Operator's Manual

SFX1630 & SFX2430

(Spray Fill Xpress)

CAUTION

READ & UNDERSTAND OPERATOR'S MANUAL BEFORE

OPERATING MACHINE.

See www.summersmfg.com for latest version of all Summers Operator's Manuals.

SUMMERS MANUFACTURING CO., INC.

WEB SITE: www.summersmfg.com

DEVILS LAKE, NORTH DAKOTA 58301

(701) 662-5391

8Z1105

Printed in USA

Table of Contents

Need help?

Do you have a question about the SFX1630 and is the answer not in the manual?

Questions and answers

Summary of Contents for Summers SFX1630

Page 1 SFX1630 & SFX2430 (Spray Fill Xpress) CAUTION READ & UNDERSTAND OPERATOR’S MANUAL BEFORE OPERATING MACHINE. See www.summersmfg.com for latest version of all Summers Operator’s Manuals. SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 (701) 662-5391 8Z1105 ©...
Page 2 Publish Date: 11/20/2018...
Page 3: Table Of Contents
Daily & Periodic Maintenance ..................... 17 Storage ............................17 Specifications ..........................18 SECTION 5 - PARTS LIST ......................19 SFX1630 Base Frame ........................ 20 SFX1630 Plumbing ........................22 SFX1630 Tanks .......................... 24 SFX2430 Base Frame ........................ 26 SFX2430 3 Tank Components ....................28 SFX2430 4 Tank Components ....................
Page 4 TABLE OF CONTENTS Mounting Package ........................38 Scale & Mounting Package ......................40 Transfer Pump Package ......................42 Decals ............................44 Part Numbers with Descriptions....................46 Page 4 © Summers Mfg. Co., Inc. 2018 8Z1105...
Page 5: Forward
FORWARD Preface This manual is intended for use with SFX1630 & SFX2430 Spray Fill Xpress for Summers® Manu- facturing Company, Inc. This book is composed of these basic sections: Safety, Operation & Maintenance, Troubleshooting and Parts. The Operation & Maintenance section provides information for the proper operation and maintenance of your Summers Spray Fill Xpress.
Page 6: Warranty
36 months from the date by the end user from Summers’ dealer. Summers’ obligation is to replace, free of charge, any part of the product that Summers in- spection shows to be defective excluding transportation charges to Devils Lake, ND and return and also excluding all transportation costs from Summers’...
Page 7: Section 1 Safety
3. ALWAYS use transport locks when transporting on public roads. 4. COMPLY with local lighting, marking and oversize regulations when transporting on highways. 5. FREQUENTLY check for traffic from rear, especially during turns. 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 7...
Page 8: Safety Decals
6. Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign in place. 7. Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper. Page 8 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 10: Spray Fill Xpress Safety Decal Locations
Safety ® 8F8140.iam/ 2/18/2016 SFX2430 DECALS Page 10 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 11 PROUDLY MADE IN THE U.S.A. WWW.SUMMERSMFG.COM 8Z2508 18” SFX1630 DECAL 8Z2510 18” SFX2430 DECAL 8Z2513 24” SFX1630 DECAL 8Z2515 24” SFX2430 DECAL 8Z2518 36” SFX1630 DECAL 8Z2520 54” SFX2430 DECAL ® 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 11...
Page 12: General Maintenance Safety Practices
• BE SURE PRESSURE IS RELIEVED from hydraulic circuits before servicing or disconnecting from tractor. • USE EXTREME CARE when assembling, servicing or adjusting. Page 12 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 13: Section 2 - Operation Safety
8. USE EXTREME CARE when making adjust- ments. 9. KEEP CHILDREN AWAY from machinery at all times. 10. NEVER ALLOW anyone to walk or work under a raised piece of equipment without installing cylinder and transport locks. 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 13...
