- Page 1 USER MANUAL THREE-PHASE SOCKET ADAPTERS FOR ELECTRICAL APPLIANCE SAFETY TESTERS PAT SONEL S. A. Wokulskiego 11 58-100 Świdnica Version 1.03 01.06.2020 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 2 This manual applies to adapters supplied as accessories to PAT electrical safety meters. NOTE! Adapters are designed for measurements performed with PAT meters. They are not recommended for using in other applications. Adapters for single-phase industrial sockets 16 A – WAADAPAT16F1 32 A –...
- Page 3 Switchable Five-wire The adapters are provided with a 16 A – WAADAPAT16PR 32 A – WAADAPAT32PR rotary switch that provides con- nections shown below: Four-wire 1 – L line of the test socket con- nected with L1 16 A – WAADAPAT16CPR 32 A –...
- Page 4 Adapters for three-phase plugs The adapters are provided with a rotary switch that provides con- 16 A – WAADAPAT16PRIEC 32 A – WAADAPAT32PRIEC nections shown below: L line of the test socket con- L1 – nected with L1 L2 – L line of the test socket con- nected with L2 L line of the test socket con-...
