Summers DT9530 Operator's Manual

Disk models

Hide thumbs

page of 82

/ 82
Bookmarks

Quick Links

Download this manual

DISK MODELS

IMPORTANT

THE OPERATOR IS RESPONSIBLE

FOR ADJUSTING THE MACHINE SINCE

MACHINE DOES NOT COME "FIELD

READY" FROM FACTORY.

See www.summersmfg.com for latest version of all Summers Operator's Manuals.

SUMMERS MANUFACTURING CO., INC.

DEVILS LAKE, NORTH DAKOTA 58301

8Z1091

Operator's

DT9530 &

WEB SITE: www.summersmfg.com

Manual

DK9630

CAUTION

READ & UNDERSTAND OPERATOR'S

MANUAL BEFORE USING MACHINE.

(701) 662-5391

Printed in USA

Need help?

Do you have a question about the DT9530 and is the answer not in the manual?

Questions and answers

Summary of Contents for Summers DT9530

Page 1 MACHINE DOES NOT COME “FIELD READ & UNDERSTAND OPERATOR’S READY” FROM FACTORY. MANUAL BEFORE USING MACHINE. See www.summersmfg.com for latest version of all Summers Operator’s Manuals. SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 (701) 662-5391 8Z1091 ©...
Page 2 36 months from the date of purchase by the end user from Summers’ dealer. Summers’ obligation is to replace free of charge any part of any product that Summers inspection shows to be defective excluding transportation charges to Devils Lake, ND and return and also excluding all transportation costs from Summers’...
Page 3 DIAMOND DISK & DT9530. A complete parts breakdown is provided in the Parts Section. Parts are referenced in each drawing with the Summers Manufacturing Part Number. Use this Part Number when ordering replacement parts from your Summers dealer. See back section of manual for description of each Part Number.
Page 4 TABLE OF CONTENTS SECTION 1 - SAFETY Safety-Alert Symbol & General Safety Practices....................1-1 Safety Decals ..............................1-2 - 1-8 SECTION 2 - ASSEMBLY General Assembly Safety Practices ........................2-1 General Assembly - All Units ........................2-2 – 2-3 16’ Units ..............................2-4 – 2-10 21’...
Page 5 SECTION 1 - SAFETY SAFETY-ALERT SYMBOL This symbol is used to denote possible danger and care should be taken to prevent bodily injury. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Definition of each Signal Word used in conjunction with the Safety-Alert symbol. DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Page 6 SAFETY SAFETY DECALS A. KEEP SAFETY DECALS CLEAN. B. REPLACE missing or unreadable decals. New decals are available from your Summers dealer by ordering correct part number (PN) located on decal. C. Locations shown on Page 1-6. 1. TRANSPORT LOCK WARNING DECAL (PN 8Z0075) WARNING REMOVE TRANSPORT LOCK(S) BEFORE LOWERING MACHINE.
Page 7 SECTION 1 - SAFETY 4. INSTALLING CYLINDER LOCKS DECAL (PN 8Z0342) WARNING TO AVOID INJURY INSTALL CYLINDER LOCKS BEFORE TRANSPORTING OR SERVICING MACHINE. 8Z0342 5. STAYING CLEAR OF WINGS DECAL (PN 8Z0344) DANGER TO AVOID INJURY OR DEATH STAND CLEAR OF MACHINE WHEN WINGS ARE BEING RAISED AND LOWERED.
