ZyXEL GS-3012 V3.80(LH.2)C0
Release Note/Manual Supplement
Date: Mar. 07, 2008
This document describes the features in the GS-3012 product for its 3.80(LH.2)C0 release.
Support Platforms:
ZyXEL GS-3012 V3.80(LH.2)C0 supports models: ZyXEL GS-3012
Version:
OS Version: V3.80(LH.2) | 03/04/2008 12:03:15
BootBase Version: V3.10 | 05/15/2007 14:47:07
Default Bootbase Setting:
ZyNOS Version
Bootbase Version
Vendor Name
Product Model
ZyNOS Code Model
HTP Code Model
ZyNOS ROM address
System Type
MAC Address
Default Country Code
Boot Module Debug Flag
RomFile Version
RomFile Checksum
ZyNOS Checksum
SNMP MIB level & OID
Main Feature Bits
Other Feature Bits
New Features
1.
Features:
1. MRSTP support
2. Multiple login supported (through RADIUS)
3. IGMP snooping timer configuration supported
4. RFC-2863 (Interface MIB), RFC-2674 (Extended Bridge MIB), RFC-2925 (Ping & Trace Route)
supported.
5. PLT (Packet Loop Test).
6. SSL/SSHv2
7. TFTP client/server.
8. Bridge control protocol transparency supported.
9. Radius management authentication.
V3.80(LH.2) | 03/04/2008 12:03:15
V3.10 | 05/15/2007 14:47:07
ZyXEL Communications Corp
GS-3012
GS-3012
Unknown
50080000
10
0019CB000001
FF
01
27
9316
435a
060102030405060708091011121314151617181920
C0
B1 00 00 00 00 00 00 00-00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00-00 41 13 00 00 00

Advertisement

loading

Related Manuals for ZyXEL Communications Dimension GS-3012

Summary of Contents for ZyXEL Communications Dimension GS-3012

  • Page 1 Release Note/Manual Supplement Date: Mar. 07, 2008 This document describes the features in the GS-3012 product for its 3.80(LH.2)C0 release. Support Platforms: ZyXEL GS-3012 V3.80(LH.2)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.80(LH.2) | 03/04/2008 12:03:15 BootBase Version: V3.10 | 05/15/2007 14:47:07...

  • Page 2: Enhanced Features

    10. Multiple login supported. 11. Multiple management IP supported. 12. Multiple ping/traceroute instances supported. 13. New CLI supported. 14. Multiple configurations supported. 15. System configuration backup / restore in text-mode. 16. DHCP relay and relay agent information (option-82) supported. 17. Read copper/fiber status on web. 18.

  • Page 3: Firmware Upgrade

    7. Classifier precedence will not follow longest prefix match. 8. Don’t set to L2 multicast hardware table when getting specific or general querier message Limitation of Settings: 1. VLAN 1Q static entry 1024 2. Static MAC forwarding entry 256 3. MAC filtering entry 256 4.
  • Page 4 • Password : the management password, 1234 by default • 380LH2C0.rom : the name of configuration file you want to upgrade • rom-0: the internal configuration name in GS-3012...
  • Page 5 Release Note/Manual Supplement Date: Sep. 12, 2007 This document describes the features in the GS-3012 product for its 3.80(LH.1)C0 release. Support Platforms: ZyXEL GS-3012 V3.80(LH.1)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.80(LH.1) | 09/06/2007 12:03:44 BootBase Version: V3.10 | 05/15/2007 14:47:07...
  • Page 6 15. TACACS+ accounting 16. Loop guard 17. Daylight saving Features: 1. MRSTP support 2. Multiple login supported (through RADIUS) 3. IGMP snooping timer configuration supported 4. RFC-2863 (Interface MIB), RFC-2674 (Extended Bridge MIB), RFC-2925 (Ping & Trace Route) supported. 5. PLT (Packet Loop Test). 6.

