Installation Instructions

Fiber Connection Cabinet

FCC6

Instruction notes for retrofit kits included.

Note also the attached instructions, data sheets and supplementary notes.

These products may be protected by one or

more patents. For further information, please

www.belden.com

visit: www.ppc-online.com/patents

Kitzingstr. 1-5, 12277 Berlin, Germany

info@sichert.com

+49 30 74707-0

1/56

www.sichert.com

Need help?

Do you have a question about the SICHERT FCC6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Belden SICHERT FCC6

Page 1 Note also the attached instructions, data sheets and supplementary notes. Note also the attached instructions, data sheets and supplementary notes. These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 1/56...
Page 2 Replacement of the cabinet 48...49 Order data 50...54 Disassembly and disposal information Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 2/56...
Page 3 Only when the manual is understood and adhered to can danger be avoided. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 3/56...
Page 4 (all dimensions in mm) Ground level Connecting dimensions (plinth - cabinet) R=6.5 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 4/56...
Page 5 Door with swivel handle for lock cylinder (according to DIN 18252) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 5/56...
Page 6 Base plate for micro ducts (max. 72 OUT) and cables Plinth version with strain relief rail (c rail) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 6/56...
Page 7 Screw for lock cylinder Double locking system: Dummy cylinder Emergency key Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 7/56...
Page 8 Plinth version with strain relief rail strain relief rail (c rail) (c rail) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 8/56...
Page 9 Screw for lock cylinder Double locking system: Dummy cylinder Emergency key Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 9/56...
Page 10 (strength class A2-70) Screw size Tightening torque values (Nm) 20.6 40.7 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 10/56...
Page 11 4x Ø 50 mm 4x Ø 50 mm Optional: cable entry on side Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 11/56...
Page 12 Ground level Predetermined Predetermined breaking points breaking points Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 12/56...
Page 13 Connect cabinet and plinth with the screw kit (delivered with plinth). Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 13/56...
Page 14 Cover (accessory) for upper plinth section during the construction phase. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 14/56...
Page 15 Use the supplied screw only! Observe locking system manufacturer‘s notes. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 15/56...
Page 16 Strain relief for ducts Matrix (Suggestion) of base plate Ø 12...20 mm Loop Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 16/56...
Page 17 12 11 10 9 8 7 6 5 4 3 2 1 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 17/56...
Page 18 Strain relief for ducts Matrix (Suggestion) of base plate Ø 12...20 mm Loop Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 18/56...
Page 19 12 11 10 9 8 7 6 5 4 3 2 1 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 19/56...
Page 20 Secure the cable to the strain relief plate with a cable tie. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 20/56...
Page 21 Overlength storage for loose tubes / loop (Included in version for overlength storage) Hook-and-loop tape Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 21/56...
Page 22 Hook-and-loop tape Routing of loose tubes Splice area Splice area Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 22/56...
Page 23 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 23/56...
Page 24 Upgrade kit: Ground rod holder Ground rod holder Ø 8...10 mm Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 24/56...
Page 25 Place the end plate after mounting all the grippers. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 25/56...
Page 26 Cable fixing and routing: page 20 see page et sqq. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 26/56...
Page 27 Note the installation instructions for the plinth. BK 46 (Ø 42...36 mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 27/56...
Page 28 Size of gripper on the top. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 28/56...
Page 29 17 To the fiber tray area: page 32 et sqq. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 29/56...
Page 30 Size of gripper on the top. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 30/56...
Page 31 19 To the fiber tray area: page 32 et sqq. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 31/56...
Page 32 The cover serves the protection of the fiber trays. (with key as option) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 32/56...
Page 33 Upgradable or in some versions: Fiber crossing bridge Fiber entry part Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 33/56...
Page 34 Retrofiting or replacement of strain relief block (Dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 34/56...
Page 35 Distribution cable Main cable Splitter out Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 35/56...
Page 36 Side A Side B Distribution cable Main cable Splitter out Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 36/56...
Page 37 Side A Side B Distribution cable Main cable Splitter out Collocation Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 37/56...
Page 38 Material: PC/ABS, light grey Material: PC/ABS, RAL 7035 (Dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 38/56...
Page 39 (up to 7x per side) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 39/56...
Page 40 (up to 7x per side) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 40/56...
Page 41 + 4x heat shrink splice protector 1.6 mm Material: PC/ABS, RAL 7035 (Dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 41/56...
Page 42 Note the markings. Install SE trays to each second position only. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 42/56...
Page 43 ~ 90 37...45° 37...45° Self-locking Self-locking Self-locking Self-locking 37...45° 37...45° Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 43/56...
Page 44 Ensure that the fibers are min. . max. max. underneath the hold-down tabs. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 44/56...
Page 45 Fiber routing with crossing (loop PtP) Fiber routing for splicing Splice storage Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 45/56...
Page 46 1:2, 1:4, 1:8, 1:16 2:2, 2:4, 2:8 Splitter Splitter Splitter Splitter Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 46/56...
Page 47 SE tray on 2 levels) Tray lid click click Material: PC transparent Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 47/56...
Page 48 Remove the fiber tray cover and the screws of the mounting plate StVz StVz Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 48/56...
Page 49 Install the new cabinet in reverse order. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 49/56...
Page 50 9x Ø 16 mm, 9x Ø 20 mm + 6x End plate for clip rail Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 50/56...
Page 51 Upgrade kit: Cable routing 75 54.8117.11.05 Two-sided hook-and-loop tape (25 m roll) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 51/56...
Page 52 4x crimp splices CS 4x heat shrink splices HS Tray lid 1x CSS019FS Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 52/56...
Page 53 (pack of 12) (upon request) Tray markers (numbers) (pack of 300, white) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 53/56...
Page 54 Ø 11.1...17.4 mm (10x) 54.0001.15.00 Ø 19.1...23.5 mm (10x) 54.0001.16.00 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 54/56...
Page 55 Please note the applicable disposable guidelines for all products. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 55/56...
Page 56 HS = Heat Shrink, CS = Crimpspleiß, OL = Overlength Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 56/56...
