- Page 1 Page title Owner’s Manual SANCO Heat Pump Water Heater with Natural Refrigerant(CO Page title Covering model numbers for residence O O w w n n e e r r ’ ’ s s m m a a n n u u a a l l Heat Pump Unit GS3-45HPA-US Heat Pump Units...
-
Page 2: Table Of Contents
This water heater may be protected by one or more patents or registered designs in the name of ECO2 System LLC TRADE MARKS ® Registered trademark of ECO2 Systems LLC Note: Every care has been taken to ensure accuracy in preparation of this publication. -
Page 3: Introduction
Introduction Introduction The Sanden Sanco SANCO Heat Pump Water Heater System has been designed using the latest The Sanden Heat Pump Water Heater System has been designed using the latest refrigeration technology to remove the heat from the air to heat water. The refrigerant used refrigeration technology to remove the heat from the air to heat water. - Page 4 ■ The extent of the possible harm or damage caused by misuse of the product falls into the following classifications. Indicates an imminently hazardous situation that will result in death Danger or serious injury in case it is not avoided. The column with this classification indicates “the extent of harm that Warning includes the possibility of death or serious injury”.
- Page 5 Warning If the water heater has been subjected to fire, flood, natural disasters or physical damage, DO NOT operate the water heater again until it has been checked by a qualified service technician. Failure to do so will cause injury. Hydrogen gas can be produced in a hot water tank served by this water heater that has not been used for two weeks or more.
- Page 6 Warning ・Please contact the Dealer about insulating the pipes. ・Contact the Dealer for repair. Sanden Heat Pump – Owner’s Manual Page 5 of 20 SANCO Heat Pump – Owner’s Manual Page 6 of 28...
- Page 7 Caution Could harmfully influence performance and lead to failure. Could significantly influence performance and lead to failure. Check the installation conditions of the unit. Check the installation conditions of the unit. Installation of the unit in the following places could result Installation of the unit in the following places could result in accidents or failure and the performance of the unit in accidents or failure and the performance of the unit...
-
Page 8: Installation Details
DHW in combination with space heating requires both a potable and non-potable water and consultation with Sanden. potable and non-potable water and consultation with Sanden. ECO2 Systems. heat exchanger suitable for local codes to be installed on the system to separate Installation details potable and non-potable water and consultation with Sanden. -
Page 9: Trouble Shooting Guide
Trouble shooting guide Trouble Shooting Guide If you face a problem while using our Heat Pump water heater system, please check the If you are faced with a problem in using our Hot Water Heat Pump system, please check following table prior to calling for support. the following items, before seeking professional help. -
Page 10: Error Codes
Error Codes When an error has occurred, a red LED on the operation panel turns on and an error code is displayed on the LED display. The panel does not turn to the display sleep mode while the error code is shown. Figure 3 Error Code example Below is the list of the error codes. -
Page 11: Filling The System & Bleeding Air
Filling the System & Bleeding Air Removing air from the system CAUTION : Be sure to follow the procedure below. Please note: If the procedure is not followed, the pump may run idle and be damaged. Plumbing work should only be completed by a licensed plumber The following steps must be taken to ensure all air is bled from the system. -
Page 12: Mains Power/Electrical Installation
Mains Power/Electrical Installation All Electrical Wiring should be done in accordance with the latest edition of the National Electrical Code (NEC) and all local State/Province and Municipality codes. The power requirement for the system is a dedicated 15 amp circuit fitted with a ... - Page 13 How to Connect Main Power Remove the power box cover (Philips head screwdriver required) Connect the power wiring to the terminal block per the wiring diagram/manual. Ensure ground wire is connected. Secure the power supply wiring below the terminal block with the screw clamp fitting. Re attach the power box cover to the heat pump unit.
