- Page 1 High Frequency Electrosurgical Unit EB03 Instruction Manual Version No: 2008-11-6...
-
Page 2: Table Of Contents
Circuit of rear panel ……………………………………………………………………………… 33 Maintenance technology ……………………………………………………………………………34 Daily check on accessories ……………………………………………………………………… 34 Warranty commitments …………………………………………………………………………… 34 Troubleshooting ……………………………………………………………………………………34 Regular check ……………………………………………………………………………………… 35 List of common failure………………………………………………………………………………36 List of external failure ………………………………………………………………………………36 List of internal failure ………………………………………………………………………………37 Attachment………………………………………………………………………………………… 38 Heal Force EB03... -
Page 3: Brief Introduction
Operation manual Brief Introduction EB03 series High Frequency Surgical Unit can be used in many surgical fields, like the general surgery dept, Gynecology dept, the five sense organs (or called ENT) dept, Orthopedics dept, Urological dept, Cerebral dept, Dermatological dept, and the heart and chest dept, etc. -
Page 4: Disassembly & Installation
Disassembly & Installation Disassembly Take out EB03 surgical unit with care; keep the hard board and materials used for package so that these could be used for the next transportation or rework. If there is any fault or question, please do not open the unit to repair by yourself; you should contact the manufacturer or local representative immediately. -
Page 5: Device Description
Order NO. Name of Article Quantity NGD-020 Foot switch 7SB-EB05NO-JDB Foot-control pen 7RB-EB03JB-001 Patient single return electrode (soft) 7DP-USAL-005 Connecting cable for patient soft electrode(single) 7NZ-310180-010 Bipolar coagulation forceps 1WC-EB03NZ-002 Connecting cable of forceps 7JB-EB0351-002 Hard Patient plate Heal Force EB03... -
Page 6: Diagram
Operation manual Diagram Heal Force EB03... -
Page 7: Control And Display Panel
23 LED - Single Patient Plate 10 LED - Blend1 24 Switch - Patient Plate Single/Dual Mode Selection 11 Switch - Cut Mode Selection 25 LED - Dual Patient Plate 12 LED - Blend2 13 LED - Blend3 Heal Force EB03... -
Page 8: Accessories Receptacles
3 Foot-switch Pencil Forceps receptacle 5 CF type control fibrillation equipment 6 Polar plate receptacle 7 Full suspension tuned balance output Rear Panel receptacle Power supply receptacle Fuse Grounding pole Foot Switch receptacle Volume potentiometer Argon gas control Heal Force EB03... -
Page 9: Accessories
● Step on cut pedal ①，the cut end a of the plug ③ is communicated with common end c ● Step on coag pedal ②, the coag end b of the plug ③ is communicated with common end c Heal Force EB03... - Page 10 Operation manual Plate Cord Dual Soft Patient Plate Single Soft Patient Plate Forceps Forceps Cord Heal Force EB03...
-
Page 11: Preparation Before Operation
Then the patient plate is evenly attached to the patient skin. If the patient plate cord is disconnected during the operation, the alarm LED of the machine will illuminate, the alarm sound will be heard when activation, and the power output will be interrupted. Heal Force EB03... - Page 12 Operator must re-attach the plate properly to patient skin so as to go on operating. Power On Turn on the power switch, and the machine type and version number will be displayed. The machine goes into the last using setting immediately (i.e. mode setting and power setting). Heal Force EB03...
-
Page 13: Operations During The Operation Process
750HZ will be sent; when coag is activated, the LED for coag startup will illuminate and the sound with 250HZ will be sent. The hand control pencil and foot control pencil can not be used at the same time because they share one output channel. Stop Operating Heal Force EB03... -
Page 14: Maintenance After Operation
● Open the top cover of the fuse unit by a screwdriver. ● Select two fuse units of the same model and insert them into the socket. ● Reinstall the top cover of the fuse unit by a screwdriver. Heal Force EB03... -
Page 15: Safety Instruction
200W. If the required setting output of a special operation is much higher than general operation, please check the installation of the patient plate, the condition of the patient plate and the cord, the machine state, and Heal Force EB03... - Page 16 ● The accessories, including hand control pencil, foot control pencil and patient plate, are consumable components which need to be check for working condition before operating to prevent burns caused by false operation. ● Precautions to the burns of High frequency patient plate Heal Force EB03...
- Page 17 B. The main reason is that several parts on the patient body come in contact with the ground. For example: a. The patient’s body may have more than two points touching the iron bed which is placed on the cement ground; Heal Force EB03...
- Page 18 (patient plate and electrode cable including plug socket and the convert plug) outside the machine All High Frequency Surgical Units supplied by our company have passed safety tests and are in compliance with the national standards. Heal Force EB03...
-
Page 19: Technical Parameters
2400 Blend 3 2900 Soft coag 3600 Spot coag 4600 100% Bipolar coag Curve showing the set power and actual power for every mode a) Pure cut 50 100 150 200 250 300 350 400 450 Setting Heal Force EB03... - Page 20 Operation manual 100 150 200 250 300 350 Setting b) Blend 1 Setting c) Blend 2 100 120 140 160 Setting d) Blend cut3 Heal Force EB03...
