Multitap - Extended Diagram - Spring NEOTAP Installation And Operation Manual

Hot, cold, sparkling multitap

Hide thumbs Also See for NEOTAP:

Table of Contents

MULTITAP - EXPANDED DIAGRAM

Drinking water

rotatable

controller

Threaded Housing

Please check the parts are all correct in the box, and read the manual throughly. To install and

use the faucet by following instruction to avoid damage

Hexagonal Screw

Silicone Shim

Metal Shim

C-Type Nut

Screw

Mixer Tap Control

Faucet body

Ambient water inlet water flexihose

(Blue striped steel wire)

Hot inlet water flexihose

(Red striped steel wire)

Three way tee
