OPERATOR'S MANUAL
WING FOLD LAND ROLLER
The Operator Is Responsible
For Adjusting The Machine For
Proper Performance And/Or
Function. Machine Does Not Come
"Field Ready" From The Factory.
SUMMERS MANUFACTURING CO., INC.
DEVILS LAKE, NORTH DAKOTA 58301
8Z1081.idw
PUBLISH DATE: 3/18/2025
Read And Understand
Operator's Manual
Before Using Machine.
www.summersmfg.com
© SUMMERS MFG. CO., INC.
(701) 662-5391
PRINTED IN USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the WING FOLD LAND ROLLER and is the answer not in the manual?

Questions and answers

gregory swecker
June 19, 2025

What is required to use the 7 pin electrical plug on a tractor. The lights don't work with my tractor. Does the roller require a relay in the harness?

0

Subscribe to Our Youtube Channel

Related Manuals for Summers WING FOLD LAND ROLLER

Summary of Contents for Summers WING FOLD LAND ROLLER

  • Page 1 OPERATOR'S MANUAL WING FOLD LAND ROLLER The Operator Is Responsible For Adjusting The Machine For Proper Performance And/Or Read And Understand Function. Machine Does Not Come Operator's Manual "Field Ready" From The Factory. Before Using Machine. SUMMERS MANUFACTURING CO., INC.
  • Page 3 TABLE OF CONTENTS...

  • Page 4: Warranty

    100% coverage of defective manufactured components in years 1-3, 75% in years 4-6 and 50% in years 7-10. Summers obligaton is to replace free of charge, any part of our product that Summers' inspection shows to be defective excluding transportation...

  • Page 5: General Information

    This book is composed of four basic sections: Safety, Operation and Maintenance, Specifcations, and Parts. The Operation Section provides information for the proper operation and maintenance of your Summers WING FOLD LAND ROLLER. A complete parts breakdown is provided in the Parts Section.

  • Page 6: Operator Orientation

    GENERAL INFORMATION OPERATOR ORIENTATION FRONT HITCH JACKS WING REST LEFT SIDE RIGHT SIDE TILT CYLINDERS CENTER RIGHT WING LEFT WING WING FOLD CYLINDERS...
  • Page 7 THIS PAGE IS INTENTIONALLY LEFT BLANK...

  • Page 8: Safety Alert Symbol

    SAFETY SAFETY ALERT SYMBOL This symbol is used to denote possible danger and care should be taken to prevent bodily injury. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 9: General Safety Practices

    (SIS) (SMV) SAFETY LIGHT OPERATION The Summers WING FOLD LAND ROLLER is equipped with a 7-pin light connector which meets SAE J560 specifications. To protect the connector when not attached to towing vehicle, store the connector in the dust cap.

  • Page 10: Safety Decals

    SAFETY SAFETY DECALS 8Z0800 REFLECTOR AMBER ADHSVBCK98- 8Z0805 REFLCTR REDORANGE ADHSVBK99- 8Z0810 REFLECTOR RED ADHSV-BACK 98- 8Z0276 GENERAL MACHINE CAUTION DECAL...
  • Page 11 SAFETY SAFETY DECALS 8Z0099 "WARNING" JACK DECAL 8Z0087 DECAL"WARNING"PINCH POINT03- 8Z0346 ELECTROCUTION-TILLAGE EQUIP. DECAL 8Z0344 DECAL WING DANGER 8Z0506 NOTICE FLOAT DECAL...
  • Page 12 SAFETY SAFETY DECALS 8Z0100 MADE IN THE USA DECAL 8Z0106B DECAL"DANGER" WNG LNDRLR TRNS 8Z0850 DECAL RIG POINT 8Z0055 PLATE SERIAL NUMBER UNIVRSL...
  • Page 13 SAFETY DECALS 8Z0245 DECAL SUMMERS LOGO 4.5" 8Z0750 8Z0741 8Z0745 DECAL SIZE ID 50' DECAL SIZE ID 41' DECAL SIZE ID 45'...
  • Page 14 SAFETY DECALS...
  • Page 15 SAFETY DECALS...
  • Page 16 SAFETY DECALS...
  • Page 17 "WARNING" JACK DECAL 8Z0087 DECAL"WARNING"PINCH POINT03- 8Z0805 REFLCTR REDORANGE ADHSVBK99- 8Z0810 REFLECTOR RED ADHSV-BACK 98- 8Z0245 DECAL SUMMERS LOGO 4.5" 8Z0750 DECAL SIZE ID 50' 8Z0745 DECAL SIZE ID 45' 8Z0741 DECAL SIZE ID 41' 8Z0106B DECAL"DANGER" WNG LNDRLR TRNS...

