Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. Related Manuals: 309205 - HVLP Turbine Gun ti3692b Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2004, Graco Inc. is registered to I.S. EN ISO 9001...
Specifications ......19 Graco Standard Warranty ....20 Manual Conventions The following are general Warnings related to the safe setup, use, maintenance and repair of this equipment.
Do not alter or modify equipment. • For professional use only. • Use equipment only for its intended purpose. Call your Graco distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces. •...
Page 4
Warnings WARNINGS PRESSURIZED ALUMINUM PARTS HAZARD Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids containing such solvents in pressurized aluminum equipment. Such use can cause serious chemical reaction and equipment rupture, and result in death, serious injury, and property damage. PERSONAL PROTECTIVE EQUIPMENT You must wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic...
Unpacking Turbine wood, plastic, and architectural applications. Unpack the Graco Turbine Sprayer from the shipping To produce high-quality paint finishes, the spray gun typ- carton. Inspect for any possible shipping damage. If ically utilizes inbound air pressure of 6 psi (0.4 bar, 41 there is any damage, call your distributor.
Component Identification Component Identification ti3693a Item Description Turbine air outlet Connection for turbine air supply to HVLP-Turbine Gun Turbine power switch On/Off switch for sprayer turbine Storage compartment Provides storage for fluid set components Turbine handle Folds flat for minimum storage space Turbine cover Houses air filter and provides dual air flow to motor and turbine AIr filters (pre-filter and main)
Setup Setup Grounding and Electric • When using a turbine spray system, use a slower drying reducer or thinner to compensate for the Requirements faster drying time caused by the warm air of the tur- bine. Do not over reduce! WARNING CAUTION Turbine sprayer performance varies with the viscosity...
Page 8
Setup Connect Fluid and Air Supply If using accessory remote pressure pots (F): Con- nect fluid supply hose (G) between remote pressure pot fluid outlet (H) and gun fluid inlet (E), or connect Connect Fluid and Air Supply (Fig. 2) pressure pot air hose (J) between pressure pot air regulator inlet (K) and the cart compressor air outlet •...
Page 9
Setup Pressure Relief Procedure CAUTION If the 2-quart remote pressure pot is accidentally WARNING tipped over or held at too great of an angle, fluid may leak into air regulator and cause damage. Take pre- The accessory remote pressure pot remains cautions to avoid this.
Page 10
Setup Preparing the Spray Surface Turn turbine On a few minutes before spraying to allow warm-up. To get proper adhesion, ensure surface is completely Note: When turbine is not in use for an extended period clean. of time, turn it off. The turbine does not shut off automat- ically.
Maintenance Maintenance Daily • Soak filter for 15 minutes in water and mild detergent. Rinse filter until clean. Air dry. The turbine system is lifetime lubricated. The only main- tenance required is filter cleaning and replacement. WARNING The turbine filter must be clean at all times to provide sufficient air flow to cool the motor and atomize the fluid.
Troubleshooting Troubleshooting Problem Cause Solution No fluid delivery No material, no remote container Check container for material pressurization, hose or pickup tube Check for leaks at the container gas- clogged ket (2-quart pressure pot cover). Tighten cover if loose. Check for air flow from male quick-disconnect at compressor out- let (should be approximately 1/4 CFM).
Repair Repair After completing repair, place turbine base plate (2) WARNING on its back. Slide turbine cover (1) on turbine base plate approximately 1-2 in. (to get it started). To avoid injury, including electric shock turn off turbine and unplug power cord before performing 10 Reaching between the turbine cover (1) and base and repair procedures on the turbine.
Page 15
Repair Motor Brush Replacement Turbine/Motor Replacement Note: It is recommended that this procedure be per- Refer to Parts Drawing, page 16. formed by an authorized service center technician. Follow Turbine Sprayer Disassembly procedure, Follow Turbine Sprayer Disassembly procedure, page 13. page 13.
Specifications Specifications Power requirements 220V AC, 50 Hz Amps at 220V 1 phase, 8A minimum Power cord (extension must be 3-wire, 12 AWG, No. 12 AWG, 3-wire, 15 ft 50 ft (15 m) or shorter Unrestricted air flow rate 80 cfm Turbine stages Maximum turbine hose length 60 ft.
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
