INSTRUCTIONS FOR SAFE AND PROPER USE ____________________ 25 POSITIONING OF THE HOB ____________________________________ 27 ELECTRICAL CONNECTION ____________________________________ 29 GAS CONNECTION ___________________________________________ 30 ADAPTATION TO DIFFERENT TYPES OF GAS _____________________ 32 FINAL OPERATIONS __________________________________________ 36 USING THE HOB______________________________________________ 39 CLEANING AND MAINTENANCE_________________________________ 42 THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
Introduction INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKING HOB. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKING HOB.
Page 3
Introduction THE IDENTIFICATION PLATE, WITH TECHNICAL DATA, SERIAL NUMBER AND MARKING IS CLEARLY VISIBLE UNDER THE CASING. THE PLATE ON THE CASING MUST NOT BE REMOVED. BEFORE CONNECTING THE DEVICE, MAKE SURE THAT IT HAS BEEN REGULATED FOR THE TYPE OF GAS THAT WILL FEED IT, CHECKING THE LABEL UNDER THE HOB.
Instructions for the installer POSITIONING OF THE HOB The following operation requires building and/or carpentry work so must be carried out by a competent tradesman. Installation can be carried out on various materials such as masonry, metal, solid wood or plastic laminated wood as long as they are heat resistant (T 90°C).
Page 5
Instructions for the installer Bracket ‘A’ in the 1st slot Bracket ‘A’ in the 2nd slot Bracket ‘B’ Fixing 90 cm hobs on 60 cm base unit If a 90 cm hob is to be bracketed to a 60 cm base unit, 2 central brackets “A”...
Instructions for the installer ELECTRICAL CONNECTION Make sure that the voltage and capacity of the power line conform to the data shown on the plate located under the casing. Do not remove this plate for any reason. The plug on the end of the supply cable and the wall socket must be the same type and conform to the current electrical system regulations.
Instructions for the installer GAS CONNECTION Connection to the gas mains may be made with a rigid copper pipe or with a flexible pipe and conforming to the provisions defined by standard regulations in force. To facilitate connection, fitting A on the rear of the appliance may be adjusted laterally.
Page 8
Instructions for the installer Connection to LPG Use a pressure regulator and make the connection to the tank according to the provisions of standards regulations in force. Make sure that feed pressure conforms to the levels shown in the table in paragraph “5.3 Regulation for LPG”.
Instructions for the installer ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, disconnect the appliance from the electrical socket. The hob has been inspected for G20 (2H) natural gas at a pressure of 20 mbar. For functioning with other types of gas the nozzles must be replaced and the primary air adjusted.
Page 10
Instructions for the installer Regulation for LPG Check that the connection has been made as described in the “Gas connection” section. Undo the screw “D” and push the air regulator “C” fully down. Use a spanner to remove the nozzles “B” and fit those of suitable type following the instructions given in the tables for bottled gas G30/G31 –...
Page 11
Instructions for the installer Regulation for natural gas The hob has been inspected for G20 (2H) natural gas at a pressure of 20 mbar. To allow the unit to work with this type of gas, perform the same operations described in paragraph “5.3 Regulation for LPG”, but choose the nozzles and regulate the primary air for natural gas, as shown in the following table and in paragraph “5.5 Regulation of primary air”.
Page 12
Instructions for the installer Regulation of primary air Referred to distance “A” in mm. 60 cm hobs with separable control panel. Burner Auxiliary (1) Semirapid r (2) Semirapid l (3) Rapid large (4) Ultrarapid (5) 90 cm hobs with separable control panel. Burner Auxiliary (1) Semirapid (2)
Instructions for the installer FINAL OPERATIONS Having carried out the above adjustments, reassemble the appliance following, backwards, the instructions in paragraph “5.1 Removing the separable control panel / 5.2 Removing the hob”. Regulation of minimum for natural gas Replace the components on the burner and slide the knobs on the gas tap pins.
Page 14
Instructions for the installer Arrangement of the burners on the hob (Hob with separable control panel) 60 cm. hob BURNERS Auxiliary Semirapid r Semirapid l Rapid large Ultrarapid 90 cm. hob BURNERS Auxiliary Semirapid Rapid Fish burner Ultrarapid...
Page 15
Instructions for the installer Arrangement of the burners on the hob (Hob with built-in control panel). 60 cm. hob Lubrication of gas taps With time it may happen that the gas taps get blocked and hard to turn. Clean them inside and re-grease them. This operation must be done by an authorised person.
Instructions for the user USING THE HOB Before turning on the burners, make sure that the burner rings, caps and grids have been fitted correctly. In the ultrarapid burner, notch A must be aligned with pin B. Grid C provided is intended for use with woks (Chinese pans). Adapter D comes only with open grids models and is intended for use with small sized vessels.
Page 17
Instructions for the user while ooking, all pans or griddle within the co inimum distance of 3-4 cm from t Diameter of the pans Burners Auxiliary Rapid medio Rapid large Ultrarapid Fish burner Electric elements 7.4.1 Turning on electric elements obs may be fitted with an electric element of varyin d ameter.
Page 18
Instructions for the user Strong Very strong ARNING When switching on the electric e first time, or if the electric element has not been used for a long time, to remove any from the insulating material it should be dried out by placing the electric element on position 1 for 30 minutes.
Instructions for the user CLEANING AND MAINTENANCE Never use a steam jet to clean the appliance. Before any intervention, disconnect the power supply of the device. Cleaning Clean the cooking top regularly every time you use it, obviously after it has cooled.
Page 20
Instructions for the user Cleaning of cooking hob components CAUTION: do not wash these components in a dishwasher. In normal use of the hob, the stainless steel burner caps and pan- stands tend to be burnished by the high temperature. Clean these parts using very fine abrasive sponges or similar commercial products.
