- Page 1 USER MANUAL ADAPTER FOR MEASURING LEAKAGE CURRENTS PAT-IPE SONEL S.A. Wokulskiego 11 58-100 Świdnica Poland Version 1.01 23.10.2023...
- Page 2 PAT-IPE – USER MANUAL...
-
Page 3: Table Of Contents
2.1 Leakage current measurement on welding machine circuit ........5 2.2 Measurement of PE leakage current in three-phase devices ........9 3 Cleaning and maintenance ................11 4 Dismantling and Disposal ................11 5 Manufacturer ....................11 PAT-IPE – USER MANUAL... -
Page 4: Safety
Tested device connected to the adapter has no direct connection to PE of the mains. The manufacturer shall not be responsible for losses caused by connecting the adapter to a damaged device. PAT-IPE – USER MANUAL... -
Page 5: Intended Use Of The Adapter
Turn on the power supply of PAT-806 meter. Press I but- ton twice. The screen informing about the readiness for measurement will be displayed. When parameters must be changed press SET. buttons to set the upper limit of leakage current I PAT-IPE – USER MANUAL... - Page 6 Depending on the type of power supply provided to the welding machine - apply one of the following diagrams. Unused leads must be plugged into appropriate sockets. Con- nect the banana socket of the adapter to I2 socket of PAT-806. Power supply from 230 V mains Mains socket Mains socket PAT-IPE – USER MANUAL...
- Page 7 Mains socket Three-phase power supply (32 A) Mains socket With continuous measurement set (time = ) press and hold START. To block the measurement press ENTER. At the time with pre-set value it is not necessary. PAT-IPE – USER MANUAL...
- Page 8 Time remaining to the end of the measurement The measurement ends after a preset time runs out or after pressing STOP/ESC. After the measurement is completed, read the result. Correct result: I < LIMIT Incorrect result: I > LIMIT PAT-IPE – USER MANUAL...
-
Page 9: Measurement Of Pe Leakage Current In Three-Phase Devices
Connect the socket plug of the tested device into the test sock- et of the meter. In addition, it is possible to carry out the meas- urement with the probe connected to R - socket. Three-phase power supply (16 A) Mains socket PAT-IPE – USER MANUAL... - Page 10 Details for setting parameters of individual measurements are presented in the man- uals of PAT meters. Measurement of PE leakage current in single-phase devices must be performed di- rectly on the measuring socket of a PAT meter manufactured by Sonel S.A., without using the PAT-IPE adapter. PAT-IPE – USER MANUAL...
-
Page 11: Cleaning And Maintenance
The manufacturer of the device and provider of guarantee and post-guarantee service: SONEL S.A. Wokulskiego 11 58-100 Świdnica Poland tel. +48 74 884 10 53 (Customer Service) e-mail: customerservice@sonel.com web page: www.sonel.com NOTE! Service repairs must be performed only by the manufacturer. PAT-IPE – USER MANUAL... - Page 12 NOTES PAT-IPE – USER MANUAL...