- Page 21 Operation manual Setting e) Soft coag Setting f) Spot coag Setting g) Bipolar coag Heal Force EB03...
-
Page 22: Load Power Curve For Each Mode
1、Pure cut Pure cut 175W 350W 334.625 207.5 169.75 150.875 169.5 162.125 83.875 1000 2000 Load（Ω） 2、Blend 1 150W Blend 1 300W 286.75 182.5 135.75 148.75 103.25 67.5 1000 2000 Load （Ω） Heal Force EB03... - Page 23 Load （Ω） 4、Blend 3 Blend 3 150W 147.25 123.75 87.25 43.5 65.875 74.5 70.125 66.125 42.25 1000 2000 Load（Ω） 5、Soft coag Soft coag 100W 97.375 86.375 76.625 59.75 51.5 43.75 50.625 41 28.625 26.25 1000 2000 Load （Ω） Heal Force EB03...
- Page 24 Operation manual 6、Spot coag Spot coag 100W 96.125 98 90.25 50.875 50.25 47.5 45.25 38.875 37.125 1000 2000 Load （Ω） 7、Bipolar coag Bipolar coag 49.875 35.75 34.625 26.125 24.875 20.5 15.75 11.5 6.75 Load（Ω） Heal Force EB03...
- Page 25 Operation manual Curve on output power and voltage peak value for each mode 1600 1400 1200 1000 P(W) a.Pure cut 3000 2500 2000 1500 1000 P（W） b.Blend 1 2500 2000 1500 1000 P(W) c.Blend 2 Heal Force EB03...
- Page 26 Operation manual 4000 3500 3000 2500 2000 1500 1000 P(W) d.Blend 3 4000 3500 3000 2500 2000 1500 1000 P(W) e.Soft coag Heal Force EB03...
- Page 27 Operation manual 5000 4500 4000 3500 3000 2500 2000 1500 1000 P(W) f.Spot coag P(W) g.Bipolar coag Heal Force EB03...
-
Page 28: Safety Indices
● Application appliances available with the equipment: output circuit for surgical electrode and neutral electrode ● Equipment’s protection from discharge effect of defibrillator ● Classified as common equipment ● Operation mode of equipment: Continuous operation with loading in intermittent pattern ● Portable equipment Heal Force EB03... -
Page 29: Description Of Circuit
Main Balance high- Inspectio control resonance frequency Plate n of plate circuit power amplifier Selection Drive of mode circuit Hand Hand- control control/fo pencil ot-control Foot control Current and voltage pencil feedback Mode detection Relay detection Feedback Heal Force EB03... -
Page 30: Block Diagram On Wiring Of Host Machine
Meantime, through the software calculation and compensation, the electrotome is enabled to output the appropriate power under the different impedance to ensure the eletrotome to work in safety and reliability. Heal Force EB03... -
Page 31: Cpu Panel Circuit
T2001 and T2002. Power output circuit may operate with full bridge power amplification circuit structured of 4 VMOS tubes (PMN1160). On the power panel, there are circuits used to restrict short-circuit current and high-frequency drain current. In case of pretty Heal Force EB03... -
Page 32: Circuit Of Output Panel
Circuit of rear panel Rear panel may function to allow NE555 to produce an oscillation and foot control pencil startup signal via coil T7001 and home-made optical coupling O7001 and O7002. Provided on rear panel is also LM386 acoustic circuit. Heal Force EB03... -
Page 33: Maintenance Technology
4. Assess that the exact part of machine inside fails. Troubleshooting on the failure inside the machine require the training. Regular check The user shall carry out some necessary check on performance and safety on a regular basis. Heal Force EB03... - Page 34 Operation manual ● Power check (every half a year) ● Check on low-frequency drain current (every half a year) Drain current to ground〈0.5mA Drain current to patient〈10μA ● Check on high-frequency drain current (every half a year) <150mA Heal Force EB03...
-
Page 35: List Of Common Failure
◆Ground wire of power cable is ◇Correctly connect the ground wire Casing charged not correctly grounded or power of power supply cable or secure the supply wire in the machine is power conducting wire in the detached. machine. Heal Force EB03... -
Page 36: List Of Internal Failure
◇ Replace the power panel ◆ No driving shape of wave for ◇ Replace the output panel power tube ◆ Resonance circuit damaged ◇ Replace the CPU panel ◆ Memory damaged Output power greatly deviated Heal Force EB03... - Page 37 6788 Songze Ave ,Shanghai Qingpu Industrial Zone,PRC China Tel: + 86 21 59867888 Fax: +86 21 59867199 E-mail: lishen@public3.sta.net.cn International sales office: Floor 16th, No.2 West Zhongshan Road, Shanghai 200051,PR China Tel: +86 21 62728646 Fax: +86 21 62728538 E-mail: nisonshh@public.sta.net.cn Website: www.shanghai-lishen.com Heal Force EB03...