Page 8 • Stay away from frame hinge area when folding wings. • Keep others away. • Do not fold wings when bystanders are present. 8Z0087 8. SUMMERS DECAL (8Z0204) ® 9. GANG BEARING GREASE (PN 8Z0350) IMPORTANT *GREASE GANG BEARINGS EVERY 20 HOURS.* GREASE AT MID DAY OR END OF DAY WHEN BEARINGS ARE AT OPERATING TEMPERATURE.
Page 9 12. RED REFLECTOR (PN 8Z0810) 13. DK9630 DECAL (8Z2255) 13. DT9530 DECAL (8Z2290) SAFETY LIGHT OPERATION The Summers Safety Light Kit is equipped with a 7 pin connector. To protect 7 pin connector, store in dust cap (8K8067) when not attached to towing vehicle.
Page 10 SECTION 1 - SAFETY...
Page 11 SECTION 1 - SAFETY Front Left Caster Rear Lights Rear Center Rear...
Page 12 SECTION 1 - SAFETY Front Rear Coulter Gang Hyd. Valve Side View Rear View...
Page 13 SECTION 2 - ASSEMBLY GENERAL ASSEMBLY SAFETY PRACTICES BLOCK UP ANY RAISED PART YOU ARE RESPONSIBLE of the machine. Be sure machine for the safe assembly of the is stable after blocking. machine. ALWAYS INSPECT LIFTING DO NOT ALLOW CHILDREN CHAINS AND SLINGS for or other unauthorized persons damage or wear.
Page 14 SECTION 2 - ASSEMBLY ASSEMBLY INSTRUCTIONS FOR 16 FT. - 28.5 FT. Refer to illustrations and follow these steps when assembling. The machine should be placed in an area that allows ample room for assembly in the field position. CAUTION: For safety purposes, always block equipment while working on it. MAIN FRAME: Refer to pages 2-4 thru 2-28 and Parts Section when assembling main frame.
Page 15 SECTION 2 - ASSEMBLY WING LIFT HYDRAULIC SYSTEM Refer to page 4-5 or 4-6 when assembling the wing lift system. Mount lift cylinders to adjustment bolts and route hoses as shown. NOTE: CYLINDER PORTS MUST BE FACING DOWN. Fill lift cylinders with oil before attaching lift linkage. Position adjustment bolts by starting end nuts so they are flush with bolt.
Page 16 SECTION 2 - ASSEMBLY...
Page 17 SECTION 2 - ASSEMBLY...
Page 18 SECTION 2 - ASSEMBLY...
Page 19 SECTION 2 - ASSEMBLY...
Page 20 SECTION 2 - ASSEMBLY...
Page 21 SECTION 2 - ASSEMBLY...
Page 22 SECTION 2 - ASSEMBLY 2-10...
Page 23 SECTION 2 - ASSEMBLY 2-11...
Page 24 SECTION 2 - ASSEMBLY 2-12...
Page 25 SECTION 2 - ASSEMBLY 2-13...
Page 26 SECTION 2 - ASSEMBLY 2-14...
Page 27 SECTION 2 - ASSEMBLY 2-15...
Page 28 SECTION 2 - ASSEMBLY 2-16...
Page 29 SECTION 2 - ASSEMBLY 2-17...
Page 30 SECTION 2 - ASSEMBLY 2-18...
Page 31 SECTION 2 - ASSEMBLY 2-19...
Page 32 SECTION 2 - ASSEMBLY 2-20...
Page 33 SECTION 2 - ASSEMBLY 2-21...
Page 34 SECTION 2 - ASSEMBLY 2-22...
Page 35 SECTION 2 - ASSEMBLY 2-23...
Page 36 SECTION 2 - ASSEMBLY 2-24...
Page 37 SECTION 2 - ASSEMBLY 2-25...
Page 38 SECTION 2 - ASSEMBLY 2-26...
Page 39 SECTION 2 - ASSEMBLY 2-27...
Page 40 SECTION 2 - ASSEMBLY 2-28...
