❖ Double-click the IP-Manager icon on the desktop to run this software.
❖ Modify the IP address. The default TCP/IP setting of this camera is set to DHCP so the
address is not fixed. If no DHCP server is available on your network, the camera setting
will change to "fixed IP" with the address 192.168.226.201. Tick all the cameras you
wish to set and then click on the "Batch Set NET" tab.
If you wish to set static IP addresses, choose "Use the following IP Addresses", set the range
of IP addresses you wish to assign (First and last address), set the gateway and subnet mask,
and click on batch set. Wait for a few
moments until the IP manager will
configure the cameras. After
configuration, the IP addresses of the
cameras will refresh automatically.
Please note:
The IP range must fit the number of chosen cameras.
The selected IP addresses in the specified range must be available.
For example, if the IP address of your computer is 192.168.1.4, then the IP address of the
cameras should be changed to 192.168.1.x. (x stands for any number between 1 and 255).
Video Doorbell Quick Guide
8
