INSTALLATIONS

■ Optional AH-5NV

When using the AH-740 with the optional AH-5NV, install the
AH-5NV as follows.
• Swivel magnet holder
Use allen wrench
to tighten
(6 mm,
Socket bolt
(Use 10 mm,
allen wrench)
Set screws
(Use 2.6 mm,
6
1 ⁄ ˝)
4
13 ⁄ ˝
32
1 ⁄ ˝ allen wrench)
10
1 Place the swivel magnet holder onto the vehicle, and
attach the NVIS antenna element to the antenna spring
of the AH-740.
• Secure the antenna element by tighten the set screws.
2 Insert the antenna element into the swivel magnet holder,
as shown below.
3 Tighten the set screw.
NVIS antenna
Swivel magnet holder
Set screw
Allen wrench (2.6 mm, 1 ⁄ ˝)
10
