Myenergi ZAPPI-2H07UW-G Installation Manual

These instructions must be followed to comply with the law for the Electric
Vehicle (Smart Charge Points) Regulations 2021, if installed in England,
Scotland or Wales from 30/12/2022.
Tamper Retrofit
Installation Guide
For use with
November 2022 (Serial Numbers starting with a 2)
Prefer a video? Scan the QR on page 3 of this guide.
1. Check if your
You need to install this retrofit kit if you're installing a
without a tamper detection device, on or after 30th December 2022.
You can identify whether the
a)
rating plate on the
indicates whether tamper is already built-in (2).
This kit is not suitable for models that have a serial number starting with 1.
b)
1
2. Install Tamper Board
Ensure is safely isolated before performing these steps. The tamper detection board is electrostatic-
sensitive. Hold it by the edges. We would advise touching something earthed before handling the board.
Step 1:
Isolate the device, if required.
Step 2:
Remove fascia and front of enclosure.
For more detailed instruction on removing the fascia and cover refer to
Revision 1.4, November 2022
IMPORTANT!
built between May 2022 and
needs this kit
for the words "Tamper Detection" (1) or by a label on the box also
-G
has in-built tamper detection by either, looking at the
WARNING!
NOTICE
, in England, Scotland or Wales,
See figures 1 and 2 below
2
Compliant with the smart charging
regulations 2021, including schedule 1
Tamper Detection built-in.
Installation Manual.
D3511
