ZyXEL Communications Dimension GS-1116A Specifications

GS-1116A
16-port Unmanaged Gigabit Ethernet Switch
Non-blocking Gigabit wire-speed
forwarding to fly the transmission
Jumbo frame mode support
(up to 10K bytes) to maximize
efficiency of transmission for
giant packets
IEEE802.1p CoS support to
priority transmission according to
packet priority level
IEEE 802.3x Flow control to
optimize transmission by
reducing congestion
2 built-in Dual-personality
(RJ-45 or SFP open slot) interfaces
for flexible deployment
Auto MDI/MDI-X support for
hales-free usage
1U, 19" rack mountable
16/24-port Unmanaged
Gigabit Ethernet Switch
gs-1116a
gs-1124a
GS-1124A
24-port Unmanaged Gigabit Ethernet Switch
Cost Advantage Solution for
Gigabit-to-the Desktop
Benefits
Cost-effective Solution for Gigabit Migration
ZyXEL GS-1116A/GS-1124A is a 16-port/24-port unmanaged gigabit switch providing a cost-effective
solution to empower "Gigabit to the desktop" connectivity. This brings significant performance
improvement with increased network bandwidth. In addition, the GS-1116A/GS-1124A come with two dual
personality (RJ-45 or SFP open slot) interfaces. It offers flexible connectivity (copper or fiber) to adapt to
different deployment environments.The GS-1116A/GS-1124A is an ideal solution for bandwidth-hungry
applications (such as high resolution digital image transmission, video/audio file streaming/downloading,
server farm connectivity).
Wire-speed Gigabit Engine to Fly the Transmission
With a robust hardware design, the GS-1116A/GS-1124A performs packet forwarding at wire-speed, which
can instantly transfer giant packets without performance degradation. In addition, with the support of
802.3x flow control, the GS-1116A/GS-1124A guarantees smooth transmission by adjusting packet
transmission to reduce congestion. IEEE802.1p CoS allows the GS-1116A/GS-1124A to send packets based
on the priority level to optimize multi-service applications, like VoIP, video conferencing or video streaming.
In addition, the GS-1116A/GS-1124A supports jumbo frame transmission up to 10K bytes to improve
transmission efficiency and network performance.
Hassle-free Installation and Usage
Connectivity can be as easy as connecting to a port on the switch. All the rest of the functions are done
automatically. All ports on the GS-1116A/GS-1124A are Auto MDI/MDIX; that means you don't need to
check the Ethernet cable type. In addition, auto-negotiation helps adjust link speed intelligently to reach
the best link quality. In other words, there is not hassle of twigging with the switch or pouring over the user
manuals. The GS-1116A/GS-1124A is rack mountable, allowing you to place it in a rack to save precious
office space.
