Summers 3RT Operator's Manual

Track remover
Hide thumbs

Advertisement

Quick Links

Download this manual
®
Operator's Manual
3RT 2010
(3RT TRACK REMOVER)
CAUTION
READ & UNDERSTAND OPERATOR'S MANUAL BEFORE
OPERATING MACHINE.
See www.summersmfg.com for latest version of all Summers Operator's Manuals.
SUMMERS MANUFACTURING CO., INC.
WEB SITE: www.summersmfg.com
DEVILS LAKE, NORTH DAKOTA 58301
(701) 662-5391
8Z1075
© Summers Mfg. Co., Inc. 2018
8Z1065
© Summers Mfg. Co., Inc. 2018
Printed in USA
Printed in USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3RT and is the answer not in the manual?

Questions and answers

Related Manuals for Summers 3RT

Summary of Contents for Summers 3RT

  • Page 1 Operator’s Manual 3RT 2010 (3RT TRACK REMOVER) CAUTION READ & UNDERSTAND OPERATOR’S MANUAL BEFORE OPERATING MACHINE. See www.summersmfg.com for latest version of all Summers Operator’s Manuals. SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 (701) 662-5391 8Z1075 ©...
  • Page 2 FORWARD Preface This manual is intended for use with 3RT 2010 Track Remover for Summers® Manufacturing Com- pany, Inc. This book is composed of these basic sections: Safety, Operation & Maintenance, Troubleshooting and Parts. The Operation & Maintenance section provides information for the proper operation and maintenance of your Summers Track Remover.

  • Page 3: Warranty

    36 months from the date by the end user from Summers’ dealer. Summers’ obligation is to replace, free of charge, any part of the product that Summers in- spection shows to be defective excluding transportation charges to Devils Lake, ND and return and also excluding all transportation costs from Summers’...
  • Page 4 3. ALWAYS use transport locks when transporting on public roads. 4. COMPLY with local lighting, marking and oversize regulations when transporting on highways. 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 5 Page 4 © Summers Mfg. Co., Inc. 2018...
  • Page 5 7. Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper. Page 6 © Summers Mfg. Co., Inc. 2018 8Z1065 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 5...
  • Page 6 BE SURE PRESSURE IS RELIEVED from hydraulic circuits before servicing or disconnecting • from tractor. USE EXTREME CARE when assembling, servicing or adjusting. • 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 7 Page 6 © Summers Mfg. Co., Inc. 2018 8Z1075...

  • Page 7: Operation Safety

    9. KEEP CHILDREN AWAY from machinery at all times. 10. NEVER ALLOW anyone to walk or work installing cylinder and transport locks. Page 8 © Summers Mfg. Co., Inc. 2018 8Z1065 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 7...

  • Page 8: Operation

    ¼. For additional soil movement see Pages 20 & 21 for changing blade aggresiveness. 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 9 Page 8 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 9 3/4” 1-1/16”* or 1-1/8” 7/8” 1-5/16” 1” 1-1/2” 1193 1-1/4” 1-7/8” 1-1/2” 2-1/4” 2” 3-1/8” 1200 1627 *Nylon Lock Nut 3/8/12 TILLAGE Page 10 © Summers Mfg. Co., Inc. 2018 8Z1065 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 9...
  • Page 10 Page 10 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 11 Maintenance & Specifcations ® 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 11 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 11...
  • Page 12 Maintenance & Specifcations ® Page 12 © Summers Mfg. Co., Inc. 2018 8Z1065 Page 12 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 13 Maintenance & Specifcations ® 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 13 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 13...
  • Page 14 Maintenance & Specifcations ® Page 14 © Summers Mfg. Co., Inc. 2018 8Z1065 Page 14 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 15 Maintenance & Specifcations ® 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 15 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 15...
  • Page 16 Maintenance & Specifcations ® Page 16 © Summers Mfg. Co., Inc. 2018 8Z1065 Page 16 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 17 Maintenance & Specifcations ® 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 17 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 17...
  • Page 18 Page 18 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 19 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 19...
  • Page 20 Parts ® Parts Ordering Procedure When ordering parts for your Summers 3RT Track Remover, please contact an authorized Summers dealer in your area. If the parts are associated with a possible warranty claim, make sure that you con- tact the original dealer from which you purchased the Summers implement.
  • Page 21 8X0260 8J2252NL 8X0265 8J2252NR 8X0266 8J2272NR 8X0280 8J3236 8X0306 8J3276 8X0309 8K4200 8X0318 8K4210 8X0492 8K4220 8X0500 9B1508.iam/ 4/17/2018 3RT TRACK REMOVER 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 19 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 21...
  • Page 22 8D5214 8K4400 8K4922S 8X0118 8X0119 8X0122 8X0260 8X0265 8X0306 12° POSITION 8° POSITION 5° POSITION 3 RT TRACK REMOVER TWIN DISK 4/17/2018 Page 20 © Summers Mfg. Co., Inc. 2018 8Z1065 Page 22 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 23 8K4400 8K4922S 8X0118 8X0119 8X0122 8X0260 8X0265 8X0306 5° POSITION 8° POSITION 12° POSITION 4/17/2018 3RT TRACK REMOVER TWIN DISK - LEFT 8Z1065 © Summers Mfg. Co., Inc. 2018 Page 21 8Z1075 © Summers Mfg. Co., Inc. 2018 Page 23...
  • Page 24 8K4019 8K2120 8K5200 8X0366 8X0320 8X0292 8J3010 8X0202 8K4009 CUTTING EDGE TO RIGHT 8J1020N GANG 5 BLADE - LFT AND RGHT 4/17/2018 Page 22 © Summers Mfg. Co., Inc. 2018 8Z1065 Page 24 © Summers Mfg. Co., Inc. 2018 8Z1075...
  • Page 25 2004 - A 124 ft. x 310 ft. addition is added onto the current Devils Lake plant. 2005 - The Summers Superroller is added to the “Field Tested Tough” product line. Additional sizes of 56’, 58’ and 60’ are added to the Superchisel line.
  • Page 26 ® . . . Field Tested TOUGH! Tillage Cultivators/Harrows Rock Picker Mounted Attachments Land Rollers/Packers Sprayers 1-800-732-4347 • www.summersmfg.com...
