DEMO MANUAL DC2253A
parts List
ITEM QTY REFERENCE
43 RFB3, RFB4
44 R28, R29, R60, R61
45 2 R7, R50
46 1 R8
47 2 R26, R55
48 17 R1, R11, R17, R23, R25
49 R27, R43, R46, R48, R51, R76
50 R57, R62, R67, R69, R70, R72
51 1 R20, R33
52 2 R16, R45
53 6 RC1, R21, R24, R34, R44, RC
54 1 R30
55 1 R31
56 1 R56
57 5 TP1, TP2, TP3, TP7, TP20
58 6 TP4, TP5, TP6, TP10-TP12
59 2 U1, U2
60 1 U3
61 4 MTGS AT 4 CORNERS
62 1
63 2 STENCILS
8
PART DESCRIPTION
RES., 1206, OPTIONAL
RES., CHIP., 100k, 0.1W, 1% 0603
RES., CHIP., 10Ω, 0.1W, 5% 0603
RES., CHIP., 10Ω, 0.1W, 5% 0805
RES., CHIP., 0Ω 1% 0603
RES., CHIP., 0Ω 2512
RES., CHIP., 1k, 0.1W, 1% 0603
RES., CHIP., 10k, 0.1W, 1% 0603
RES., CHIP., 41.2k, 0.1W, 1% 0603
RES., CHIP., 12.1k, 0.1W, 1% 0603
RES., CHIP., 499k, 0.1W, 1% 0603
TESTPOINT, TURRET, .061" PBF
TESTPOINT, TURRET, .094" PBF
I.C.,LTC3789EGN SSOP N
I.C.,LTC6908CDCB-1 2mm × 3mm
STAND-OFF, NYLON 0.5"
FAB, PRINTED CIRCUIT BOARD
STENCIL BOTH SIDES
MANUFACTURER/PART NUMBER
YAGEO, RC0603FR-07100KL
YAGEO, RC0603JR-0710RL
YAGEO, RC0805JR-0710RL
YAGEO, RC0603FR-070RL
TEPRO, RN5326
YAGEO, RC0603FR-071KL
YAGEO, RC0603FR-0710KL
YAGEO, RC0603FR-0741K2L
YAGEO, RC0603FR-0712K1L
YAGEO, RC0603FR-07499KL
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
LINEAR TECH., LTC3789EGN#PBF
LINEAR TECH., LTC6908CDCB-1
KEYSTONE, 8833 (SNAP ON)
DEMO CIRCUIT FT228A
STENCIL FT228A