Page 15: Section 3 - Operation
Do not use the Spray Fill Xpress if it is not prop- 8. Repeat 4 & 5 as required to make recipe. erly secured to application. Do not exceed the maximum pressure of 75 psi when using the Spray Fill Xpress. 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 15...
Page 16: Getting Ready For Transfer
1. Close and secure lid. 2. Secure any loose chemical containers. 3. FOLLOW ALL local laws governing trans- porting of farm machinery. 4. Stay clear of overhead lines and other over- head obstructions. Page 16 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 17: Section 4 - Maintenance & Specifications
Operation 1. Check all plumbing components for leaks. 2. Check for any lose or missing fasteners. 3. Check engine oil and fuel levels. 4. Check valves operation and conditions. 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 17...
Page 18: Specifications
Scale Capacity 2500 lbs. 13 HP Engine with 3” pump Max GPH - 440 Max PSI - 54 8F8115 - 2 Compartment (SFX1630) Weight - 945 lbs. 8F8125 - 3 Compartment (SFX1630) Weight - 1003 lbs. 8F8135 - 4 Compartment (SFX1630) Weight - 1065 lbs.
Page 19: Section 5 - Parts List
Parts ® Parts Ordering Procedure When ordering parts for your Summers Spray Fill Xpress, please contact an authorized Summers dealer in your area. If the parts are associated with a possible warranty claim, make sure that you con- tact the original dealer from which you purchased the Summers implement.
Page 20: Sfx1630 Base Frame
Parts ® DETAIL B 2/20/2017 8F8125.iam/ 160GAL SFX 3 HPPR Page 20 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 21 NUT 5/16"-18NC NY-LOCK GR2 ZDI 8X0242 NUT 1/2"-13NC NY-LOCK GR2 YZ 8X0319 WASHER 17/32"IDX7/8ODX16GA ZDI 8X0320 WASHER 3/8" (7/16" ID)FLAT ZDI 8X1112 CRG 3/8-16NC X 1" SS 8X1113 CRG 3/8-16NC X 1.5" SS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 21...
Page 22 Parts ® 2 & 3 4 HOPPER HOPPER ONLY ONLY 8F8125.iam/ 11/15/2018 160GAL SFX 3 HPPR Page 22 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 23: Sfx1630 Plumbing
HYPRO 3" UNIVERSAL FLANGE CLAMP 8A2387 FLANGE GASKET 3" HYPRO 8F6134 FLANGEPIPE 3 X 33.75" SS304 8F6150 FLANGEPIPE 3 X 50.06" SS304 8X0046 BOLT 7/16-14NC X 7-1/4"GR5 ZDI 8X0234 NUT 7/16"-14NC NY-LOCK GR2 ZDI 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 23...
Page 24 Parts ® NOTE: PARTS REMOVED FOR CLEAR VIEW. 8F8125.iam/ 160GAL SFX 3 HPPR 7/20/2016 Page 24 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 25: Sfx1630 Tanks
8A2508A BOTTLE RINSE PLUNGER HYPRO 8A2508B BOTTLE RINSE NOZZLE HYPRO 8A4008 HOSE 1/2" EPDM AG 200PSI BLACK 8F0420 SEAL RUBBER TRIM LOC 15- 8F6040 CHEMTANK SS 40GAL 8F6080 CHEMTANK SS 80GAL 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 25...
Page 26: Sfx2430 Base Frame
Parts ® DETAIL A 8F8130.iam/ BASE UNIT 2/20/2017 Page 26 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 27 NUT THIN 10 X 24 NY-LOCK SS 8X0212 NUT 5/16"-18NC NY-LOCK GR2 ZDI 8X0242 NUT 1/2"-13NC NY-LOCK GR2 YZ 8X0319 WASHER 17/32"IDX7/8ODX16GA ZDI 8X0320 WASHER 3/8" (7/16" ID)FLAT ZDI 8X1112 CRG 3/8-16NC X 1" SS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 27...
Page 28: Sfx2430 3 Tank Components
Parts ® 3 TANK PLUMBING DETAIL A DETAIL C DETAIL B 8F8130.iam/ 12/15/2015 3 COMPARTMENT PLUMBING Page 28 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 29 8F0420 SEAL RUBBER TRIM LOC 15- 8F6080 CHEMTANK SS 80GAL 8F6156 FLANGEPIPE 3X56" SS304 8F6172 FLANGEPIPE 3X72.35" SS304 8X0200 NUT 3/8"-16NC SERFLANG GR2 YZ 8X1112 CRG 3/8-16NC X 1" GR2 ZN 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 29...