  • Page 18: Operation And Maintenance

    OPERATION AND MAINTENANCE NEVER PARK, UNHOOK OR SERVICE WITH WINGS RAISED IF THE HITCH IS DISCONNECTED IN THIS POSITION, THE HITCH WILL RAISE AND THE BACK OF THE MACHINE WILL DROP! ONLY DISCONNECT WHEN WINGS ARE IN THE WING RESTS OR THE MACHINE IS FULLY UNFOLDED. ONLY DISCONNECT ON FIRM LEVEL SURFACES.
  • Page 19 CONNECTING TO THE TRACTOR The Summers Wing Fold Land Rollers are equipped with an Articulating Ball Hitch. This hitch is designed to eliminate "slop" between the implement hitch and the tractor drawbar. All the Wing Fold Land Rollers will come with a Category 4 hitch that uses a 2"...

  • Page 20: Preparing For Field Operation

    WARNING: Wing Fold Land Roller must be attached directly to tractor drawbar and not an intermediate towed vehicle or implement. Loss of control could result causing serious injury or death to you or others. Park tractor and Wing Fold Land Roller on firm level surface with enough open area free of overhead obstacles.

  • Page 21: Field Operation

    NOT covered by warranty! TRANSPORT The Wing Fold Land Roller must be connected to a tractor drawbar. Park tractor and Wing Fold Land Roller on firm level surface with enough open area free of overhead obstacles. Take both hydraulic circuits out of Float.

  • Page 22: Disconnecting From The Tractor

    OPERATION AND MAINTENANCE TRANSPORT CONTINUED Tow with a secure drawbar pin and safety chain attached to tow vehicle. Ensure safety lights, reflective decals, Speed Identification Symbol, and Slow Moving Vehicle Sign are in working condition and visible. Tow vehicle must be able to withstand the tongue weight of machine. See specifications page for machine tongue weight.

