Active 2.3 Instruction Book

Premium prosumer electric pressure washer 1500 psi 2.3 gpm
Hide thumbs
Table of Contents

Advertisement

Quick Links

ACTIVE™ 2.3
ACTIVE™ 2.3
PREMIUM PROSUMER
PREMIUM PROSUMER
ELECTRIC PRESSURE
ELECTRIC PRESSURE
WASHER
WASHER
User Manual
MODEL NO. SE10
1500 PSI
Congratulations on the purchase of your new
ACTIVE™ pressure washer. In order to ensure you
have the best possible experience, please read
through the following instructions.
Important safety instructions:
Keep this instruction book with the machine all time.
Version: 2023 V4
2.3 GPM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2.3 and is the answer not in the manual?

Questions and answers

Related Manuals for Active 2.3

Summary of Contents for Active 2.3

  • Page 1 1500 PSI 2.3 GPM Congratulations on the purchase of your new MODEL NO. SE10 ACTIVE™ pressure washer. In order to ensure you have the best possible experience, please read through the following instructions. Important safety instructions: Keep this instruction book with the machine all time.

  • Page 2: Table Of Contents

    Table of Contents 1. IMPORTANT PRECAUTIONS..................3 1.1 Definitions ..............................3 1.2 Safety Warnings ............................3 1.3 Intended Application ..........................5 2. SAFETY FEATURES AND ELECTRICAL INFORMATION ........... 5 2.1 Extension Cords ............................5 3. EXPLODED VIEW ......................6 4. PARTS LIST ........................6 5.

  • Page 3: Important Precautions

    Important Precautions 1. Important Precautions IMPORTANT, RETAIN FOR FUTURE REFERENCE 1.2 Safety Warnings AND READ CAREFULLY! Do not attempt to install or operate this device DANGER until you have read the safety instructions in this manual. Safety items throughout this manual To reduce the risk of fire, electric shock, explosion are labelled with Danger, Warning, or Caution or injury to people, read the following:...
  • Page 4 If replacement of the power plug or cord is needed, use only identical replacement parts. • Repairing and replacing parts should be done by an adult within the scope of Active CAUTION — WATER CONNECTIONS documentation for product troubleshooting and maintenance.

  • Page 5: Intended Application

    Important Precautions / Safety Features and Electrical Information 1. Important Precautions (cont.) 2.1 Extension Cords 1.3 Intended Application This product is designed for residential and slight If possible, do not use extension cords with this commercial applications. Do not modify or use product.

  • Page 6: Exploded View

    Exploded View / Parts List 3. Exploded View 4. Parts List Item # Part Name Qty. Part # Item # Part Name Qty. Part # Quick-connect wand XE16-020-0002 Screw kit (6x30) SE10-080-0001 Gun assembly UG01-020-0003 Main unit SE10-001-0000 Pre-attached on Tips kit (4 pcs) SE10-020-0004 Water filter...

  • Page 7: Assembly Instructions

    Assembly Instructions 5. Assembly Instructions 5.4 Assembly 5.1 Surface Preparation Before beginning any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture.
  • Page 8 Assembly Instructions 5. Assembly Instructions (cont.) 5.4 Assembly (cont.) To install tip, gently slide the collar back before inserting it, then release the collar to lock the tip. Attach the desired spray tip to the wand. The spray tips are for the following purposes: 0°...
  • Page 9 Assembly Instructions 5. Assembly Instructions (cont.) 5.4 Assembly (cont.) RESET TEST Plug the unit into an outlet. WARNING Make sure your hands are dry. Plug the unit into an outlet. Release the safety trigger if it is locked.

  • Page 10: Wallmount Assembly

    Assembly Instructions 5. Assembly Instructions (cont.) 5.4 Assembly (cont.) PURGING ON / OFF button Purge air by squeezing the trigger on the gun until there is a steady stream of water. CAUTION Push ON/OFF button, switch is set in ON position, machine is ready to operate.

  • Page 11: Shelf Mounting Procedure

    Assembly Instructions 5. Assembly Instructions (cont.) 5.5 Wallmount STEP A-1 For concrete wall in the garage For 24" spacing between studs 3/4˝ CONCRETE WALL 16˝ 16˝ 7˝ 24˝ WOOD STUD 1/5˝ FLAT SPRING 2¾˝ STEP A-2 WASHER WASHER 45˝– 65˝ 45˝–...

  • Page 12: Operating Instructions

    Operating Instructions 6. Operating Instructions 6.1 Working with Foam Blaster Working with a detergent ensures quick soaking of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively. Always spray detergent on a dry surface, do not pre-soak the area.

  • Page 13: Shutting Down And Cleaning Up

    Operating Instructions WARNING Pencil Turn off the water supply and pull the trigger to Spray depressurize the device. Failure to do so might result in personal injury due to discharge of Spray high-pressure water. 6.3 Taking Breaks 1. Pencil Spray - Sliding collar backwards will If taking a five minute or longer break while using the set to prencil spray mode.

  • Page 14: Winterizing And Long-Term Storage

    Winterizing 7. Winterizing and Long-Term Storage 7.1 Optimum Winterizing Procedure 7.2 Quick Winterizing Procedure Winterizing your pressure washer will help protect If you are unable to perform the optimum and prolong its life. We strongly recommend you winterizing procedure, you can still protect your follow the below steps using a Pressure Washer pressure washer from winter damage by doing the Antifreeze before storing for the winter.

  • Page 15: Cleaning And Maintenance

    1100 PSI (7.6 MPa) Power source requirement: 120 V / 60 Hz Electric power cord: 35' (10.7m) 14 AWG High-pressure hose: 39' (12m) US GPM: 2.3 GPM Current drawn: 14 A Inlet water: Cold tap water Motor: Induction Pump: Brass, direct-drive...

  • Page 16: Troubleshooting

    Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution Push the ON/OFF button once to turn to the ON The device is in OFF mode. mode. The power cord is not plugged in. Plug in the power cord.
  • Page 17 Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution Loose fittings. Tighten fittings. The garden hose connection leaks. Missing/worn rubber washer. Insert new washer. Ensure the quick-connect wand is attached The spray nozzle was not properly securely.

  • Page 18: Warranty

    Warranty 11. Warranty Limited Warranty Statement This product is to be operated in compliance with the instructions in the operating guidelines. Failure to comply will result in denying warranty. This warranty does not cover accidental damage, unreasonable use or use outside the scope of intended purpose, any changes made to the product (use of unauthorized accessories or spare parts), maloperation of the product ( exceeding or not meeting electrical and input water requirements) and normal wear and tear like belts, chains and tine, use of improper detergents, freezing, neglect, or non-compliance with the...
  • Page 19 Note...
  • Page 20 Important safety instructions: Keep this instruction book with the machine all time.