  • Page 7: Configuration Upgrade

    8. IGMP MVR entry 256 9. IGMP filtering profile 256 10. Syslog server entry 4 Firmware Upgrade: The GS-3012 uses FTP to upgrade firmware in run-time through its built-in FTP server. You can use any FTP client (for example, procedure is as follows: Upgrade GS-3012 FW: C:\>...
  • Page 8 Release Note/Manual Supplement Date: Aug. 6, 2007 This document describes the features in the GS-3012 product for its 3.80(LH.0)C0 release. Support Platforms: ZyXEL GS-3012 V3.80(LH.0)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.80(LH.0) | 08/01/2007 16:33:51 BootBase Version: V3.10 | 05/15/2007 14:47:07...
  • Page 9 15. TACACS+ accounting 16. Loop guard 17. Daylight saving Features: 1. MRSTP support 2. Multiple login supported (through RADIUS) 3. IGMP snooping timer configuration supported 4. RFC-2863 (Interface MIB), RFC-2674 (Extended Bridge MIB), RFC-2925 (Ping & Trace Route) supported. 5. PLT (Packet Loop Test). 6.
  • Page 10 4. Cluster member 24 5. Management IP address 64 6. Classifier entry 128 7. Policy rule entry 128 8. IGMP MVR entry 256 9. IGMP filtering profile 256 10. Syslog server entry 4 Firmware Upgrade: The GS-3012 uses FTP to upgrade firmware in run-time through its built-in FTP server. You can use any FTP client (for example, procedure is as follows: Upgrade GS-3012 FW:...
  • Page 11 Release Note/Manual Supplement Date: May 15, 2007 This document describes the features in the GS-3012 product for its 3.70(LH.1)C0 release. Support Platforms: ZyXEL GS-3012 V3.70(LH.1)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.70(LH.1) | 05/15/2007 14:21:31 BootBase Version: V3.10 | 05/15/2007 14:47:07...
  • Page 12 13. Multiple configurations supported. 14. System configuration backup / restore in text-mode. 15. DHCP relay and relay agent information (option-82) supported. 16. Upgrade switch driver to V.4.2.6. 17. Read copper/fiber status on web. 18. Bootbase version V3.00: using new MAC prefix 00-13-49 19.
  • Page 13 C:\> ftp <GS-3012 IP address> User : <Enter> Password: 1234 230 Logged in ftp> put 370LH0C0.bin ras ftp> bye Where • User name : just press <Enter> • Password : the management password, 1234 by default • 370LH0C0.bin : the name of firmware file you want to upgrade •...
  • Page 14 Release Note/Manual Supplement Date: Nov 27, 2006 This document describes the features in the GS-3012 product for its 3.70(LH.0)C0 release. Support Platforms: ZyXEL GS-3012 V3.70(LH.0)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.70(LH.0) | 11/27/2006 14:12:39 BootBase Version: V3.00 | 01/14/2005...
  • Page 15 13. Multiple configurations supported. 14. System configuration backup / restore in text-mode. 15. DHCP relay and relay agent information (option-82) supported. 16. Upgrade switch driver to V.4.2.6. 17. Read copper/fiber status on web. 18. Bootbase version V3.00: using new MAC prefix 00-13-49 19.
  • Page 16 ftp> bye Where • User name : just press <Enter> • Password : the management password, 1234 by default • 370LH0C0.bin : the name of firmware file you want to upgrade • ras : the internal firmware name in GS-3012 Configuration Upgrade: The GS-3012 uses FTP to upgrade firmware in run-time through its built-in FTP server.
  • Page 17 Release Note/Manual Supplement Date: April 26, 2006 This document describes the features in the GS-3012 product for its 3.60(LH.2)C0 release. Support Platforms: ZyXEL GS-3012 V3.60(LH.2)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.60(LH.2) | 04/26/2006 18:40:42 BootBase Version: V3.00 | 01/14/2005...

  • Page 18: Change History

    5. Do not support tagged frame forwarding in the Port-Based VLAN. Limitation of Settings: 1. VLAN 1Q static entry 1024 2. Static MAC forwarding entry 256 3. MAC filtering entry 256 4. Cluster member 24 5. Management IP address 64 6.
  • Page 19 When enabled Cluster Management, user can’t use Telnet or SSH client to rcommand member ,and the key in words in Telnet or SSH client will also print in console. V3.60(LH.0)C0 (2/3/2005) First Public version...
  • Page 20 Release Note/Manual Supplement Date: Dec 12, 2005 This document describes the features in the GS-3012 product for its 3.60(LH.1)C0 release. Support Platforms: ZyXEL GS-3012 V3.60(LH.1)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.60(LH.1) | 12/12/2005 18:13:54 BootBase Version: V3.00 | 01/14/2005...
  • Page 21 4. CLI "timesync" cause config resotre fail 5. Remove “time” and “time date” in backup configuration 6. In bandwidth control setting, specify the maximum bandwidth allowed in Kbps. 7. Restore config with IP address fail becasue out-of-band and inband exchange IP addresses.
  • Page 22 Bug Fixed : 1. CPU utilization division by 0 will cause crash when generate ssh/ssl key 2. Windows File Sharing low performance 3. Receiving jumbo packet cause system hang 4. CLI "timesync" cause config resotre fail 5. Remove “time” and “time date” in backup configuration 6.
  • Page 23 Release Note/Manual Supplement Date: Feb 03, 2005 This document describes the features in the GS-3012 product for its 3.60(LH.0)C0 release. Support Platforms: ZyXEL GS-3012 V3.60(LH.0)C0 supports models: ZyXEL GS-3012 Version: OS Version: V3.60(LH.0) | 02/03/2005 BootBase Version: V3.00 | 01/14/2005...
  • Page 24 11. Multiple configurations supported. 12. System configuration backup / restore in text-mode. 13. DHCP relay and relay agent information (option-82) supported. 14. Upgrade switch driver to V.4.2.6. 15. Read copper/fiber status on web. 16. Remove cluster management from web. 17. Disable web session idle timeout on web 18.
  • Page 25 Configuration Upgrade: The GS-3012 uses FTP to upgrade firmware in run-time through its built-in FTP server. You can use any FTP client (for example, procedure is as follows: Upgrade GS-3012 configuration: C:\> ftp <GS-3012 IP address> User : <Enter> Password: 1234 230 Logged in ftp>...
