ZyXEL Communications Dimension GS-3012 Support Notes

ZyXEL Communications Dimension GS-3012 Support Notes

Ipsubnetting vlan
Hide thumbs Also See for Dimension GS-3012:

Advertisement

Quick Links

Download this manual See also: User Manual, Cli Reference Manual
IPSubnetting VLAN
Ethernet Switch
ZyNOS 3.8

Support Notes

Version 3.80
September 2007

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dimension GS-3012 and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications Dimension GS-3012

Summary of Contents for ZyXEL Communications Dimension GS-3012

  • Page 1: Support Notes

    IPSubnetting VLAN Ethernet Switch ZyNOS 3.8 Support Notes Version 3.80 September 2007...
  • Page 2 Subnet based VLANs allow users to group traffic into logical VLANs based on the source IP address and IP subnet. When a frame is received on a port, the switch checks where the IP subnet it came from and what the source IP address is. The untagged packets from the same IP subnet are then placed in the same subnet based VLAN.
  • Page 3 In this topology, three IP services are needed by customer, VoIP, IPTV, and general network access. Each client belongs to different IP subnets. We can achieve this purpose using the switch with IPSubnetting VLAN function. All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 4 5. By default, the username for the administrator is “admin” and the password is “1234”. 6. After successfully logging in you will see a screen similar to the one below. 7. Go to “Static VLAN” page by clicking “Advanced Application” ”VLAN” ”Static VLAN” All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 5 VLAN tag. Port 2 connects to the router in the CO, and packets going in and out port 2 should have different VLAN tags according to its IP address. Click “Add”. All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 6 VLAN tag. Port 2 connects to the router in the CO, and packets going in and out port 2 should have different VLAN tags according to its IP address. Click “Add”. All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 7 IPSubnetting VLAN 11. Go to “VLAN Port Setting” page by clicking “Advanced Application” “VLAN” “VLAN Port Setting” 12. Go to “Subnet Based VLAN” page. All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 8 “Active” check box to enable it. Click “Apply” 14. Create the Subnet Based VLAN entry for the VoIP phone. Here we see that packets from 192.168.1.10/24 will be attached a VLAN tag 3 and its All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 9 16. Create the Subnet Based VLAN entry for the PC. Here we see that packets from 192.168.10.10/24 will be attached a VLAN tag 5 and its priority will be set to 7. Click “Add” All contents copyright (c) 2007 ZyXEL Communications Corporation.
  • Page 10 VoIP source-ip 192.168.1.10 mask-bits 24 vlan 3 priority 2 subnet-based-vlan name IPTV source-ip 192.168.5.10 mask-bits 24 vlan 4 priority 5 subnet-based-vlan name PC source-ip 192.168.10.10 mask-bits 24 vlan 5 priority 7 All contents copyright (c) 2007 ZyXEL Communications Corporation. IPSubnetting VLAN...
