Hubbell AccelTex Solutions ATS-RDMM-16 Installation Manual

Installation Guide
Introduction
This is a quick guide for the AccelTex folding
mast mount. This install goes over the steps
of putting the mount together in order to
install the wireless solution. Once the overall
setup is put together the height of it can be
adjusted.
This product is intended for dry, flat,
horizontal surfaces and should be properly
secured depending on the specific
environment
Step 1
Mount should be received as in the picture
after unpacking with an adjustable height
mast (not included in the picture). Please
inspect all components are in the package.
Overall setup is put together the height of it
can be adjusted.
ATS-RDMM-16
Parts List
1 ATS-NPRM-TEMPEVENT-3.0 Base mount
2 Side supports (Included in base mount)
4 wing nuts (Included in base mount)
1 ATS-MST20-TEMPEVENT-3.0 Telescopic Mast
Step 2
Ensure 2 side supports are inside the tube.
Step 3
Release the folding tension cable and lay out the pieces
to ensure all parts are included.
