Installation Instructions
Fiber Connection Cabinet
FCC3
Instruction notes for retrofit kits included.
Note also the attached instructions, data sheets and supplementary notes.
Note also the attached instructions, data sheets and supplementary notes.
These products may be protected by one or
more patents. For further information, please
www.belden.com
visit: www.ppc-online.com/patents
Kitzingstr. 1-5, 12277 Berlin, Germany
info@sichert.com
+49 30 74707-0
1/40
www.sichert.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SICHERT FCC3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Belden SICHERT FCC3

Summary of Contents for Belden SICHERT FCC3

  • Page 1 Note also the attached instructions, data sheets and supplementary notes. Note also the attached instructions, data sheets and supplementary notes. These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 1/40...
  • Page 2 Fiber tray system 25...33 Order data 35...39 Disassembly and disposal information Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 2/40...

  • Page 3: Safety Standards

    Only when the manual is understood and adhered to can danger be avoided. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 3/40...
  • Page 4 Ground level Connecting dimensions (plinth - cabinet) (dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 4/40...

  • Page 5: Technical Data

    Door with swivel handle for lock cylinder (according to DIN 18252) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 5/40...

  • Page 6: Scope Of Supply

    Strain relief for duct bundles and cables Plinth Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 6/40...

  • Page 7: Delivery Condition

    Screw for lock cylinder Double locking system: Dummy cylinder Emergency key Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 7/40...

  • Page 8: Important Notes

    (strength class A2-70) Screw size Tightening torque values (Nm) 20.6 40.7 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 8/40...
  • Page 9 St Vz St Vz (Reinstall in reverse order) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 9/40...
  • Page 10 Ground level 60 cm 60 cm ~ 50 cm 50 cm Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 10/40...

  • Page 11: Locking System

    Use the supplied screw only! Observe locking system manufacturer‘s notes. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 11/40...
  • Page 12 Matrix of base plate Ø 12...20 mm Loop Ø 12...16 mm (Suggestion) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 12/40...
  • Page 13 Matrix of base plate Ø 7 mm + Ø 10 mm (Suggestion) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 13/40...
  • Page 14 Matrix of base plate Ø 12...20 mm Loop Ø 12...16 mm (Suggestion) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 14/40...
  • Page 15 For FCC3-48 only Ø 7 mm + Ø 10 mm (Suggestion) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 15/40...
  • Page 16 Secure the cable to the strain relief plate with a cable tie. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 16/40...
  • Page 17 22 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 17/40...
  • Page 18 Place the end plate after mounting all the grippers. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 18/40...
  • Page 19 Cable fixing and routing: page 16 Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 19/40...
  • Page 20 Close an unused duct with an end cap (accessory) in accordance with the manufacturer‘s instructions. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 20/40...
  • Page 21 22 4 ( F 5 ( F (Layout suggestion) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 21/40...
  • Page 22 Fiber entry part Strain relief block Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 22/40...
  • Page 23 Place fibers in the trays: see Avoid crossing over cables, loose tubes and fibers. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 23/40...
  • Page 24 Distribution cable direct connections trays Distribution cable Main cable Splitter out Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 24/40...
  • Page 25 Material: PC/ABS, light grey Material: PC/ABS, RAL 7035 (Dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 25/40...
  • Page 26 (up to 7x per side) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 26/40...
  • Page 27 (up to 7x per side) or snap marker Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 27/40...
  • Page 28 + 4x heat shrink splice protector 1.6 mm Material: PC/ABS, RAL 7035 (Dimensions in mm) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 28/40...
  • Page 29 Note the markings. Install SE trays to each second position only. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 29/40...
  • Page 30 ~ 90 37...45° 37...45° Self-locking Self-locking Self-locking Self-locking 37...45° 37...45° Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 30/40...
  • Page 31 Ensure that the fibers are min. . max. max. underneath the hold-down tabs. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 31/40...
  • Page 32 Fiber routing with crossing (loop PtP) Fiber routing for splicing Splice storage Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 32/40...
  • Page 33 1:2, 1:4, 1:8, 1:16 2:2, 2:4, 2:8 Splitter Splitter Splitter Splitter Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 33/40...
  • Page 34 SE tray on 2 levels) Tray lid click click Material: PC transparent Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 34/40...

  • Page 35: Order Data

    9x Ø 16 mm, 9x Ø 20 mm + 6x End plate for clip rail Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 35/40...
  • Page 36 Upgrade kit: overlength storage for loose tubes 59.2519.00.02 Flexible conduit Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 36/40...
  • Page 37 4x crimp splices CS 4x heat shrink splices HS Tray lid 1x CSS019FS Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 37/40...
  • Page 38 (pack of 12) (upon request) Tray markers (numbers) (pack of 300, white) Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 38/40...
  • Page 39 Please note the applicable disposable guidelines for all products. Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany info@sichert.com more patents. For further information, please www.belden.com +49 30 74707-0 www.sichert.com visit: www.ppc-online.com/patents 39/40...
  • Page 40 HS = Heat Shrink, CS = Crimpspleiß, OL = Overlength Contents Previous These products may be protected by one or Kitzingstr. 1-5, 12277 Berlin, Germany more patents. For further information, please info@sichert.com www.belden.com visit: www.ppc-online.com/patents +49 30 74707-0 www.sichert.com 40/40...