Page 41 SECTION 3 - OPERATION & MAINTENANCE START-UP AND HYDRAULIC OPERATION INITIAL START UP PROCEDURE FOR DISK LIFT them in the storage positions. After wings are lowered, extend cylinders fully. HYDRAULIC CYLINDERS BEFORE INITIAL OPERATION This disk has a Master-Slave Hydraulic Lift System. Fully extend hydraulic cylinders and maintain hydraulic pressure for 30 seconds to insure all air is purged from system.
Page 42 SECTION 3 - OPERATION & MAINTENANCE FIELD OPERATION The following procedure should be used for field operation of your Summers Diamond Disk & DT9530. 1. Remove wing safety lock pins and transport locks and place in their storage positions. 2. Lower wings for field operation.
Page 43 If this occurs, run rear coulter gang hydraulic circuit in Float Position Only until cause of overheating is resolved. Contact your Summers Dealer for troubleshooting information. Damage caused by overheating of tractor hydraulic system is not covered by Summers warranty.
Page 44 SECTION 3 - OPERATION & MAINTENANCE TRANSPORTING The Summers Diamond Disk & DT9530 are equipped with 5. Check wheel bolts / nuts after first 20 miles of road manual wing and center lift cylinder locks. The following transport and every 60 miles there after.
Page 45 SECTION 3 - OPERATION & MAINTENANCE TROUBLESHOOTING NO. PROBLEM CAUSE CORRECTION Leaving center valley Rear gangs cutting too deep. Level disk using threaded adjustment bolts above each cylinder/wheel assembly. Diamond Disk - Install additional 2 8K5025N blades at rear center. Gangs plugging.
Page 46 SECTION 3 - OPERATION & MAINTENANCE PROPER BOLT USE DO NOT use these values if a different torque value or tightening procedure is given for a specific applica- tion. Torque values listed are for general use only. Check tightness of fasteners periodically. BOLT SIZE WRENCH SIZE GRADE 5...
Page 47 SECTION 4 - PARTS BRING OWNER REGISTER INFORMATION LOCATED AT THE BEGINNING OF THIS MANUAL WHEN ORDERING PARTS (SERIAL NUMBER IS LOCATED AT FRONT OF DISK BY HITCH PIECE).
Page 48 SECTION 4 - PARTS...
Page 49 SECTION 4 - PARTS 8K1423 (21') 8K1422 (25' & 28 1/2') SHOWN 8D9110 8X0140 8K1470 1 X 7" 8K1452 8K1417 8X0309 1" LW 8K1425 8X0280 8K1615 1" N 8K1440 8K1415 8X0121 3/4" X 6-1/2" 8X0266 DETAIL A 3/4" FN 8X0260 8CC6018 3/4"...
Page 50 SECTION 4 - PARTS 8T3620 8X0044 7/16" X 3-1/2" 8K1920 8X0234 7/16" LNUT 8K1900 8X0072 1/2" X 3-3/4" 8K1152 8K1105S 8T4132 8K7042 8X0242 NY-LOCK 1/2" N 8X0320 3/8" FW 8X0202 3/8" LN 8K5200 8K9230 8X0015 3/8" X 3 3/4" 8X0292 2"...
Page 51 SECTION 4 - PARTS...
Page 52 SECTION 4 - PARTS...
Page 53 SECTION 4 - PARTS...
Page 54 SECTION 4 - PARTS 16' NARROW DT GANG DISK/DT (GANG MOUNT TUBE PN) GANG LAYOUT 8K0160 (8K3113) (8K3316) 8K0950 (8K3111) 8K0862 (8K3117) 8K0860 (8K3115) 8K1075 8X0317 8X0306 8X0114 8K6800 8X0260 8X0138 8X0281 8K1660 8X0044 *8K6860 HARDWARE PACKAGE 16' N-DISK.iam/ 9/3/2014 GANG LAYOUT...
Page 55 SECTION 4 - PARTS...
Page 56 SECTION 4 - PARTS 4-10...
Page 57 SECTION 4 - PARTS 4-11...