-
Page 14: How To Connect Thermistor Cable And Modbus Cable
How to Connect Thermistor Cable and Modbus Cable Remove the piping cover. Power supply 208/230V Connect the thermistor cable and the modbus cable line to the terminal block. Ground Fix the thermistor cable and the modbus cable with the code clip and conduit clip. Wire holder band Attach the piping cover back on the heat pump unit. -
Page 15: System Operation If Connected To Dry Contact
Ensure that the work site is tidy; Sanden International recommends the use of Slim Duct or ECO2 Systems LLC recommends the use of Slim Duct or Fortress product to cover water piping on the outside of the house Sanden Heat Pump –... -
Page 16: Water Supply Quality
Water Supply Quality (Supplemental) Chloride and PH Water Supply Quality In areas with a high concentration of chloride in the water, that water can cause Chloride, Water Hardness and pH corrosion and subsequent failures. Where the chloride level exceeds 0.1 ounces per In high chloride water supply areas, the water can corrode some parts and cause them gallons (200 mg/litre), the warranty is no longer valid on to the heat pump unit and tank to fail. -
Page 17: Technical Data
Specifications Technical Data Heat Pump Stainless Steel Storage Tank Dimensions Storage Tank " 11" ECO-43SSAQB ECO-83SSAQB ECO-119GLBB Tank Model No: SAN-43SSAQA SAN-83SSAQA SAN-119GLBK* /SAN-43SSAQA /SAN-83SSAQA /SAN-119GLBK* 119-gal. sys. Height " ” 5” 3.23 B Hot Water Outlet & PR Valve "... - Page 18 GS3-45HPA-US Dimensions GS5-45HPC/GS5-45HPC-D Dimensions DRAIN CONNECTOR 16.24” 3.86” 4.82” 22.83” 4.82” 0.91” 32.48” 2.7” 0.88” 11.81” 2.39” 5.85” 1.08” HP INLET (COLD WATER) PT1/2 HP OUTLET (HOT WATER) PT1/2 Unit ： inch Specification Refrigerant type R744(CO2) Refrigerant type R744(CO2) Refrigerant Change 25.4oz (720g) Mass volume 22 oz.
- Page 19 The warranty period is that stated below, which is not the same period as the Residential DHW system. SANCO Heat Pump – Owner’s Manual 1-3.1. Combined DHW/Heating application; Heat Pump unit Page 19 of 28 Eco2 Systems LLC warrants all parts & labor on the SANCO₂ Combi Heat Pump unit for a period of 1 year...
- Page 20 1-3.1. Combined DHW/Heating application; Heat Pump unit Eco2 Systems LLC warrants all parts & labor on the SANCO₂ Combi Heat Pump unit for a period of 1 year Eco2 Systems LLC warrants all parts & labor on the SANCO₂ Combi Heat Pump unit for a period of 1 year Eco2 Systems LLC warrants all parts &...
- Page 21 Warranty Exclusions Repair and replacement work will be carried out as set out in the Eco2 Systems LLC Heat Pump Water Repair and replacement work will be carried out as set out in the Eco2 Systems LLC Heat Pump Water Heater System warranty.
- Page 22 Eco2 Systems LLC shall not be liable by virtue of this warranty or otherwise for damage to any persons or property, whether direct or indirect, and whether arising in contract or in tort.
- Page 23 Exhibit A: Labor Costs Labor costs are paid per the payment cost schedule published by Eco2 Systems LLC and revised from time to time at Eco2 Systems LLC’s requirement. Labor warranty specifically excludes (unless agreed to in writing prior to service being carried out) costs...
-
Page 24: Registration For Warranty
Please Note: Similar registration details will be provided to ECO2 Systems LLC by your Please Note: Similar registration details will be provided to Sanden by your supplier/installer to supplier/installer to validate their claim for warranty support;... -
Page 25: Memo
Memo -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- ------------------------------------------------------------------------------- Sanden Heat Pump – Installation Manual SANDEN Heat Pump SANCO Heat Pump –... - Page 26 Memo -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- ------------------------------------------------------------------------------- Sanden Heat Pump – Installation Manual SANDEN Heat Pump SANCO Heat Pump –...
- Page 27 Memo -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- ------------------------------------------------------------------------------- Sanden Heat Pump – Installation Manual SANDEN Heat Pump SANCO Heat Pump –...
- Page 28 Memo -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- ------------------------------------------------------------------------------- Sanden Heat Pump – Installation Manual SANCO HEAT PUMP SANDEN Heat Pump...
Need help?
Do you have a question about the SANCO2 GS5-45HPC and is the answer not in the manual?
