RECIPROCATING SAW
CAUTION:
Understand Operator's Manual. Save These Instructions For Future
Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374 (M-F 8:30am-5:00pm EST).
BRUSHLESS
241-0352
OPERATOR'S MANUAL
To Reduce The Risk Of Injury, User Must Read And
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MasterForce BOOST 241-0352
Summary of Contents for MasterForce BOOST 241-0352
- Page 1 BRUSHLESS RECIPROCATING SAW 241-0352 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374 (M-F 8:30am-5:00pm EST).
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ............Page 2 Safety Instructions . -
Page 3: Safety Symbols
SAFETY SYMBOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. - Page 5 SAFETY INSTRUCTIONS GENERAL POWER TOOL SAFETY use an extension cord suitable for outdoor use. Use of a cord suitable for WARNINGS outdoor use reduces the risk of electric shock. WARNING: Read all safety warnings, 6. If operating a power tool in a damp instructions, illustrations and specifications location is unavoidable, use a ground- provided with this power tool.
- Page 6 SAFETY INSTRUCTIONS POWER TOOL USE BATTERY TOOL USE AND CARE AND CARE 1. Recharge only with charger specified manufacturer. A 1. Do not force the power tool. Use the charger that is suitable for one type of correct power tool for your application. battery pack may create a risk of fire The correct power tool will do the job when used with another battery pack.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS RECIPROCATING SAWS 1. To reduce the risk of electric shock or damage to the chargers and batteries, 1. Hold power tool by insulated gripping use only with the MASTERFORCE ® surfaces, when performing battery packs and chargers listed.
-
Page 8: Overview/Specifications
OVERVIEW Variable-Speed Lock-Off Button Trigger Switch Hook Pivot Shoe Shoe-Locking Lever Blade-Orbit Selector Lever Tool-Less Blade Clamp LED Worklight SPECIFICATIONS No-load Speed 0-3,100 SPM Blade Stroke 1-1/8” (29mm) Tool Weight (without battery) 5 lb. 15 oz. (2.7 kg) Page 7... -
Page 9: Assembly
ASSEMBLY WARNING: If any part is broken or missing, DO NOT attempt to attach the battery pack or operate the tool until the broken or missing part is replaced. Failure to do so could result in possible serious injury. WARNING: Do not attempt to modify this tool or create accessories not recommended for use with this tool. -
Page 10: Operation
OPERATION TO ATTACH BATTERY 4. Release the blade clamp to lock the blade in place. PACK (FIG. 1) NOTICE: When changing a blade immediately after operation, allow the 1. Make sure that the tool is switched off. blade to cool before removing to avoid 2. - Page 11 OPERATION VARIABLE-SPEED TRIGGER 4. Hold the saw firmly and then pivot the shoe to the desired angle. SWITCH (FIG. 5A & 5B) WARNING: To avoid injury and damage, do not operate the saw without Your reciprocating saw is equipped with a trigger switch to turn the saw on and off and the pivot shoe in place.
- Page 12 OPERATION ADJUSTING THE BLADE ORBIT FIG. 7 ACTION (FIG. 6) LED Worklight This reciprocating saw has the option of orbit action to make the blade swing slightly as it cuts. Orbital cutting action is conducive to removing saw-dust, which increases the cutting efficiency.
- Page 13 OPERATION 10. Open the lock-off button and press Your reciprocating saw is ideal for plunge the trigger switch to start the saw and cutting directly into surfaces that cannot be bring it to the maximum desired cutting cut from an edge, such as walls or floors. speed before applying the blade to the Plunge cutting may be done two ways, workpiece.
- Page 14 OPERATION METAL CUTTING The saw can be used to cut metals, such as sheet steel, pipe, steel rods, aluminum, brass, and copper. Be careful not to twist or bend the saw blade. Do not force. The use of cutting oil is recommended when cutting soft metals and steel.
-
Page 15: Maintenance
MAINTENANCE LUBRICATION WARNING: Always wear safety goggles or safety glasses with side All of the bearings in this tool are lubricated shields during power tool operations, or with a sufficient amount of high grade when blowing dust. If operation is dusty, lubricant for the life of the unit under normal also wear a dust mask. -
Page 16: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION The saw does not work. The battery is depleted. Charge the battery. The saw does not work and the tool The tool is overheated. Cool down the tool. LED worklight flashes. The saw does not work and two The battery is Cool down the battery. - Page 17 NOTES Page 16...
- Page 18 NOTES Page 17...
-
Page 19: Warranty
90-DAY MONEY BACK GUARANTEE: This MASTERFORCE brand power tool carries our 90-DAY Money Back ® Guarantee. If you are not completely satisfied with your MASTERFORCE brand ® power tool for any reason within ninety (90) days from the date of purchase, return... - Page 20 © 2020 Menard, Inc., Eau Claire, WI 54703 12/2020 Page 19...
