- Page 1 ATS-DRPMNT-UNIV1-OOOP-HVD Universal AP and Antenna Heavy Duty Versatile Drop Mount Installation Guide ATS-DRPMNT-UNIV1-OOOP-HVD VERSION 1...
- Page 2 ATS-DRPMNT-UNIV1-OOOP-HVD Installation Guide INSTALLATION GUIDE (Universal AP and Antenna Heavy Duty Versatile Drop Mount) Contents Overview......................................2 Tools Required ....................................2 Installation Safety ..................................2 Parts Needed ....................................2 Installation ..................................... 3 Overview This is a quick installation guide on how to install the AccelTex Heavy Duty Drop Mount. The installation goes over the steps of putting the mount together along with the access point (AP) and Antenna.
- Page 3 ATS-DRPMNT-UNIV1-OOOP-HVD Installation Guide Installation Inspect Mounted Conduit Make sure the Mount placement is at the network drop location Directions 1. Remove the mount from its package and install the selected AP and Antenna using pre-defined Mount and Antenna Articulating Arm keyholes. 2.