  • Page 23: Specifications

    SPECIFICATIONS DIMENSIONS/WEIGHT (APPROX.) OVERALL TRANSPORT TRANSPORT TRANSPORT MACHINE MACHINE WORKING LENGTH HITCH WIDTH (A) HEIGHT (B) SIZE WEIGHT WIDTH WEIGHT 21,791 16' 2" 11" 11" 3500 22,776 16' 2" 12' 6" 4500 44.5' 24,200 16' 2" 13' 6" 6000 49.5' WHEEL HUBS PART WHEEL BOLT/NUT...
  • Page 24 SPECIFICATIONS DO NOT use these values if a different torque value to tightening procedure is given for a specific application. Torque values listed are for general use only. Periodically inspect fasteners for condition and tightness. Re-torque as necessary.
  • Page 25 THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 26 PARTS 8K1109 HUB ASSEMBLY...
  • Page 27 PARTS 8K1109 HUB ASSEMBLY ITEM DESCRIPTION 8K7210 HUB H1010 W/CUPS&ZRK 10BLT 15K 8K7212 GASKET HUB CAP H1010 8K7218 BEARING OUTER 12&15K H1010 8K7220 SEAL 3" ID 12K H1010 SE48 8X0328 WASHER 1.312"IDX2.5 OD-1/4" BL 8D5314 NUT 1-1/4"-12 HEX SLOT GR2 PLN 8X0414 COTTER PIN 1/4 X 2"...
  • Page 29 PARTS HITCH ITEM DESCRIPTION 8D0760 HITCH ARTIC. BALL CAT 4 8D2470 SAFETY CHAIN 7/16" X 5' 8X0281 NUT 1"-8NC NY-LOCK GR2 YZ 8X0146 BOLT 1-8NCX8.5" W/1.5"THD GR5ZDI 8Z1010 MANUAL HOLDER TUBE 8S3095 CAPLUG FITS ISO HYD COUPLR 08- 8K8067 DUST CAP FOR 7PIN CONNECT00- 8D8502 HYD HOSE HOLDER H-DUTY BLK 14- 8X0110...
  • Page 31 PARTS HITCH ITEM DESCRIPTION 8X3142 SLEEVEBRNG 2.50X2.0"ID- 2.0" 8P3900 PIN 2 X 11-1/8" HARDENED 8X0095 BOLT 5/8-11NC X 5" GR5 ZDI 8X0253 NUT 5/8"-11NC NY-LOCK GR2 YZ 8C0532 HYD CYL 5" X 32" 3500PSI 8K8660 SEAL KIT 5 X 32 & 36" CTD 89- 8T3300 PIVOT BOLT CHSLTRP&WNGLFT YZ 8X0316...
  • Page 33 PARTS WING REST ITEM DESCRIPTION 8P5031 LANDROLLER WING REST 8P4520 WING REST PLATE 8C1755 U-BOLT 3/4 X 6-1/16 X 6" SQ 8P5021 WING REST BRACE 8C1760 U-BOLT 3/4 X 8-1/16 X 6" SQ 8C1780 U-BOLT 7/8 X 8-1/16 X 10" SQ 8X0271 NUT 7/8"-9NC NY-LOCK GR2 YZ 8X0261...

  • Page 35: Right Wing

    PARTS RIGHT WING ITEM DESCRIPTION 8X3142 SLEEVEBRNG 2.50X2.0"ID- 2.0" 8P4044 ROLLER CROSSMEMBER 8X0107 BOLT 3/4-10NC X 2" GR5 YZ 8X0095 BOLT 5/8-11NC X 5" GR5 ZDI 8X0253 NUT 5/8"-11NC NY-LOCK GR2 YZ 8R8010 BEARING 2-1/2"FLNG 4BLT-49/64" 8X0111A BOLT 3/4-10NC X 2-3/4" GR5 ZDI 8X0265 NUT 3/4"-10NC CNTRLOCK GR2 YZ 8P5080...
  • Page 37 PARTS LEFT WING ITEM DESCRIPTION 8X3142 SLEEVEBRNG 2.50X2.0"ID- 2.0" 8P4044 ROLLER CROSSMEMBER 8X0107 BOLT 3/4-10NC X 2" GR5 YZ 8X0095 BOLT 5/8-11NC X 5" GR5 ZDI 8X0253 NUT 5/8"-11NC NY-LOCK GR2 YZ 8R8010 BEARING 2-1/2"FLNG 4BLT-49/64" 8X0111A BOLT 3/4-10NC X 2-3/4" GR5 ZDI 8X0265 NUT 3/4"-10NC CNTRLOCK GR2 YZ 8P5080...

  • Page 39: Center Frame

    PARTS CENTER FRAME ITEM DESCRIPTION 8P4044 ROLLER CROSSMEMBER 8X0107 BOLT 3/4-10NC X 2" GR5 YZ 8K1109 SPINDLE W/H1010 15K 8X0075 BOLT 1/2-13NC X 6" GR5 YZ 8X0242 NUT 1/2"-13NC NY-LOCK GR2 YZ 8C0532 HYD CYL 5" X 32" 3500PSI 8K8660 SEAL KIT 5 X 32 &...
  • Page 40 DETAIL B SCALE 1/20...
  • Page 41 PARTS SMV/FLOW DIVIDER ITEM DESCRIPTION 8X0329 WASHER 5/16"(3/8" ID)FLAT YZ 8X0211 NUT 5/16"-18NC SERFLANG GR2 YZ 8X0203 NUT 3/8"-16NC SERFLANG GR2 YZ 8S1120 SIGN SLOW MOVING VEHICLE(SMV) 8Z2606 DECAL 20 MPH SIS 8A1155 U-BOLT 3/8 X 6-1/16 X 5" SQ 8X0803 STL .25 MODULE BRACKET 16- 8K8203...

