Rotary Rockpicker, Hyd. Direct Drive
IMPORTANT
THE OPERATOR IS RESPONSIBLE FOR AD-
JUSTING THE MACHINE SINCE MACHINE DOES
NOT COME "FIELD READY" FROM FACTORY.
See www.summersmfg.com for the latest version of all Summers Operator's Manuals
SUMMERS MANUFACTURING CO., INC.
DEVILS LAKE, NORTH DAKOTA 58301 ................................................... (701) 662-5391
8Z1102
Operator's
WEB SITE: www.summersmfg.com
© Summers Mfg. Co., Inc. 2017
Manual
RP6700
(MODEL 700)
CAUTION
READ & UNDERSTAND OPERATOR'S MANUAL
BEFORE USING MACHINE.
®
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP6700 and is the answer not in the manual?

Questions and answers

Related Manuals for Summers RP6700

Summary of Contents for Summers RP6700

  • Page 1 NOT COME “FIELD READY” FROM FACTORY. READ & UNDERSTAND OPERATOR’S MANUAL BEFORE USING MACHINE. See www.summersmfg.com for the latest version of all Summers Operator’s Manuals SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 ........... (701) 662-5391 8Z1102 ©...
  • Page 2 This express warranty is the sole warranty of Summers. There are no warranties, which extend beyond the warranty herein expressly set forth. The sales for products of Summers under any other warranty or guarantee express or implied is not authorized. This warranty voids all previous issues.

  • Page 3: Table Of Contents

    Reference to “Right” and “Left” in this book is determined when the machine is viewed from the rear. Parts are referenced in each drawing with the Summers Manufacturing Part Number. Use this Part Number when ordering replacement parts from your Summers dealer.
  • Page 4 NOTES...

  • Page 5: Section 1: Safety

    SECTION 1 - SAFETY SAFETY-ALERT SYMBOL This symbol is used to denote possible danger and care should be taken to prevent bodily injury. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Definition of each Signal Word used in conjunction with the Safety-Alert symbol. indicates an imminently hazardous situation which, if not avoided, will result in death or DANGER serious injury.

  • Page 6: Safety Decals

    SAFETY DECALS 1. KEEP SAFETY DECALS AND REFLECTORS CLEAN. 2. REPLACE missing or unreadable decals. New decals are available from your Summers dealer by ordering correct part number (PN) located in lower right hand corner. 1. PINCH POINT HAZARD DECAL (PN 8Z0087)
  • Page 7 SECTION 1 - SAFETY 4. GENERAL INFORMATION DECAL (PN 8Z0220) IMPORTANT GREASE REGULARLY. CHECK WHEEL BOLTS DAILY FOR TIGHTNESS. REEL SPEED MUST NOT EXCEED 35 RPM. 8Z0220 5. ROCKPICKER BATT WARNING DECAL (PN 8Z0230) DANGER DO NOT ATTEMPT TO FREE ANY ROCKS OR MAKE ANY ADJUSTMENTS ON ROCK PICKER UNLESS TRACTOR...

  • Page 8: Maintenance Safety

    SECTION 1 - SAFETY 7. AMBER REFLECTOR (PN 8Z0800) 8. RED-ORANGE REFLECTOR (PN 8Z0805) 9. RED REFLECTOR (PN 8Z0810) MAINTENANCE SAFETY 1. STOP engine, place all controls in neutral, set parking brake, remove ignition key and wait for all moving parts to stop before servicing, adjusting or maintaining.

  • Page 9: Section 2: Operation And Maintenance

    SECTION 2 - OPERATION AND MAINTENANCE INITIAL SETUP HITCH AND SPINDLE SETUP Install hitch with hydraulic cylinder on left side, attach hitch jack, safety chain, hydraulic hose stand and tip holder. Use appropriate lifting device, hitch assembly weighs 410 lbs. 16.5L X 16.1 Tire: Attach receiver tube with plate (8R6206) to frame with tube on top.

  • Page 10: Electric Solenoid Lift Option

    SECTION 2 - OPERATION AND MAINTENANCE INSTALLATION INSTRUCTIONS FOR ELECTRIC SOLENOID LIFT OPTION 1. When installing an Electric Solenoid Lift Option refer to following instructions and see breakdown on page 3-6. Mounting the switch. Mount switch to a secure support in a convenient location on the tractor. Route the red and white battery wires to a 12-volt battery.

  • Page 11: Field Operation

    4. Pressure should read about 2000 psi, however, pressure here will never be higher than tractor pressure read in step #1. If stalled reel pressure is less than pressure in step #1 and less than 2000 psi contact your Summers dealer.
  • Page 12 Page 3-4 planetary gear box. caused by leaking gear box and replace shaft seal (Order shaft seal on hyd. Summers PN 8R7407 for complete kit). motor. Oil from tractor hyd. system enters gear box through motor and this pressure forces seal out.
  • Page 13 SECTION 3- PARTS...
  • Page 14 SECTION 3- PARTS...
  • Page 15 SECTION 3- PARTS...
  • Page 16 SECTION 3- PARTS...
  • Page 17 SECTION 3- PARTS...
  • Page 18 SECTION 3- PARTS...

