Operation
TexFinish™
For Water-Based Materials Only
Models:
246185
55 psi (3.8 bar) Maximum Fluid Working Pressure
Read warnings and instructions.
Related Manuals
309584
309797
Graco Inc. P.O. Box 1441 Minneapolis, MN
55440-1441
Interior Texture Sprayers
ti3157a
US
C
Conforms to ANSI/UL
standard 1450
309796A
Advertisement
Table of Contents
Related Manuals for Graco Magnum TexFinish 246185
Summary of Contents for Graco Magnum TexFinish 246185
- Page 1 Interior Texture Sprayers TexFinish™ 309796A For Water-Based Materials Only Models: 246185 55 psi (3.8 bar) Maximum Fluid Working Pressure Read warnings and instructions. Related Manuals 309584 309797 ti3157a Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Conforms to ANSI/UL standard 1450...
- Page 2 Route hoses away from traffic areas, sharp edges, moving parts and hot surfaces. • Do not expose Graco hoses to temperatures above 130°F (55°C) or below -35°F (-37°C).Store haz- ardous fluid in an approved container. Dispose of hazardous fluid according to all local, state and national guidelines.
- Page 3 WARNINGS Electric Shock Hazard To reduce the risk of electric shock: • Be sure sprayer is adequately grounded through electrical outlet. • Use only 3-wire, extension cords. • Make sure ground prongs are intact on sprayer and extension cords. Improper installation of ground- ing plug will result in a risk of electrical shock, fire or explosion that could cause serious injury or death.
-
Page 4: Component Identification
Air Compressor (inside) Material thickness gauge Material/air hose Nozzle (3 sizes available) Texture spray gun (manual 309584) Gun air valve Material Hopper Burp guard Graco RotoFlex™ pump (inside) Hopper fitting (fluid inlet) Hose rack/cord wrap Hopper clamp Hose clip 309796A... -
Page 5: Generator Requirements
Preparation Preparation Pressure Relief Procedure WARNING To reduce risk of injury, follow this procedure page 2 and 3 whenever you see this symbol throughout this manual, Also, perform this procedure whenever you: 120V AC Systems • stop spraying. • This equipment grounded outlets requires a 120V AC,... -
Page 6: Texture Spraying
Setup Setup Important • If you are going to stop spraying for more than 5 minutes, turn sprayer off to prevent shortened pump hose life. • Do not allow material to dry inside pump, hoses, gun or spray system. 3. Open air valve. WARNING page 2 and 3 ti2448a... - Page 7 Setup Touch Up Hopper Attachment 8. Turn power switch ON. ti2446a • The Hose Plug must be securely fastened to bottom of gun when using the Touch Up 9. Close gun air valve. Hopper. Gun Plug must be removed from top of gun. ti2699a ti2453 10.
- Page 8 Setup 7. Turn hopper 8. Open gun air valve. gun/spray gun selector switch to HOPPER GUN. ti2448a ti2592a 9. Turn power switch ON. CAUTION ti2446a Failure to change selector switch to Hopper Gun when using hopper gun will damage pump hose. 10.
-
Page 9: Mixing Material
Mixing Material Mixing Material 5. Observe the ball on the Correct material mixture is essential. The pump READY ADD WATER material. When the mate- will not operate if the mixture is too thick. rial is thin enough to spray the ball will sink com- Mix the material in a separate container before pletely into the mixture. -
Page 10: Spray Techniques
Spray Techniques Spray Techniques Recommended Nozzle Selection Chart To Get Less Material Application Try one or a combination of these methods: Nozzle Size Air Volume Simulated 6 mm, white medium to • Open air valve. Acoustic (fine to medium) high 8 mm, gray •... -
Page 11: Shut Down And Clean-Up
Shutdown and Cleanup Shutdown and Cleanup Keep pump and hose clean when switching between simulated acoustic, knockdown and orange peel applications. A dirty pump can release particles of texture into the finish. CAUTION • Turn off sprayer if you are going to stop spraying for 5 minutes or longer. •... -
Page 12: Transporting The Sprayer
Shutdown and Cleanup Removing Material Hopper from Sprayer 3. Fill hopper with clean water. Remove nozzle The material hopper can be removed for cleaning. To from gun and allow water remove material hopper: to flow through and out of gun. 1. -
Page 13: Troubleshooting
Refer to Grounding and Electrical Requirements, page 5. Gun needle plugged Clean needle and retry. Worn compressor Replace compressor. Contact a qual- ified Graco Service Center. Lines not connected Check all quick disconnect connec- tions to gun and hoses Damaged hose Replace hose... - Page 14 Troubleshooting Problem Cause Solution Speed of application slow or slower Material too thick Thin material. Nozzle too small Change nozzles to a larger size. See Recommended Nozzle Selection Chart, page 10. Too much air being used. Partially close gun air valve to reduce air flow.
-
Page 15: Technical Data
Technical Data Technical Data Main unit power requirements 120V AC, 60 hz, 15A, 1 phase Maximum fluid working pressure 55 psi, (3.8 bar) Maximum air working pressure 38 psi (2.6 bar) Compressor specifications Universal motor thermally protected, oil-less Compressor air displacement 4.5 displacement scfm at 30 psi Generator required 3500 w minimum... -
Page 16: Limited Warranty
This warranty does not cover and Graco shall not be liable for general wear and tear, or any malfunction, damage, or wear caused by improper use, accidents, user negligence, use of non-Graco component parts or service or repair performed by anyone other than a Graco authorized service center.
