USE ...................................................................................................... 4
2. INSTALLING THE APPLIANCE .............................................................................................. 6
3. ADAPTATION TO DIFFERENT TYPES OF GAS ................................................................ 10
4. FINAL OPERATIONS ........................................................................................................... 13
5. GETTING TO KNOW YOUR COOKER ................................................................................. 14
6. DESCRIPTION OF FRONT PANEL CONTROLS ................................................................ 15
7. USING THE HOB .................................................................................................................. 17
8. USING THE OVEN ................................................................................................................ 18
9. AVAILABLE ACCESSORIES ............................................................................................... 20
10. CLEANING AND MAINTENANCE ...................................................................................... 21
11. EXTRAORDINARY MAINTENANCE .................................................................................. 23
12. PROBLEMS AND CAUSES ................................................................................................ 24
Thank you for choosing our product.
We advise you to read this manual carefully. It contains all necessary instructions for maintaining
unaltered the appearance and functional qualities of the cooker.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorized person who is to check
the gas supply system and install, commission and test the appliance.
INSTRUCTIONS FOR THE USER: these provide recommendations for use, a description of the controls
and the correct procedures for cleaning and maintaining the appliance.

Table of contents

3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OFGG7GVXA and is the answer not in the manual?

Questions and answers

brian barron
July 17, 2025

my oven is not heating properly. Took too long to cook scones so not tasty

0

Subscribe to Our Youtube Channel

Related Manuals for Smeg OFGG7GVXA

Summary of Contents for Smeg OFGG7GVXA

  • Page 1: Table Of Contents

    12. PROBLEMS AND CAUSES ....................24 Thank you for choosing our product. We advise you to read this manual carefully. It contains all necessary instructions for maintaining unaltered the appearance and functional qualities of the cooker. INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorized person who is to check the gas supply system and install, commission and test the appliance.

  • Page 2: Precautions For Use

    ELEMENTS INSIDE THE OVEN. TO AVOID BURNS AND SCALDS CHILDREN SHOULD BE KEPT AWAY. IF THE APPLIANCE IS TO BE POSITIONED ON A PLATFORM IT MUST BE INSTALLED IN SUCH A WAY AS TO PREVENT IT FROM SLIPPING OFF THE FORMER.
  • Page 3 ON THE WARRANTY CARD. The manufacturer declines all responsibility for injury or damage caused by failure to comply with the above regulations or deriving from tampering with even just one part of the appliance and the use of non-original spare parts.

  • Page 4: Installing The Appliance

    This rating plate must never be removed. The plug on the end of the power supply cable and the wall socket must be of the same type (in compliance with the relevant national standards). Check that the power supply line is properly earthed.

  • Page 5: Gas Connection

    For proper operation of a gas appliance it is essential for the air necessary for combustion of the gas to be able to flow naturally into the room. Air must flow directly into the room through openings in its outside walls. This (these) opening (s) must have a free passage cross- section of at least 100 cm2, or 200 cm2 for appliances not equipped with gas safety device.
  • Page 6 Where D, the distance from the periphery of the nearest burner to a horizontal combustible surface is less than 200 mm, then E shall be 10 mm or more, or the horizontal surface shall be above the trivet. See insets above.
  • Page 7 Instructions for the installer Instruction for wall fixing 1 Fasten the two wall brackets to the wall taking care to comply with the centre distances and measurements indicated in the images below. The dimensions are given in mm. A= 262 / B = 218 2 Attach the chain to the cooker 3 Stretch out the chain attached to the cooker horizontally so that the other end touches the wall.

  • Page 8: Adaptation To Different Types Of Gas

    The cooker hob is preset for natural gas at a pressure of 1.0 KPa. In the case of operation with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps. To change the nozzles, proceed as described below.
  • Page 9 Rapid (3) 12.0 1.55 Ultra-rapid (4) 15.8 1.85 Oven 11.5 1.55 3.3 Arrangement of the burners on the hob BURNERS min. and max. Ø (in cm) 1. Auxiliary 12 - 14 2. Semi-rapid 16 - 24 3. Rapid 18 - 26 4.
  • Page 10 Instructions for the installer 3.4 Oven burner adjustment To adjust the oven burner you need to open the oven door and carry out the following operations: • Remove the oven basin and its rack. • Lift up the oven surface and pull it outwards.

  • Page 11: Final Operations

    After adjusting for use of a gas other than the gas used for testing the appliance, replace the gas setting label on the appliance with the label for the new gas. The label is supplied in the bag with the nozzles.

  • Page 12: Getting To Know Your Cooker

    Instructions for the user 5. GETTING TO KNOW YOUR COOKER CONTROL PANEL omega OVEN/MAIN OVEN FOOD WARMER COMPARTMENT...

  • Page 13: Description Of Front Panel Controls

    Instructions for the user 6. DESCRIPTION OF FRONT PANEL CONTROLS All the cooker controls are grouped together on the front panel. The symbols used are described in the table below. omega OVEN THERMOSTAT KNOB REAR LEFT-HAND BURNER OVEN FUNCTIONS KNOB...
  • Page 14 ) functions can be used when the oven is off. The fan-assisted function ( ) can only be used if the gas oven is lit. Ventilation will start working when the oven has reached a temperature of about 120-130 °C.

  • Page 15: Using The Hob

    The optional grid B is for use with woks. To prevent damage to the hob, the cooker comes complete with a raised pan stand C for use underneath pans more than 26 cm in diameter. The pan stand C supplied is for use even with small pans.

  • Page 16: Using The Oven

    The tangential cooling system remains active even after cooking has finished and continues working when the oven has been switched off in order to disperse all the heat that has built up in side. This mechanism allows all the furniture units surrounding the appliance to be protected, preventing them from overheating.

  • Page 17: Using The Electric Grill

    It is not possible to operate the gas oven and the grill at the same time. 8.4.1 How to use the grill When the oven has come on, confirmed by the red light switching on, leave it to heat up for 5 minutes before placing foods inside.

  • Page 18: Available Accessories

    Oven shelf: for cooking food on plates, small cakes or roasts or foods requiring light grilling. Tray grid: for placing on top of a tray for cooking foods which may drip. Oven tray: useful for collecting fat from foods placed on the grid above.

  • Page 19: Cleaning And Maintenance

    Rinse thoroughly and dry with a soft cloth or chamois leather. Do not allow spills of foods with high sugar content (e.g. jam) to dry inside the oven. If they dry for too long, they might damage the enamel coating of the inside of the oven.
  • Page 20 Do not use abrasive or corrosive cleaners for cleaning the door glazing. (e.g. powder products, oven- cleaner sprays, stain removers and metal scouring pads). Do not use rough or abrasive materials or sharp metal scrapers to clean the oven's glass doors since they may scratch the surface and cause the glass to shatter.

  • Page 21: Extraordinary Maintenance

    11.1 Changing the light bulb Remove the protective cover A by unscrewing it anti-clockwise; replace the bulb B with another of the same type (25 W). Re-fit the bulb protector A. WARNING : Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.

  • Page 22: Problems And Causes

    Instructions for the user 12.PROBLEMS AND CAUSES Each of the following cases is caused by abnormal operation of the appliance and should be dealt with by a authorised person: please contact your local dealer or Service Center in case you detect any of these malfunctioning.
  • Page 24 914774105/ B...