Page 58 SECTION 4 - PARTS 8X0260 8X0138 8X0306 3/4" N 1 X 5-1/2" 3/4" LW 8X0285A 8X0317 1-1/2" NYLOCK 3/4" FW 8X0114 8X0352 3/4 x 3" 8K1775 8K1075 8X0288 8K6313 8X0146 1 X 8-1/2" 8X0281 NY-LOCK 1" 8K1760 8X0044 8K1570 7/16" X 3-1/2" 8X0405 8K1585 8X0234...
Page 59 SECTION 4 - PARTS 8K4400 8X0306 3/4" LW 8X0260 3/4" N 8X0325 3/4" FW 8X0260 3/4" N 8X0306 8J0200 8K4199 3/4" LW 8K5520 3/4 X 6-1/8 X 7-1/2" 8K4209 8X0306 3/4" LW 8X0260 3/4" N 8X0015 3/8" X 3 3/4" 8K5505 8K1565 3/4 X 2-1/8 X 4-1/4"...
Page 60 SECTION 4 - PARTS 4-14...
Page 61 SECTION 4 - PARTS 8K9716 8X0306 3/4" LW 8X0260 3/4" N 8K9700 8X0111 3/4" X 2-1/2" 8H2314 (52") 8X0258 5/8" NUT 67 1/4" 32" 32" 67 1/4" 0" 8H2718 8H2718 NOTE: USE 8X0101 5/8 X 8" BOLTS IN PLACE OF 8X0099 5/8 X 6.75"...
Page 62 SECTION 4 - PARTS 4-16...
Page 63 SECTION 4 - PARTS 4-17...
Page 64 SECTION 4 - PARTS 4-18...
Page 65 SECTION 4 - PARTS 8K9718 8X0306 3/4" LW 8X0260 3/4" N 8X0111 3/4" X 2-1/2" 8K9700 8H2314 (52") 8HD5381 8HD5381 32" 32" 67 3/16" 67 3/16" 0" NOTE: USE 8X0101 5/8 X 8" BOLTS IN PLACE OF 8X0099 5/8 X 6.75" BOLTS TO ATTACH 8H2314 MOUNTING 16' N-DISK.iam/ ARMS.
Page 66 SECTION 4 - PARTS 4-20...
Page 67 SECTION 4 - PARTS 4-21...
Page 68 SECTION 4 - PARTS 4-22...
Page 69 SECTION 4 - PARTS 4-23...
Page 70 SECTION 4 - PARTS 4-24...
Page 71 SECTION 4 - PARTS Assembly Notes: A. Before towing machine, pack wheel bearings and fill 1/2 of hub cavity with high quality bearing grease. B. Tighten axle nut to 45 ft.-lbs., loosen nut until first slot is aligned with hole in axle, install cotter pin and bend to retain.
Page 72 SECTION 4 - PARTS 4-26...
Page 73 SECTION 4 - PARTS 4-27...
Page 74 SECTION 4 - PARTS 4-28...
Page 75 INSTALLATION AND OPERATION INSTRUCTIONS FOR 8K1850 HUBODOMETER W/ HOUSING FOR SUMMERS DIAMOND DISK AND 2510 DT Attach HUB ODOMETER to gang nut as shown in photos with 3/8” x 4-1/2” bolt, flat washers and lock nut. To prevent loosening, rotate gang to insure that bracket is on center and spot weld at locations shown.
Page 76 SECTION 4 - PARTS 4-30...
Page 77 SECTION 5 - PART NUMBERS AND DESCRIPTIONS Stock Code Description Stock Code Description 7K2055 STL 1/2 X 2 X 4.25” 11- 8J6010 3/4”-16 ORB X #6 JIC(M)90*ADP 7K2060 STL 5/8 SCRAPR BACKPLATE 11- 8J6020 3/4”-16 ORB X #10 JIC(M)90*ADP 7L2150 STL 1/2 X 7-1/2”OD X 2-9/16”ID 8J6030 7/8”-14 ORB X #10 JIC(M)90*ADP...
Page 78 SECTION 5 - PART NUMBERS AND DESCRIPTIONS Stock Code Description Stock Code Description 8K4406 STL 5/16” 2510 SCRAPR OUT RAW 8T1060 HYD CYL 6 X10 W/STRK CNTRL 96- 8K4409 STL 3/16” SCRAPR PLATE DSK RAW 8T2990 HYD HOSE CLAMP MTL/RUB BACK 8K4423 FILLER FLAT 5/8 X 2.5- 3”...
Page 79 REFLECTOR RED ADHSV-BACK 98- 8Z0204 DECAL 5.5” SUMMERS 14- 8Z1000 MANUAL-PAK 3DIA X 11.75” 09- 8Z0276 DECAL GENERAL CAUTION 91- 8Z2255 DECAL DK9630 ID 16-28.5’ N-DISK 8Z0340 DECAL REPHASING CYLINDERS 8Z2290 DECAL DT9530 ID 16-28.5’ N-DT 8Z0342 DECAL INSTALL CYLINDER LOCKS...
