    MHTM MicroDrive Short instructions Contents Safety ..............3 Scope of delivery ..........3 2.1 ACCESS PRO H ........... 3 2.2 ACCESS / PARKING ........4 2.3 TOLL .............. 4 Required tools ............. 5 Dimensions ............6 4.1 ACCESS PRO H ........... 6 4.2 ACCESS / PARKING ........

  • Page 3: Safety

    MHTM MicroDrive Short instructions Safety WARNING! These instructions are short instructions. These instructions do not replace the operating instructions „MHTM MicroDrive“ that are part of the delivery. These short instructions are targeted at specialists who already have experience with assembly, installation and commissioning. For detailed information, see the operating instructions.

  • Page 4: Access / Parking

    MHTM MicroDrive Short instructions ACCESS / PARKING optional TOLL optional Doc-Id: 5816,0002EN / Version 03...

  • Page 5: Required Tools

    MHTM MicroDrive Short instructions Required tools Impact drill 10 mm Silicone cartridge Silicone Open-face wrench 13 mm Torque wrench, hexagon socket 5 AF Torque wrench, hexagon socket 8 AF Torque wrench, hexagon socket 10 AF Torx wrench T20 Hexagon socket wrench 4 AF Phillips screwdriver for 3.5 mm Diagonal pliers...

  • Page 6: Dimensions

    MHTM MicroDrive Short instructions Dimensions ACCESS PRO H min. 500 min. 500 min. 800 Access Pro H 3500 Access Pro H 4500 Access Pro H 5000 Access Pro H 6000 Left version MicroBoom Right version Doc-Id: 5816,0002EN / Version 03...

  • Page 7: Access / Parking

    MHTM MicroDrive Short instructions ACCESS / PARKING min. 500 min. 500 Access 3500 Access Pro 3500 Access Select 3500 Access L 5000 Access Pro L 6000 Access Select L 6000 Parking 3500 Left version VarioBoom Right version Doc-Id: 5816,0002EN / Version 03...

  • Page 8: Toll

    MHTM MicroDrive Short instructions TOLL min. 500 min. 500 Toll 3000 min. 800 Toll Pro 3000 Toll HighSpeed 2000 / 2500 / 3000 Toll HighSpeed 2 1500 Left version MicroBoom-T Right version Doc-Id: 5816,0002EN / Version 03...

  • Page 9: Set Up Foundation And Install Housing

    MHTM MicroDrive Short instructions Set up foundation and install housing < 2 mm/m² For housing alignment, see chapter 4, page 6. Doc-Id: 5816,0002EN / Version 03...

  • Page 10: Remove Transport Protection

    MHTM MicroDrive Short instructions Remove transport protection Electrical connection Electrical voltage! 230 V AC / 50 – 60 Hz Doc-Id: 5816,0002EN / Version 03...

  • Page 11: Assemble Barrier Boom

    MHTM MicroDrive Short instructions Assemble barrier boom ACCESS PRO H Water = 2000 + 3 mm < 2000 > 2000 Doc-Id: 5816,0002EN / Version 03...
  • Page 12 MHTM MicroDrive Short instructions 12 Nm M8 x 16 (AF 5) Tighten the screws 2 x. Danger of crushing! 10 AF 75 Nm Doc-Id: 5816,0002EN / Version 03...

  • Page 13: Access / Parking

    MHTM MicroDrive Short instructions ACCESS / PARKING M6 x 10 (T20) M6 x 12 (AF 4) Doc-Id: 5816,0002EN / Version 03...
  • Page 14 MHTM MicroDrive Short instructions Water + 3 mm = 2000 < 2000 > 2000 Doc-Id: 5816,0002EN / Version 03...
  • Page 15 MHTM MicroDrive Short instructions 12 Nm M8 x 16 (5 AF) Tighten the screws 2 x. Doc-Id: 5816,0002EN / Version 03...

  • Page 16: Toll

    MHTM MicroDrive Short instructions Danger of crushing! 10 AF 75 Nm TOLL Danger of crushing! Mag05017 Doc-Id: 5816,0002EN / Version 03...

  • Page 17: Align Barrier Boom

    MHTM MicroDrive Short instructions Align barrier boom Danger of crushing! Upper tool bore for opening the barrier Lower tool bore for closing the barrier Service Doc-Id: 5816,0002EN / Version 03...

  • Page 18: Adjust Balancing Springs

    MHTM MicroDrive Short instructions 10 Adjust balancing springs Check and set the balancing springs. See operating instructions, chapter "Check and set the balancing springs in the lever system". 11 Stick on warning signs Doc-Id: 5816,0002EN / Version 03...

  • Page 19: Start Up Barrier

    MHTM MicroDrive Short instructions 12 Start up barrier Service Doc-Id: 5816,0002EN / Version 03...
  • Page 20 MHTM MicroDrive Short instructions MAGNETIC Autocontrol GmbH Grienmatt 20 79650 Schopfheim Germany Tel.: +49 (0) 7622 695 5 Fax.: +49 (0) 7622 695 602 info@ac-magnetic.com www.ac-magnetic.com Doc-Id: 5816,0002EN / Version 03...
