inVue ZW1921 Operation And Merchandising Manual

ZW1921-22 merchandising
1 Place a charged and coded
OneKEY onto the Zips Alarm Unit.
Press the button on the key to
deactivate the Alarm Unit.
5 Open the band clamp.
2 Place a DBG400 Magnet Key onto
the lock icon on the Alarm Unit.
Pull the sensor free from the Alarm
Unit.
6 Unplug the sensor from the WS2
Recoiler/W2000 cable.
3 Remove the wearable from the
cradle and pull enough of the
cable from the stand to facilitate
the removal. Place the cable clip
(included with the WS2 Recoiler/
W2000 stand) over the cable and
snap it closed.
7 Carefully lift one corner of the
sensor from the wearable.
1
4 Use the TT8 bit with the multitool
to remove the band clamp screw.
8 Lift the other corners away from
the wearable and remove the
sensor.