  • Page 42: Hitch Jack

    PARTS HITCH JACK 138A...
  • Page 43 PARTS HITCH JACK ITEM DESCRIPTION 8X0107 BOLT 3/4-10NC X 2" GR5 YZ 8K9106 PIN 1-1/4 X 4-3/8" HARDENED 8D9108 ROLL PIN 1/4 X 2" YLW ZNC 8X0262F NUT 3/4"-10NC TLCK FLNG GRFPLN 8P5032 HYDRAULIC JACK CYLINDER ATTCH 8P5033 HYDRAULIC JACK BASE 8P0510 HYD CYL 5.5"...
  • Page 44 NEGATIVE GRIP POSITIVE GRIP...
  • Page 45 PARTS JACK HYDRAULICS ITEM DESCRIPTION 8P0510 HYD CYL 5.5" X 10" 3500PSI 8P0511 SEAL KIT 5.5X10"CTD 8P0510 11- 8J7216 #6JIC(M)X6JIC(F)1/16"RSTR GOLD 8J7000 BALL VALVE HYD 9/16"-18ORB(2X) 8J6060 3/4" - 16 ORB X #6 JIC(F) 90°ADP 8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP 8J5680 3/4"-16 ORB X 3/4"-16ORB UNION 8J5510...
  • Page 46 PARTS TILT HYDRAULICS POSITIVE GRIP NEGATIVE GRIP...
  • Page 47 PARTS TILT HYDRAULICS ITEM DESCRIPTION 8C0532 HYD CYL 5" X 32" 3500PSI 8J7000 BALL VALVE HYD 9/16"-18ORB(2X) 8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP 8J7216 #6JIC(M)X6JIC(F)1/16"RSTR GOLD 8J5300 TEE #6 JIC (MALE) 3X 8J5700 #6 JIC(F-SW) X #6 JIC(M)90*ADP 8J5500 9/16"-18 ORB X #6 JIC(M) STR 8J5510 3/4"-16 ORB X #6 JIC(M) STR 8D3212...
  • Page 48 NEGATIVE GRIP POSITIVE GRIP DETAIL A NOTES: 1. 8J7116 RESTRICTOR ARROW DIRECTION MUST BE POINTED INTO THE CYLINDER...

  • Page 49: Wing Fold Hydraulics

    PARTS WING FOLD HYDRAULICS ITEM DESCRIPTION 8C0532 HYD CYL 5" X 32" 3500PSI 8J7040 THERMAL RELIEF MANIFLD 4000PSI 8J5510 3/4"-16 ORB X #6 JIC(M) STR 8J7116 3/4"-16 ORB(2X)1WAY 1/16"RESTR 8J5690 3/4-16X3/4-16 ORB M-SW90*UNION 8J5680 3/4"-16 ORB X 3/4"-16ORB UNION 8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP 8J5300 TEE #6 JIC (MALE) 3X...

  • Page 51: Light Harness

    PARTS LIGHT HARNESS ITEM DESCRIPTION 8K8095B LIGHT LED RED 3WIRE DTSCH 12- 8K8090B LIGHT LED AMBER 2WR DTSCH 12- 8K8083 EXT HARNESS WFLR 8K8070B MAIN HRNSS 7PN 32' W/BRAKE 09- 8K8030A MODULE AG ENHNCDW/BRAKE6PIN08-...
  • Page 52 PARTS INSTALLATION AND OPERATION INSTRUCTIONS FOR 8K1800 ACRE METER Clean threads in end of drum shaft. The threads are 1/2"-20 UNF. Recommended location is Left wing towards the center. This allows the inspection of the Acre Meter while machine is in transport. Attach Acre Meter with 1/2"...
  • Page 53 NOTES...
