Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear eye
instructions
protection
1. SAFETY
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this
equipment.
Familiarise yourself with the application and the limitations of the riveter, as well as the potential hazards.
9
Maintain the riveter in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the riveter clean for best and safest performance.
9
Check moving parts alignment on a regular basis.
9
DO NOT hold the workpiece by hand. Secure unstable workpiece with a clamp, vice or other adequate holding device.
8
Ensure the workpiece is correctly secured before using the riveter.
9
DO NOT use the riveter for any purpose other than that it was designed for.
8
DO NOT operate the riveter if any parts are damaged or missing, as this may cause failure and/or personal injury.
8
When not in use store in a safe, dry, childproof location.
9
2. INTRODUCTION
Suitable for blind rivets, rivet nuts and rivet studs in aluminium, steel and stainless steel. 360° Swivel head gives greatly improved accessibility.
Four nozzles for blind rivets, four mandrels for rivet nuts and three mandrels for rivet studs. Supplied with spanners and a selection of steel rivet
nuts.
3. SPECIFICATION
Model no.: .............................................................AK396.V4
Contents:
Blind Rivet Nozzle Sizes:
2.4(3/32"), 3.2(1/8"), 4(5/32"), 4.8mm(3/16")
Rivet Nut Sizes: M3 x 0.5, M4 x 0.7, M5 x 0.8, M6 x 1mm
Rivet Stud Sizes: M4 x 0.7, M5 x 0.8, M6 x 1mm
Rivet Materials:
Aluminium, Steel, Stainless Steel
Rivets Nuts Supplied:M3 x 0.5, M4 x 0.7, M5 x 0.8, M6 x 1mm (10pc each)
4. CONTENTS
© Jack Sealey Limited
BLIND NUT & STUD RIVETING KIT
AK396.V4
MODEL NO:
Original Language Version
AK396.V4
Issue 1
03/10/22
