- Page 1 SoundExtreme SE26R Models: GDI-EXSNDXTR01R POWERSPORTS AMPLIFIED SOUNDBAR User Guide...
-
Page 2: Left Side
SoundExtreme Layout Backlit Speakers Control Panel FRONT Backlit Woofer Backlit Woofer LEFT SIDE RIGHT SIDE Auxiliary Power Out 12V Power In SAE SAE Connector (Black) Connector (Red) Light Bar BACK... - Page 3 In/Out Connections USB Charging AUX-IN AUX-OUT Port Port (Black) Port (Gray) Do NOT use these connections if they are wet. AUX-IN: This input can be used to connect a CD player, MP3 player, etc. AUX-OUT: This output can be used to connect to an amplifier or to another speaker AUX-IN connection.
- Page 4 Connecting to 12VDC Power Supply The SoundExtreme does not have an internal battery. It must be connected to an external 12VDC power supply to function. When you install the SoundExtreme to a battery or a voltage regulator on a golf cart, a boat, a quad bike, a UTV, or another vehicle, you need to make sure that your vehicle battery or battery pack terminal voltage is 12VDC.
- Page 5 Installation: Gas Vehicle 1. Loosen the bolts on the battery terminals. Use Caution: Do NOT attempt to loosen bolts if battery is wet. Contact may cause electric shock and injury if wet. 2. Connect the BLACK wire to the Loosen Bolts BLACK, negative terminal, then the RED wire to the RED, positive terminal.
-
Page 6: Control Panel
Controls 1. LED Indicators: Each of the 4 LEDs correspond to different functions: Power, Bluetooth, Mode, and Status. 2. Power Button: Press button to turn the SoundExtreme on / off. 3. Mode Button: Press button to cycle through the following modes: Bluetooth, EcoCast Transmitting, EcoCast Receiving, FM, and AUX-IN. -
Page 7: Led Indicators
Operations LED Indicators From left to right, the 4 LED Indicators correspond to Power, Bluetooth, Mode, and Status. 1. Power Solid Green: Power On No Light: Power Off 2. Bluetooth Flashing Blue: Bluetooth Paring Solid Blue: Bluetooth Connected 3. Mode Solid Blue: Speaker Mode Solid / Flashing Red: EcoCast Transmitting Mode Solid / Flashing Green: EcoCast Receiving Mode... -
Page 8: Pairing A Bluetooth Device
LED Indicator from the left) is not flashing, briefly press start pairing your device. 3. Navigate to your Bluetooth device’s setup screen, find ECOXGEAR and connect. If the connection is successful, the Bluetooth icon will be lit solid and your SoundExtreme will announce “Your phone is connected. ”... - Page 9 Play Music (Bluetooth Mode) After the SoundExtreme is connected to your Bluetooth device, press briefly on the SoundExtreme to play, press again to pause. Press briefly to play previous song. Press briefly to get the next song. Notes: · Pair and connect your Bluetooth device with SoundExtreme before using this feature.
- Page 10 EcoCast – Broadcast Your Music to Multiple Speakers x100 When you have two or more SoundExtreme speakers, you can build a broadcast system by initiating EcoCast Transmitting Mode in one SoundExtreme speaker and broadcasting your music to one or more SoundExtreme speakers in EcoCast Receiving Mode.
- Page 11 Transmitting Mode (Speaker A). If they are not automatically reconnected, please follow the above steps. · You can also pair the SoundExtreme with any other ECOXGEAR speaker bearing the EcoCast symbol · The EcoCast functionality is only available while using Bluetooth as your Audio Source at a maximum range of 30 feet between speakers.
-
Page 12: Accessory Mode
Listening to FM Radio (FM Mode) Press briefly to cycle through to FM Mode. Press briefly to tune in a radio station. To “seek” (jump to the next available station), PRESS AND HOLD either button down for a few seconds until it starts to seek a station. -
Page 13: Pairing Your Remote Control
Remote Control Pairing Your Remote Control Before you use your Remote Control for the first time, pull and remove the plastic tab at the bottom of the Remote Control. Your Remote Control should be paired to your unit. IF NOT paired, please follow the steps below. -
Page 14: Remote Switch
After the SoundExtreme is connected to your Bluetooth device, press briefly to play, press again to pause. Press briefly to play previous song. Press briefly to get the next song. Press briefly to adjust the speaker volume. LED: Backlit Speakers Press briefly to turn on your speaker backlights. - Page 15 Mounting Your Speaker CAUTION: Do NOT install on your own. This installation is a two- person job, to be done safely and to avoid personal injury and / or damage to your vehicle. When mounting the soundbar, it is extremely important to make sure that each mount and the speaker are secure and will not cause any potential issues.
- Page 16 3. Put the appropriate Lower Rubber Inserts onto each of the Bottom Clamps. Then put the matching Upper Rubber Inserts on each of the Top Clamps. Align the rubber groove with the bulge of the Clamps and press firmly to assemble the Clamp and Rubber Inserts.
-
Page 17: Troubleshooting
Troubleshooting The sound is distorted Try lowering the volume control of your connected device or musical instrument. Also, try to reduce the overall volume of the SoundExtreme. Cannot Pair With Bluetooth Device Make sure that your device is compatible with Bluetooth. Turn off your SoundExtreme and Bluetooth device, then power on and reconnect. -
Page 18: Specifications
Specifications Dimensions 4.5 in / 114.3 mm 25.5 in / 647.7 mm 2.1 in / 53 mm 4.6 in / 117 mm 5.25 in / 133 mm Unit Weight Modulation 11 lbs GFSK, π/4-DQPSK, 8DPSK Mount Weight Bluetooth Range 0.75 lbs (each) Up to 100 ft / 30m Replacement Mounts Tweeter (2x) - Page 19 Audio Output Power 500W (peak) Power Supply Input Voltage: 12VDC, 10A (requires connection to external DC battery for power) USB Output 5V, 2.1A EcoCast Using Qualcomm® Broadcast Audio technology EcoCast Range 30 ft / 9.1 m between Casting speaker and Receiving speakers Compatibility Mobile phone / device supporting Bluetooth V1.1 (and above)
- Page 20 1.) Use the ECOXGEAR speaker in accordance with any music or noise rules and regulations. 2.) Properly seal the ECOXGEAR prior and after each use when in humid or water environments to avoid water damage to the internal components. Salt water / air is particularly corrosive. Always make sure that the gaskets are sealed when in a salt water environment and that the unit is properly rinsed off after use.
- Page 21 4.) Store your unit with all caps properly sealed to avoid long term internal moisture damage inside your unit. 5.) Return the ECOXGEAR to Grace Digital if you suspect water ingress into the unit or if the unit has experienced a severe impact that may have affected the integrity of the unit to take on water.
- Page 23 PLAY IT LOUD!
-
Page 24: What's In The Box
What’s in the Box SoundExtreme Speaker 8ft Power Cable SoundExtreme SE26R Models: GDI-EXSNDXTR01R POWERSPORTS AMPLIFIED SOUNDBAR Auxiliary Power Out Mating Connector User Guide (4x) 1/4-20 Flat Washers SoundExtreme SoundExtreme User Guide Remote Control (4x) 1/4-20 x 0.75” (6x) M6 Spring...