  • Page 19: Hydraulic Swing Hitch

    SECTION 3- PARTS HYDRAULIC SWING HITCH (Model 700) 8J6010 3/4-16ORB X #6JIC(M) 90° ADP 8D1660 8X0202 3/8" LN (8X0112) 3/4X2-1/4" 8S2990 8X0234 HOSE CLMP 7/16" LNUT 8X0044 (8D8500) 7/16" X 3-1/2" DETAIL A 8R7880 8X1130 8X0110 CRG 3/8"x3" 3/4 X 1.25" 8N3136 (2X) 8X0400 3/8 X 136"...
  • Page 20 SECTION 3- PARTS...
  • Page 21 SECTION 3- PARTS ROCKPICKER...
  • Page 22 SECTION 3- PARTS 3-10...
  • Page 23 Disc Valve Motors Integral Cross Over Relief Valve Technical Manual 2000 Series...
  • Page 24 Introduction 2000 Series Eaton Char-Lynn®, your proven low speed high torque motor supplier, now offers the Char-Lynn® 2000 Series Geroler® Element ....9 Displacements motor with our proven Eaton Vickers® Screw-in Flow LPM [GPM]....75 [20] Cont.** 115 [30] Inter.* Cartridge Valves integral to the motor. This compact Speed ........Up to 924 RPM and efficient package offers increased value and cost Pressure Bar [PSI] ....200 [3000] Cont.
  • Page 25 Standard Mount Motors 1-1/4 inch Dia. 1-1/4 inch 1 inch and 25 mm SAE 6 B 1-1/4 inch Dia. 32 mm 7/8 inch Dia. Tapered Shaft Dia.Shaft Dia.Shaft Splined Shaft Splined Shaft Dia. Shaft Splined Shaft 65,8/63,5 56,7/54,3 56,7/54,3 [2.59/2.50] [2.23/2.14] [2.23/2.14] 10,2/7,8...
  • Page 26 Wheel Mount Motors 1 inch and 25 mm 1-1/4 inch SAE 6 B 1-1/4 inch Dia. 32 mm 7/8 inch Dia. Dia.Shaft Dia.Shaft Splined Shaft Splined Shaft Dia. Shaft Splined Shaft 106,0/103,6 96,8/94,4 96,8/94,4 [4.17/4.08] [3.81/3.72] [3.81/3.72] 1-1/4 inch Dia. Tapered Shaft 92,5/89,9 92,5/89,9...
  • Page 27 Bearingless Motors Port for Internal 157,5 or External [6.20] Case Drain Max. (2) 127,0 101,60/101,47 [5.00] [4.000/3.995] Dia. Pilot Dia. 13,85/13,33 119,2 [.545/.525] [4.69] Dia. Thru (4) Sq. Max. 14,22 [.560] Min. (4) 24,06/23,54 [.947/.927] Port B 6.7/6,0 [.26/.24] Max. 7/8-14 O-ring Staggered Ports, G 1/2 (BSP) Staggered Ports O-ring Seal...
  • Page 28 Model Code The following 24-digit coding Use this model code to spec- You may want to photocopy Model Code for 2000 system has been developed ify a motor with the desired the matrix below to ensure Series Motors features. All 24-digits of the that each number is entered to identify all of the configu- ration options for the 2000...
  • Page 29 Model Code Model Code — 2000 Series Disc Valve Motors Sample Model Code: 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Feature Code Description Feature Code Description 10, 11 Port Type 7/8-14 UNF –2B SAE O-ring 19, 20 Special Features (Hardware) (Staggered) None...
  • Page 30 Eaton Eaton Eaton 14615 Lone Oak Road 20 Rosamond Road Eaton Fluid Power GmbH Eden Prairie, MN 55344 Footscray Dr.-Reckeweg-Str. 1 Victoria 3011 D-76532 Baden-Baden, Germany Tel: 952 937-9800 Australia Tel: +49 (0) 7221 682-0 Fax: 952 974-7722 Tel: (61) 3 9319 8222 Fax: +49 (0) 7221 682-788 www.hydraulics.eaton.com Fax: (61) 3 9318 5714...
  • Page 42 Eaton Eaton Eaton Fluid Power Group Fluid Power Group Fluid Power Group Hydraulics Business USA Hydraulics Business Europe Hydraulics Business Asia Pacific 14615 Lone Oak Road Route de la Longeraie 7 11th Floor Hong Kong New World Tower Eden Prairie, MN 55344 1110 Morges 300 Huaihai Zhong Road Shanghai 200021...
  • Page 50 Eaton Eaton Eaton Fluid Power Group Fluid Power Group Fluid Power Group Hydraulics Business USA Hydraulics Business Europe Hydraulics Business Asia Pacific 14615 Lone Oak Road Route de la Longeraie 7 11th Floor Hong Kong New World Tower 300 Huaihai Zhong Road Eden Prairie, MN 55344 1110 Morges Switzerland...
  • Page 51 2004 - A 124 ft. x 310 ft. addition is added onto the current Devils Lake plant. 2005 - The Summers Superroller is added to the “Field Tested Tough” product line. Additional sizes of 56’, 58’ and 60’ are added to the Superchisel line.
  • Page 52 ® . . . Field Tested TOUGH! Tillage Cultivators/Harrows Rock Picker Mounted Attachments Land Rollers/Packers Sprayers 1-800-732-4347 • www.summersmfg.com...