Page 30: Sfx2430 4 Tank Components
Parts ® 4 TANK PLUMBING DETAIL B DETAIL A 8F8140.iam/ 4 TANK PLUMBING 1/21/2016 Page 30 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 31 FLANGEPIPE 3X56" SS304 8F6172 FLANGEPIPE 3X72.35" SS304 8X0046 BOLT 7/16-14NC X 7-1/4"GR5 ZDI 8X0200 NUT 3/8"-16NC SERFLANG GR2 YZ 8X0234 NUT 7/16"-14NC NY-LOCK GR2 ZDI 8X1112 CRG 3/8-16NC X 1" SS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 31...
Page 32: Sfx2430 5 Tank Components
Parts ® 5 TANK PLUMBING DETAIL B DETAIL A 8F8150.iam/ 5 TANK PLUMBING 2/1/2016 Page 32 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 33 FLANGEPIPE 3X56" SS304 8F6172 FLANGEPIPE 3X72.35" SS304 8X0046 BOLT 7/16-14NC X 7-1/4"GR5 ZDI 8X0200 NUT 3/8"-16NC SERFLANG GR2 YZ 8X0234 NUT 7/16"-14NC NY-LOCK GR2 ZDI 8X1112 CRG 3/8-16NC X 1" SS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 33...
Page 34: Sfx2430 6 Tank Components
Parts ® 6 TANK PLUMBING DETAIL A DETAIL B 1/18/2017 8F8160.iam/ 6 TANK PLUMBING Page 34 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 35 FLANGEPIPE 3X56" SS304 8F6172 FLANGEPIPE 3X72.35" SS304 8X0046 BOLT 7/16-14NC X 7-1/4"GR5 ZDI 8X0200 NUT 3/8"-16NC SERFLANG GR2 YZ 8X0234 NUT 7/16"-14NC NY-LOCK GR2 ZDI 8X1112 CRG 3/8-16NC X 1" SS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 35...
Page 36: Sfx2430 Side Plumbing
Parts ® 8F8130.iam/ 11/26/2018 SIDE PLUMBING Page 36 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 37 8A2380 1" UNIVERSAL FANGE CLAMP 8A2381 FLANGE GASKET 1" HYPRO 8A2384 HYPRO 2" UNIVERSAL FLANGE CLAMP 8A2385 FLANGE GASKET 2" HYPRO 8A2386 HYPRO UNIVERSAL FLANGE CLAMP 8A2387 FLANGE GASKET 3" HYPRO 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 37...
Page 38: Mounting Package
Parts ® MOUNTING PACKAGE 8F6190.iam/ 12/9/2015 MOUNTING PACKAGE Page 38 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 39 ® MOUNTING PACKAGE ITEM PART NUMBER DESCRIPTION 8F0430 SPRAY FILL MOUNTING PIN PLTD 8F6180 WEIGHT SUPPORT BRACKET 8X0016A 3/8 - 16 x 3.5" SS bolt 8X0202 NUT 3/8"-16NC NY-LOCK GR2 YZ 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 39...
Page 41: Scale & Mounting Package
3/8 - 16 x 3.5" SS bolt 8X0161 SCREW SKT HD 10 X 24 X 1" SS 8X0202 NUT 3/8"-16NC NY-LOCK GR2 YZ 8X0207 NUT THIN 10 X 24 NYLOCK SS 8A1840 FLOWMETER MINI-BULTK 1” 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 41...
Page 42: Transfer Pump Package
Parts ® 13 HP TRANSFER PUMP PACKAGE PN 1 - SEAL KIT 7/28/2017 8F8020.iam/ 13HP TRANSFER ENGINE PKG 15- Page 42 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 43 8F7900A SKID ENGINE MOUNTING 8X0093 BOLT 5/8-11NC X 2" GR5 YZ 8X0168 SCRW TORXTAMPPRF5/16-18X2"ZDI 8X0212 NUT 5/16"-18NC NY-LOCK GR2 ZDI 8X0250 NUT 5/8"-11NC HEX GR2 YZ 8X0304 LOCKWASHER 5/8" YLW ZNC 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 43...
Page 45 DECAL PATENT PENDING 1.25X3” 8Z0100 DECAL MADE IN USA 8Z2508 DECAL 18” SFX1630 8Z2510 DECAL 18” SFX2430 8Z2513 DECAL 26” SFX1630 8Z2515 DECAL 26” SFX2430 8Z2518 DECAL 36” SFX-SUMMERS 8Z2520 DECAL 54” SFX-SUMMERS 8Z1105 © Summers Mfg. Co., Inc. 2019 Page 45...
Page 46 DECAL 26” SFX1630 8A2385 FLANGE GASKET 2” HYPRO 8Z2515 DECAL 26” SFX2430 8A2386 HYPRO 3” UNIVERSAL FLANGE CLAMP 8Z2518 DECAL 36” SFX-SUMMERS 8A2387 FLANGE GASKET 3” HYPRO 8Z2520 DECAL 54” SFX-SUMMERS Page 46 © Summers Mfg. Co., Inc. 2019 8Z1105...
Page 47 2004 - A 124 ft. x 310 ft. addition is added onto the current Devils Lake plant. 2005 - The Summers Superroller is added to the “Field Tested Tough” product line. Additional sizes of 56’, 58’ and 60’ are added to the Superchisel line.
Page 48 ® . . . Field Tested TOUGH! Tillage Cultivators/Harrows Rock Picker Mounted Attachments Land Rollers/Packers Sprayers 1-800-732-4347 • www.summersmfg.com...
