RAYSTECH RT5120 Manual page 10

S Pro battery indicator operating status description
The green indicator light flashes
every 1S
The green indicator light flashes
rapidly at high frequency
The indicator light off
S Series Common Fault Codes and Solutions
Error
Fault description
code
Undervoltage in non-charging
098
state
Overvoltage in non-charging
099
state
100 Battery over temperature
101 Battery under temperature
102 MOS over temperature
103 MOS under temperature
104 Hardware overvoltage
105 Software overvoltage
106 Software undervoltage
107 Discharge overcurrent
108 Charge overcurrent
S PRO Series Common Fault Codes and Solutions
Error
Fault description
code
061 Cell undervoltage
062 Cell overvoltage
063 Hardware short circuit
064 Hardware overcurrent
065 Software short circuit
066 Software overcurrent
The battery is working normally
The battery is faulty and the corresponding fault code is
displayed on the screen
The battery is off and not working
Charge the battery individually
Discharge the battery individually
Disconnect the load, move the battery away from
the heat source, and restart the battery after the
temperature drops to the ambient temperature.
Disconnect the
temperature rise to the ambient temperature, then
restart the battery
Disconnect the load, move the battery away from
the heat source, and restart the battery after the
temperature drops to the ambient temperature.
Disconnect the
temperature rise to the ambient temperature, then
restart the battery
Discharge the battery individually
Discharge the battery individually
Charge the battery individually
Disconnect the load and reduce the battery
discharge current
Disconnect the charger to reduce battery charging
current
Charge the battery individually
Discharge the battery individually
Disconnect the load, restart the battery
Disconnect the load, restart the battery
Disconnect the load, restart the battery
Disconnect the load, restart the battery
Troubleshooting
load, wait for
load, wait for
Troubleshooting
the battery
the battery
